6-4

Setting and Operating Outlines

[2] Method for selecting the menu configuration

(1) When power is first turned ON after the machine is delivered

When power is first turned ON after the machine is delivered, the [SELECT MENU] screen will

appear.

* For the IV-S33M

- For details about the method for using the simplified menus, see Chapter 7, "Simplified Menu

Operation."

- For details about the method for using the standard menus, see the User’s Manual (Function

and Operation).

Notes

- If you have saved the configuration data in flash memory by selecting the "SAVE" item, the

next time you turn ON the power, the menu configuration you selected will be displayed

automatically.

1 To select the standard menus configuration

1. Move the cursor to the [1STANDARD MENU]

item with the up and down keys, and press the

SET key.

- The standard mode [MAIN OPS MENU] screen

will appear.

2 To select the simplified menus

configuration

1. Move the cursor to the [2

SIMPLIFIED MENU] item with the

up and down keys, and press the

SET key.

- The [SIMPLIFIED MENU] screen

will appear.

[SELECT MENU]

1STANDARD MENU (STD RUN-MENU)

2SIMPLIFIED MENU (SEL EASY MENU)



1. Move the cursor to the item you want to set

with the up and down keys, and press the

SET key.

2. Move the cursor to the item you want to

specify with the left and right keys, and press

the SET key.

3. Move the cursor to the OPS-MENU item with

the up and down keys, and press the SET

key.

- The [MAIN OPS MENU] screen will appear.

Camera 1: Use only CAMERA 1

Camera 1& 2: Use both CAMERA 1 and CAMERA 2

When the [

1MEAS OBJ] is set to

[EXISTENCE], [3 XY CORRECTION] item

is displayed. Select "YES" to execute an XY

correction.

[SIMPLIFIED MENU]

1MEAS OBJ POSITIONING EXISTENCE

SELECT CAMERA

CAM1 CAM1&2

XY CORRECTION

NO YES

OPS-MENU

Positioning (CAMERA 1 & 2)

Existence inspection (CAMERA 1 & 2, XY correction: YES)

Power ON

[SIMPLIFIED MENU]

[SELECT MENU]

F.IMG C1 H

VX.XX

(TYPE00)



MEAS 0000ms 2000-08-01 10:30

MEASUREMENT POSITION CORRECTION

CHG-TYPE AUX-COND AUX-EVAL. EXIST-COND EXIST-EVAL. SEL-CAMERA

OPS-CND SYS-CND ADJ-CONTRAST SAVE SHUTTER

X0~7 Y0~7

READY

31 

×

39 

47 

55 

×

F.IMG C1 H

VX.XX

(TYPE00)

MEAS 0000ms 2000-08-01 10:30

MEASURE0 CAM1 NO

CHG-MEA

CHG-REG

CHG-RST

CHG-C1

CHG-C2

CHG-EVAL

CUSTOM-MNU

OPS-CND SYS-CND SYS-CND CHG-TYPE NEXT-NG RE-EXAM-NG MANL-MEAS

X0~7

7 READY



F.IMG C1 H

VX.XX



(TYPE00)



MEAS 0000ms 2000-08-01 10:30

MEASURE 0 CAM1 POSITIONING

CHG-TYPE

POSI-COND

POSI-EVAL. SEL-CAMERA

OPS-CND

SYS-CND

ADJ-CONTRAST

SAVE

SHUTTER

X0~7 Y0~7 READY

×
