PN-70TW3 PN-60TW3 LCD MONITOR OPERATION MANUAL
Information on the Disposal of this Equipment and its Batteries IF YOU WISH TO DISPOSE OF THIS EQUIPMENT OR ITS BATTERIES, DO NOT USE THE ORDINARY WASTE BIN, AND DO NOT PUT THEM INTO A FIREPLACE! Used electrical and electronic equipment and batteries should always be collected and treated SEPARATELY in accordance with local law. Separate collection promotes an environment-friendly treatment, recycling of materials, and minimizing final disposal of waste.
IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
DEAR SHARP CUSTOMER Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of trouble-free operation of your product, please read the Safety Precautions carefully before using this product. SAFETY PRECAUTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety.
SAFETY PRECAUTIONS (Continued) 19. Batteries — Incorrect use of batteries may cause the batteries to burst or ignite. A leaky battery may corrode the equipment, dirty your hands or spoil your clothing. In order to avoid these problems, make sure to observe the precautions below: • Use the specified batteries only. • Install the batteries with due attention to the plus (+) and minus (-) sides of the batteries according to the instructions in the compartment. • Do not mix old and new batteries.
TIPS AND SAFETY INSTRUCTIONS - The TFT color LCD panel used in this monitor is made with the application of high precision technology. However, there may be minute points on the screen where pixels never light or are permanently lit. Also, if the screen is viewed from an acute angle there may be uneven colors or brightness. Please note that these are not malfunctions but common phenomena of LCDs and will not affect the performance of the monitor.
MOUNTING PRECAUTIONS • This product is for use indoors. • A mounting bracket compliant with VESA specifications is required. • Since the monitor is heavy, consult your dealer before installing, removing or moving the monitor. • Mounting the monitor on the wall requires special expertise and the work must be performed by an authorized SHARP dealer. You should never attempt to perform any of this work yourself.
Contents IMPORTANT INFORMATION.............................................3 DEAR SHARP CUSTOMER...............................................4 SAFETY PRECAUTIONS...................................................4 TIPS AND SAFETY INSTRUCTIONS................................6 MOUNTING PRECAUTIONS.............................................7 Supplied Components......................................................9 System Requirements......................................................9 Part Names.......
Supplied Components If any components are missing, please contact your dealer.
Part Names nFront view 6 7 7 7 7 1 2 3 5 4 1. Power button / Power LED (See page 18.) 2. Remote control sensor (See page 15.) 3. TOUCH MENU button (See page 25.) nRear view 5 4. 5. 6. 7.
Part Names nRemote control unit 1 2 7 3 8 4 9 10 5 1. Signal transmitter 2. POWER button (See page 18.) 3. MUTE button (See page 26.) 4. VOL +/- buttons (See page 26.) BRIGHT +/- buttons (See page 27.) Cursor control ( / / / ) buttons 5. DISPLAY button (See page 27.) 6. MODE button (See page 27.) 7. INPUT button (See page 26.) 8. MENU button (See page 26.) 9. ENTER button (See page 27.) 10. RETURN button (See page 27.) 11. SIZE button (See page 27.
Connecting Peripheral Equipment 19 17 18 14 13 6 2 3 8 16 10 9 11 12 15 Caution • Be sure to turn off the main power switch and disconnect the plug from the power outlet before connecting/ disconnecting cables. Also, read the manual of the equipment to be connected. • Be careful not to confuse the input terminal with the output terminal when connecting cables. Accidentally reversing cables connected to the input and output terminals may cause malfunctions and the other problems.
Connecting Peripheral Equipment 7. 8. • • Audio 1 input terminal Audio 2 input terminal Use an audio cable without resistance. Set the audio input terminal to be used in each input mode in AUDIO SELECT on the SETUP menu. 9. DisplayPort output terminal • The screen displayed on the monitor and the audio output from the monitor can be output to an external device. • Use a commercially available DisplayPort cable (conforming to the DisplayPort standard).
