9-20
Operation Examples (Standard menu: Positional deviation measurement)
9
REFERENCE IMG
SYSTEM I/O
OBJECT TYPE COND
■■
■
■■■■■■■■■■■□□□□□
SAVING
To the next page
Continued from the previous page
(11) Saving data
Although the specified data is temporarily stored in RAM memory, it is not stored in the flash
memory. So, you must save the data manually using the save operation. If you do not save the
data in the flash memory, it will be deleted when the IV-S30 controller is turned OFF.
- You can save data at any time using the "SAVE" item on the [TYPE MEAS COND], [TYPE RUN
COND], or [SYSTEM COND] menu.
(In this example, data is saved while in the [TYPE MEAS COND] menu.)
1. Move the cursor to the "SAVE" item using the left and right keys, and press the SET key.
- The following message will be displayed on the screen.
DATA SAVE? (Do you want to save the data?) (YES=[SET]/NO=[ESC])
2. Press the SET key.
- The IV-S30 will start saving the data and the progress will be displayed on the bottom of the
screen.
When the data has been saved in the IV-S30 flash memory, the display will change from
"SAVING" to "COMPLETE SAVE."
3. Move the cursor to the "OPS-MENU" item using the left and right keys, and press the SET key.
- The screen will return to the MAIN OPS MENU.
3
1
[TYPE MEAS COND]
①
OBJECT TYPE NO.
00(0~63) NO YES
②SELECT CAMERA CAM1&2 CAM1&NG-IMG
OPS-MENU SAVE LOCK TITLE FINAL-CALC FINAL-OUTPUT I/O SYSTEM
