9-14
Operation Examples (Standard menu: Area measurement by binary conversion)
9
F.IMG C1 L
VX.X
(TYPE00)
OK
MEAS XXXXms XXXX-XX-XX XX:XX
MEASUREMENT 1 MEAS-BIN-AREA
CHG-MEA CHG-REG CHG-RST CHG-C1 CHG-C2 CHG-EVAL
CUSTOM-MNU
OPS-CND MEA-CND SYS-CND CHG-TYPE NEXT-NG
RE-EXAM-NG MANL-MEAS
X0~7 Y0~7 READY
A00=001884 OK
A01=
A02=
A03=
A04=
A05=
A06=
A07=
*2
Continued from the previous page
Press the TRG/BRT key, and the size of the area measured will be displayed as the number of pixels contained
within the area.
(12) Area measurement
*1 The final evaluation result will be displayed as "OK" in the upper left corner of the screen when all of the
items have been evaluated acceptable. If there is a single unacceptable item, "NG" will be displayed.
The only item used for the evaluation in the area measurement by binary conversion is the area. The result
will be OK if it falls within the evaluation conditions that are specified in step (11) (upper and lower limits).
*2 When the evaluation result is OK, Y0 will be turned ON because we set it that way in step (11), and a filled
box will be displayed. (If the result is NG, an empty box will be displayed.)
[Display of the measured result]
Final evaluation result (*1)
Measuring time
Area of registration number 00
(number of pixels) and evaluation
result
Saving data
- Although the specified data is temporarily stored in RAM memory, it is not stored in the flash memory.
So, you must save the data manually using the save operation. If you do not save the data in the flash
memory, it will be deleted when the IV-S30 controller is turned OFF.
- You can save data at any time using the "SAVE" item on the [TYPE MEAS COND], [TYPE RUN COND],
or [SYSTEM COND] menu.
[TYPE MEAS COND] menu
1. On each menu screen, move the cursor to "SAVE" using the up/down and left/right keys, and
press the SET key.
- The following message will be displayed on the screen.
DATA SAVE? (Do you want to save the data?) (YES=[SET]/NO=[ESC])
2. Press the SET key.
- The IV-S30 will start saving the data and the progress will be displayed on the bottom of the
screen.
When the data has been saved in the IV-S30 flash memory, the display will change from
"SAVING" to "COMPLETE SAVE."
[TYPE MEAS COND]
①
OBJECT TYPE NO.
00(0~63) NO YES
②SELECT CAMERA CAM1&2 CAM1&NG-IMG
1
OPS-MENU SAVE LOCK TITLE FINAL-CALC FINAL-OUTPUT I/O SYSTEM
REFERENCE IMG
SYSTEM I/O
OBJECT TYPE COND
■■
■
■■■■■■■■■■■□□□□□
SAVING