Connecting the Power Cord Caution Main power switch • Use only the power cord supplied with the monitor. 1 1. Turn off the main power switch. 2. Plug the power cord (supplied) into the AC input terminal. 3. Plug the power cord (supplied) into the AC power outlet. For power outlet 3 2 Power cord (Supplied) AC input terminal Binding Cables The cables connected to the terminals on the rear of the monitor can be fastened with the cable clamp.
Preparing the Remote Control Unit Installing the batteries Remote control operation range 1. Press the cover gently and slide it in the direction of the arrow. The operation range of the remote control unit is approx. 16.4 feet (5 m) at an angle of approx 10° from the center to the top/ bottom/right/left of the remote control sensor. 2. See the instructions in the compartment and put in the supplied batteries (R-6 (“AA” size) x 2) with their plus (+) and minus (-) sides oriented correctly. 3.
Removing the Handles The handles can be removed. Handle Handle screws Caution • The removable handles and handle screws are for use with this monitor. Do not use them for any other devices. • To attach handles, be sure to use the handles and handle screws which were removed from this monitor. • Be sure the handles are attached securely.
Connecting the wireless adapter To connect a computer to this monitor by wireless, connect the wireless adapter (supplied) to this monitor. 1. Remove the screw next to the wireless adapter port on this monitor. 3. Attach the wireless adapter cover (supplied), and fasten with the screw you removed in step 1. Wireless adapter port Wireless adapter cover 2. Insert the wireless adapter (supplied) into the wireless adapter port.
Turning Power On/Off Caution • Turn on the monitor first before turning on the computer or playback device. • To keep the performance of the wireless controller stable, put the monitor in the Power off (Standby mode) state once a day. • When switching the main power switch or the POWER button off and back on, always wait for at least 5 seconds. A short interval may result in a malfunction. Turning power on 1. Press the POWER button.
Turning Power On/Off nOperation mode When the monitor is turned on for the first time after being shipped from the factory, the operation mode setting screen will be displayed. Set it to MODE1 or MODE2. MODE1 ����OFF IF NO OPERATION is set to ON, and POWER SAVE MODE is set to ON. (These settings can not be changed.) Determines whether or not to set the monitor to go into standby mode when there is no operation from the remote control unit, or LAN for over 4 hours.
Touch Panel / Touch Pen Preparations Connecting the touch pen adapter Computer preparations To use the touch pen, insert the touch pen adapter into the touch pen adapter port on the monitor. To use the touch panel, the touch pen and the eraser with a computer that is connected to the video input terminal on this monitor, install the software below. • Touch Panel Settings Tool • Touch Pen Utility • Pen Software To install the software, see the manual for each.
Touch Panel / Touch Pen Preparations Touch pen actions Adding touch pens (pairing) Only use touch pens that are used with this monitor (supplied touch pens or optional PN-ZL02). • Up to 4 touch pens can be used simultaneously. (Up to 10 touch pens can be registered.) When touch pens are added, they can be used to write simultaneously, and a different color can be set for each pen. • To use an optional touch pen with the monitor, the touch pen must be registered in the touch pen adapter.
Touch action Touch action Touch actions that can be used with this monitor differ according to operating system and application. The functions of touch actions are also different. For details, check Windows Help and the application’s support documentation. Touch Operation Mode Multi-Touch Mode Mouse Mode Touch action Windows 8 / 8.1 / 10 Windows 7 Windows 7 / 8 / 8.
Touch action Drag-and-drop Same action as drag-and-drop with a mouse. Touch the screen with your finger/touch pen and move without lifting. When you have finished the movement, lift your finger/ touch pen. nFinger actions Zoom Use in a screen that is capable of enlargement/reduction. Touch the screen with two fingers and move your fingers closer together to reduce the view, or apart to enlarge the view. Flicks Flick your finger/touch pen in the direction of the function you want to use.
Touch action Rotation Use this action in a screen that is capable of image rotation. Touch the center point of the rotation with one finger. While holding that finger still, move another finger in the desired direction of rotation.
