PN-70HC1E Dismantle Instruction LCD MONITOR MODEL PN-70HC1E Dismantle Instruction 1
PN-70HC1E Dismantle Instruction Table of contents 1. Scope ............................................................................................................... 3 2. Tools for dismantling............................................................................................. 3 3. Dismantle Procedure ............................................................................................ 3 4. Back covers ..............................................................................
PN-70HC1E Dismantle Instruction 1. Scope This document describes dismantling instruction according to Annex VII of Directive 2012/19/EU. 2. Tools for dismantling Below tools are required to dismantle this product. - Screw Driver Nipper 3. Dismantle Procedure This product can be dismantled by below steps. 1. Remove Back covers (section 4) 2. Remove the shielding 3. Remove Printed circuit boards (section 5) 4. Remove battery (section 6) 5. Dismantle LCD (section 7) 6.
PN-70HC1E Dismantle Instruction 4. Back covers Back covers can be removed by screw driver.
PN-70HC1E Dismantle Instruction 5. Printed circuit boards All PWBs can be removed by screw driver.
PN-70HC1E Dismantle Instruction 6. Batteries This model uses CR2032 Lithium Coin battery on MAIN PWB. Battery CR2032 can easily be removed from the battery holder. This model uses AAA battery for remote control.
PN-70HC1E Dismantle Instruction 7. LCD Module bezels/bracket - LCD Dismantle procedure 1. Remove screws 2. Remove Cover glass and Bezels 3. Remove screws 4. Remove Middle Frame 5. After you have removed the PWB´s, the cover glass and bezels please take out the cables from the LCD module.
PN-70HC1E Dismantle Instruction 8. Capacitors Electrolyte Capacitors which diameter/height is larger than 25mm is installed on the Power PWB. These capacitors can be removed by using nipper to cut the leads. 9. Parts List Parts described in Annex VII of directive 2012/19/EU are as below.