Basic Operation Using the touch menu You can touch the monitor to change input mode, volume, and other settings. 1. Press the TOUCH MENU button. TOUCH MENU button 2. Touch the screen to change settings. INPUT Direct Drawing Wireless SIDE INPUT TERMINAL D-SUB2 HDMI2 HDMI3 BOTTOM INPUT TERMINAL D-SUB1 DisplayPort HDMI1 (4) (1) (2) (3) (1) I NPUT (Input mode selection) Changes the input mode.
Basic Operation (3) Touch action setting Touch to disable touch action. Touch again to enable touch action. Using the remote control unit 1 TIPS • When the input mode is changed, the disable touch action setting is canceled. • When TOUCH OUTPUT INVALID ICON is set to ON and touch action is disabled, the TOUCH OUTPUT INVALID icon appears in the monitor. 2 5 3 4 6 9 • You can touch the TOUCH OUTPUT INVALID icon in the monitor to enable touch action.
Basic Operation 5. BRIGHT +/- (Backlight adjustment) or displays the BRIGHT menu when the Pressing menu screen is not displayed. BRIGHT 10. MODE (Color mode selection) Each time you press this button, the color mode changes in the following order: STD (Standard) → VIVID → sRGB → HIGH ILLUMINANCE → STD... 15 Press or to adjust the brightness. * If you do not press any buttons for about 4 seconds, the BRIGHT menu automatically disappears. 6. ENTER Confirms the setting. 7.
Basic Operation nSwitching the screen size Even when the screen size is changed, the display may remain the same depending on the input signal. WIDE ZOOM 1 PC input Displays image so it fills the entire screen. AV input An image with a 4:3 aspect ratio is stretched to fill the entire screen. PC input An image with a 4:3 aspect ratio is enlarged to fill the entire screen without changing the aspect ratio. The edges of the image may be cut off.
Menu Items Displaying the menu screen TIPS Video and audio adjustment and settings of various functions are enabled. This section describes how to use the menu items. See pages 30 to 37 for details of each menu items. Caution • Do not turn the main power switch off while the menu items are being displayed. Doing so may initialize the settings. • The menu will differ depending on the input mode. • The menu screen will close automatically if no operation is performed for about 15 seconds.
Menu Items Menu item details The menu will differ depending on the input mode. nSCREEN You can move the menu screen display position each time DISPLAY is pressed. AUTO (D-SUB1[RGB]/D-SUB2/Direct Drawing/Wireless) The CLOCK, PHASE, H-POS, and V-POS are automatically adjusted. ENTER Pressing performs adjustment. Use this automatic adjustment when you use the D-SUB1[RGB] or D-SUB2 to display a computer screen for the first time or when you change the setting of the computer. (See page 40.
Menu Items nPICTURE You can move the menu screen display position each time DISPLAY is pressed. BRIGHT Adjusts the backlight brightness. (In PIP mode, the main side setting is reflected in the image.) CONTRAST Adjusts the difference between the bright and dark portions of the image. BLACK LEVEL Adjusts the entire brightness of the video signals. TINT Adjusts the hue. Selecting + changes the color towards green, and selecting - changes it towards magenta. COLORS Adjusts the color intensity.
Menu Items ADVANCED AUTO (D-SUB1[RGB]/D-SUB2/Direct Drawing/Wireless) The ANALOG GAIN and ANALOG OFFSET are automatically adjusted. ENTER Pressing performs adjustment. ANALOG GAIN (D-SUB1[RGB]/D-SUB2/Direct Drawing/Wireless) Adjusts the bright portions of the video input signal. ANALOG OFFSET (D-SUB1[RGB]/D-SUB2/Direct Drawing/Wireless) Adjusts the dark portions of the video input signal. 3D-NR (AV input) Reduce the noise of playback images on video. Setting a higher level reduces more noise.
Menu Items nAUDIO TREBLE Adjusts the volume of treble-level sound. BASS Adjusts the volume of bass-level sound. BALANCE Adjusts the balance of the audio sound between right and left. RESET Resets the values of the AUDIO menu items to the factory preset values. ENTER . Select “ON” and then press nSETUP DATE/TIME SETTING to select the date and time, and press or or Set the date and time. Press Set the date in “Day/Month/Year” order. Set the time on a 24-hour basis.
Menu Items AUDIO OPTION SPEAKER SELECT Set whether to use the built-in speakers or the external speakers connected to the external speaker terminals. AUDIO OUTPUT Sets the volume of sound output from the audio output terminals. VARIABLE1......... You can adjust the volume from the speakers of this monitor and the audio output terminal simultaneously by using VOLUME. VARIABLE2......... You can adjust the volume from the audio output terminal by using VOLUME.
Menu Items nMONITOR OSD H-POSITION Adjusts the horizontal display position of menu screen. OSD V-POSITION Adjusts the vertical display position of menu screen. OPERATION MODE MODE1 ������OFF IF NO OPERATION is set to ON, and POWER SAVE MODE is set to ON. (These settings can not be changed.) MODE2 ������Will perform standard operation. OFF IF NO OPERATION is set to OFF, and POWER SAVE MODE is set to OFF. These settings can be changed.
Menu Items nPIP/PbyP PIP MODES Sets the display method. OFF �����������Displays one screen. PIP �������������Displays a sub screen inside a main screen. PbyP ����������Displays a main screen and a sub screen in a line. PbyP2 ��������Displays a main screen which measures 1280 pixels in the longest direction and a sub screen in a line. PIP SIZE Sets the size of the sub screen in PIP mode. PIP H-POS Adjusts the horizontal position of the sub screen in PIP mode.
Menu Items nOTHERS SCREEN MOTION PATTERN Residual images are reduced by moving the screen. OFF.................. SCREEN MOTION function is disabled. PATTERN1....... The whole screen moves vertically and horizontally. PATTERN2....... A black screen spreads from the bottom of the screen and then shrinks to the bottom of the screen. PATTERN3....... A black bar moves from the left end to the right end of the screen. PATTERN4.......
Menu Items nDual screen display You can display two screens simultaneously. Set this function with “PIP MODES” in the PIP/PbyP menu. PIP A sub screen is displayed inside a main screen. Main screen Sub screen PbyP Main screen Sub screen PbyP2 Main screen Sub screen A main screen and a sub screen are displayed in a line. Displays a main screen which measures 1280 pixels in the longest direction and a sub screen in a line. * The currently selected input signal is displayed on the main screen.
Menu Items nSCHEDULE Caution You can set the time to switch the monitor on and off. Set this function with SCHEDULE in the SETUP menu. (See page 33.) D-SUB1[RGB] SCHEDULE (2) No.
Menu Items Adjustments for PC screen display nAutomatic adjustment When you use D-SUB1 or D-SUB2 to display a computer screen for the first time, or when you change the setting of the computer, use the automatic screen adjustment. 1. Switch the input to D-SUB1 or to D-SUB2 and display the adjustment pattern. (See the description below.) MENU 2. Press and use or to display the SCREEN menu. 3. Press ENTER and select “AUTO”. ENTER . 4. Press The automatic adjustment is complete in several seconds. 5.
Initialization (Reset)/Functional Restriction Setting (FUNCTION) You can return the settings to their factory-preset values and restrict operations. SIZE down until “F” appears in the upper left 1. Hold corner of the screen. , , , in that 2. While “F” appears, press order.
Controlling the Monitor with a PC (RS-232C) You can control this monitor from a PC via RS-232C (COM port) on the PC. TIPS • To control the monitor via RS-232C, set RS-232C/LAN SELECT to RS-232C. • When POWER SAVE MODE is set to ON, control is not possible in standby mode. • You cannot use RS-232C and LAN control simultaneously. PC connection Connect the RS-232C conversion cable (supplied) to the RS232C input terminal on the monitor.
Controlling the Monitor with a PC (RS-232C) nResponse code format When a command has been executed correctly O K Return code (0DH, 0AH) A response is returned after a command is executed. When a command has not been executed E R R nCommunication interval • After OK or ERR is returned, you must send the following commands. To set a timeout for the command response, specify 10 seconds or longer.
Controlling the Monitor with a PC (RS-232C) Setting of the GAMMA user data nTo transfer the GAMMA user data Use the user data transfer commands (UGRW, UGGW and UGBW). For each of the R, G and B colors, divide the total 512 pieces of user data into 16 blocks, and transfer 32 pieces of data with each command.
Controlling the Monitor with a PC (RS-232C) RS-232C command table How to read the command table Command: Command field (See page 42.) Direction: W When the “Parameter” is set in the parameter field (see page 42), the command functions as described under “Control/Response Contents”. R The returned value indicated under “Reply” can be obtained by setting “????” or “ ?” in the parameter field (see page 42). Parameter: Parameter field (See page 42.
Controlling the Monitor with a PC (RS-232C) SCREEN menu Command Direction Auto Function ASNC W CLOCK CLCK WR PHASE positioning size RESOLUTION Parameter Reply Control/Response contents 1 When the input mode is D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless. 0-1200 0-1200 When the input mode is D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless. Varies depending on the signal.
Controlling the Monitor with a PC (RS-232C) ADVANCED Function Command Direction AUTO AGIN W ANALOG GAIN ANGA Parameter Reply Control/Response contents 1 When the input mode is D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless. WR 0-127 0-127 When the input mode is D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless. 0-127 When the input mode is D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless.
Controlling the Monitor with a PC (RS-232C) SETUP menu Command Direction Date/time setting Function DATE WR DATE DISPLAY FORMAT DTFT WR TIME DISPLAY FORMAT TMFT WR 0-1 SCHEDULE SC01SC08 WR ABCDEFFGGH SCHEDULE BRIGHTNESS SB01SB08 WR 0-31 LANG WR LANGUAGE Parameter Reply AABBCCDDEE 0-2 INPUT MODE NAME Edit the input mode name AUDIO SELECT AUDIO OPTION TOUCH INPUT SELECT HDMI1 0-1 0: 24-HOUR TIME, 1: 12-HOUR TIME ABCDEFFGGH 48 Schedule of a specified number A: Schedule 0= Not
Controlling the Monitor with a PC (RS-232C) Function COMMUNICATION SETTING Command Direction RS-232C/LAN SELECT CTLS WR Parameter 0-1 Reply 0-1 0: RS-232C 1: LAN Control/Response contents BAUD RATE BAUD WR 0-2 0-2 0: 9600bps, 1: 19200bps, 2: 38400bps * ○ WIRELESS FUNCTION WLFC WR 0-1 0-1 0: OFF 1: ON - CONNECT AUTO INPUT SELECT AICW WR 0-1 0-1 0: OFF 1: ON ○ REGION SETTING (WIRELESS) WLRG WR 0-11, 14-21 0-11, 14-21 0: NO SETTING, 1: EUROPE, 2: AUSTRALIA, 3: NEW ZEALAND, 4:
Controlling the Monitor with a PC (RS-232C) OTHERS menu Function Command Direction PATTERN SCSV WR MOTION TIME1 MTIM WR 0-20 MOTION TIME2 (PATTERN1) MINT WR 10-990 MOTION TIME2 (PATTERN2-4) MINT WR 5-20 POWER MANAGEMENT (PC) PMNG WR 0-1 0-1 0: OFF, 1: ON POWER MANAGEMENT (AV) PMAV WR 0-1 0-1 0: OFF, 1: ON CONNECT AUTO INPUT SELECT AICO WR 0-1 0-1 0: OFF, 1: ON NO SIGNAL AUTO INPUT SEL.
Controlling the Monitor with a PC (RS-232C) Initialization/Functional Restriction Setting (FUNCTION) menu Command Direction ALL RESET Function RSET W Parameter 0-1 Reply Control/Response contents ADJUSTMENT LOCK ALCK WR 0-2 0-2 0: OFF, 1:ON1, 2:ON2 When POWER SAVE MODE is set to ON, ON2 cannot be selected (ERR). ADJUSTMENT LOCK TARGET ALTG WR 0-2 0-2 0: REMOTE CONTROL, 1: MONITOR BUTTONS, 2: BOTH “ERR” when OFF is selected for ADJUSTMENT LOCK.
Controlling the Monitor with a PC (RS-232C) Commands for setting of the GAMMA user data Function E Command Direction RED GAMMA DATA TRANSFER UGRW W GREEN GAMMA DATA TRANSFER UGGW W BLUE GAMMA DATA TRANSFER UGBW W Parameter Reply aaxxxx ··· xxxxcc (xxxx: 32 pieces) aa: 01-16 xxxx: 0000-1023 cc: 00-FF RED GAMMA DATA READ UGRR W GREEN GAMMA DATA READ UGGR W BLUE GAMMA DATA READ UGBR W USER DATA INITIALIZE UGRS W 0 Initialize the user data.
Controlling the Monitor with a computer (LAN) Your monitor can be connected to a LAN allowing you to control it from a computer on the LAN. You can also configure the monitor to send e-mail notification when it has a problem. The connection requires a commercially available LAN cable (UTP cable, Category 5, straight through). Network (LAN) Settings to connect to a LAN Set the monitor’s IP address and subnet mask to match the settings of your LAN.
Controlling the Monitor with a computer (LAN) ■ To set from a computer When the monitor is connected to a computer, LAN settings can be configured via computer. Set up process (1) Connect your monitor to a computer (2) Specify the computer’s IP address (3) Configure the monitor’s LAN settings 7. Temporarily change the IP address and subnet mask. To access the monitor as it is shipped from the factory, set as follows. • IP Address: 192.168.150.1 • Subnet Mask: 255.255.255.
Controlling the Monitor with a computer (LAN) 5. Click on “LAN SETUP” under NETWORK. Controlling with a computer TIPS • For security, set a USER NAME and PASSWORD. ■ Basic operation You use the web browser on a computer on the LAN to control the monitor. 1. Launch the web browser on the computer. 2. In the “Address” box, type “http://” followed by your monitor’s IP address followed by “/”, then press the Enter key. You can confirm the IP address with the DISPLAY function. 6.
Controlling the Monitor with a computer (LAN) ■ INFORMATION Information about this monitor appears. ■ ADJUSTMENT You can adjust these settings which are also available on the monitor’s menu. • SCREEN (See page 30.) • PICTURE (See pages 31 to 32.) • AUDIO (See page 33.) • SETUP (See pages 33 to 34.) • MONITOR (See page 35.) • SCHEDULE (See page 39.) • PIP/PbyP (See page 36.) • OTHERS (See page 37.) • FUNCTION (See page 41.
Controlling the Monitor with a computer (LAN) ■ NETWORK (LAN SETUP) This screen allows you to set the settings necessary when the monitor is connected to a LAN. DHCP CLIENT If your LAN has a DHCP server and you wish to obtain an address automatically, change this setting to ON. To set the address manually, set this to OFF. IP ADDRESS If the DHCP CLIENT is set to OFF, specify an IP address. SUBNET MASK If the DHCP CLIENT is set to OFF, specify the subnet mask.
Controlling the Monitor with a computer (LAN) ■ NETWORK (GENERAL) This screen allows you to specify the general LAN settings. MONITOR NAME Specify a name for this monitor as it should appear on the web browser screen. AUTO LOGOUT TIME Specify the time (in minutes) to elapse before automatically disconnecting this monitor from the network. Specify in minutes from 1 to 65535. A value of ‘0’ will disable this function. DATA PORT Specify the TCP port number to use for exchanging data with the monitor.
Controlling the Monitor with a computer (LAN) ■ MAIL (RECIPIENT) This screen allows you to specify the recipients of the e-mail sent periodically or when the monitor has an error. RECIPIENT E-MAIL ADDRESSES Specify the e-mail addresses to send error notification e-mail to. CONDITION Specify the conditions to send mails. When you check PERIODICAL, specify the date and time to send the mails in the PERIODICAL setting. CONFIRMATION Sends test e-mail.
Controlling the Monitor with a computer (LAN) ■ SNMP You can configure settings related to SNMP. Caution • After you set SNMP, click [Switch the main power of monitor off and on now.] or turn off the monitor and then turn it on again with the main power switch. When the monitor restarts, wait about 30 seconds and then start the next operation. • If the IP address is changed while the SNMP function is operational, turn off the monitor and then turn it on again with the main power switch.
Controlling the Monitor with a computer (LAN) [Advanced operation] Command-based control You can control the monitor using RS-232C commands (see page 45) via terminal software and other appropriate applications. In order to use this function, enable a connection to the monitor through the web browser. Read the manual for the terminal software for detailed instructions. (1) Connect the computer to the monitor. 1. Specify the IP address and data port number and connect the computer to the monitor.
Troubleshooting If you are experiencing any problem with your display, before calling for service, please review the following troubleshooting tips. There is no picture or sound. • Is the power cord disconnected? (See page 14.) • Is the main power switch off? (See page 18.) • Is the monitor in standby mode (the power LED illuminating in orange)? (See page 18.) • Make sure correct input mode is selected. (See pages 25, 26.
Troubleshooting The monitor makes a cracking sound. • You may occasionally hear a cracking sound from the monitor. This happens when the cabinet slightly expands and contracts according to change in temperature. This does not affect the monitor’s performance. The Power LED is flashing in red and green alternately. When “TEMPERATURE” is displayed in the corner of the screen.
Specifications nProduct Specifications Model LCD component PN-70TW3 PN-60TW3 70" Class [69-1/2 inch (176.6cm) 60" Class [60-1/16 inch (152.5cm) diagonal] TFT LCD diagonal] TFT LCD Max. resolution (pixels) 1920 x 1080 Max. colors Approx. 1.06 billion colors Pixel pitch 0.802 mm (H) × 0.802 mm (V) 0.692 mm (H) × 0.692 mm (V) 2 1 Max.
Specifications nDimensional Drawings Note that the values shown are approximate values.
Specifications nPower management This monitor conforms to VESA DPMS. Both your video card and computer must support the same standard in order for the monitor’s power management function to work. DPMS: Display Power Management Signaling Power Hsync consumption*1 DPMS Screen ON STATE Display 235 W 190 W Yes Yes No display 25.0 W *2 25.0 W *2 No Yes Yes No No No STANDBY SUSPEND OFF STATE Vsync *1 Upper value: PN-70TW3, Lower value: PN-60TW3.
Specifications nCompatible signal timing (AV) Screen resolution 1920 × 1080p 1920 × 1080i 1280 × 720p 720 × 576p 720 × 480p 640 × 480p(VGA) 720(1440) × 576i 720(1440) × 480i Frequency 24Hz 50Hz 59.94Hz 60Hz 50Hz 59.94Hz 60Hz 50Hz 59.94Hz 60Hz 50Hz 59.94Hz 60Hz 59.94Hz 60Hz 50Hz 59.
Specifications nD-sub input terminal (Mini D-sub 15 pin) No. Function Function Red video signal input 9 +5V 2 Green video signal input 10 GND 3 Blue video signal input 11 N.C. 4 N.C. 12 DDC data 5 GND 13 Hsync signal input 6 GND for red video signal 14 Vsync signal input 7 GND for green video signal 15 8 GND for blue video signal No. 68 No. 1 nHDMI input terminal (HDMITM Connector) E nDisplayPort input (DisplayPort 20 pin) pins Function DDC clock pins No.
Mounting Precautions (For SHARP dealers and service engineers) • When installing, removing or moving the monitor, ensure that this is carried out by at least 4 people. (PN-60TW3: at least 3 people.) • Be sure to use a wall-mount bracket designed or designated for mounting the monitor. • This monitor is designed to be installed on a concrete wall or pillar. Reinforced work might be necessary for some materials such as plaster / thin plastic board / wood before starting installation.
