PN-C805B PN-C705B LCD MONITOR OPERATION MANUAL
IMPORTANT: To aid reporting in case of loss or theft, please record the product’s model and serial numbers in the space provided. The numbers are located in the rear of the product. Model No.: Serial No.: U.S.A.
IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
DEAR SHARP CUSTOMER Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of trouble-free operation of your product, please read the Safety Precautions carefully before using this product. SAFETY PRECAUTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety.
SAFETY PRECAUTIONS (Continued) 19. Batteries — Incorrect use of batteries may cause the batteries to burst or ignite. A leaky battery may corrode the equipment, dirty your hands or spoil your clothing. In order to avoid these problems, make sure to observe the precautions below: • Use the specified batteries only. • Install the batteries with due attention to the plus (+) and minus (-) sides of the batteries according to the instructions in the compartment. • Do not mix old and new batteries.
IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
TIPS AND SAFETY INSTRUCTIONS -T he TFT color LCD panel used in this monitor is made with the application of high precision technology. However, there may be minute points on the screen where pixels never light or are permanently lit. Also, if the screen is viewed from an acute angle there may be uneven colors or brightness. Please note that these are not malfunctions but common phenomena of LCDs and will not affect the performance of the monitor.
MOUNTING PRECAUTIONS • This product is for use indoors. • A mounting bracket compliant with VESA specifications is required. • Since the monitor is heavy, consult your dealer before installing, removing or moving the monitor. • Mounting the monitor on the wall requires special expertise and the work must be performed by an authorized SHARP dealer. You should never attempt to perform any of this work yourself.
Contents IMPORTANT INFORMATION.............................................3 DEAR SHARP CUSTOMER...............................................4 SAFETY PRECAUTIONS...................................................4 IMPORTANT SAFETY INSTRUCTIONS............................6 TIPS AND SAFETY INSTRUCTIONS................................7 MOUNTING PRECAUTIONS.............................................8 Supplied Components....................................................10 System Requirements...............
Supplied Components If any component should be missing, please contact your dealer.
Part Names nFront view 11 11 11 11 10 1. 2. 3. 4. 5. 6. 12 1 10 Remote control sensor (See page 16.) Power LED (See page 18.) POWER button (See page 18.) HDMI1 button (See page 23.) D-SUB button (See page 23.) INPUT button (See page 23.) 7. 8. 9. 10. 11. 12. 2 POWER HDMI 1 D-SUB INPUT BL OFF 3 4 5 6 7 VOL ─ VOL + 8 FREEZE 9 Backlight OFF button (See page 23.) VOLUME +/- (Volume adjustment) buttons (See page 22.) FREEZE button (See page 22.
Part Names Remote control unit n 1 2 E 12 1. Signal transmitter 2. Operation buttons (See pages 22 and 23.
Connecting Peripheral Equipment 10 4 5 1 2 8 7 Caution • Be sure to turn off the main power switch and disconnect the plug from the power outlet before connecting/ disconnecting cables. Also, read the manual of the equipment to be connected. • Be careful not to confuse the input terminal with the output terminal when connecting cables. Accidentally reversing cables connected to the input and output terminals may cause malfunctions and the other problems.
Connecting the Power Cord Caution • Use only the power cord supplied with the monitor. • When all connections are complete, connect the power cord. 1. Turn off the main power switch. 2. Plug the power cord (supplied) into the AC input terminal. 3. Plug the power cord (supplied) into the AC power outlet.
Binding Cables The cables connected to the terminals on the rear of the monitor can be fastened with the supplied cable clamp. PN-C705B PN-C805B *1 *1 *1 *1 *2 *1 *2 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *2 Cable clamp (for power cord) Cable clamp Cable clamp attachment Cable Cable clamp attachment Cable Affixing the Stand Hole Protection Covers After installing the monitor, affix the stand hole protection covers. 1. Peel off the backing sheet and affix the cover on the monitor.
Preparing the Remote Control Unit Installing the batteries Remote control operation range 1. Place your finger on the part marked with the ▲, and then pull the cover off. The operation range of the remote control unit is approx. 16.4 feet (5 m) at an angle of approx 10° from the center to the top/ bottom/right/left of the remote control sensor. 2. See the instructions in the compartment and put in the batteries (R‑03 (“AAA” size) x 2) with their plus (+) and minus (-) sides oriented correctly. 3.
Removing the Handles The handles can be removed. Handle Handle screws Caution • The removable handles and handle screws are for use with this monitor. Do not use them for any other devices. • To attach handles, be sure to use the handles and handle screws which were removed from this monitor. • Be sure the handles are attached securely.
Turning Power On/Off Caution • When all connections are complete, turn on the power. • Turn on the monitor first before turning on the computer or playback device. • When switching the main power switch or the POWER button off and back on, always wait for at least 5 seconds. A short interval may result in a malfunction. Turning power on/off Press the remote control POWER button or the monitor POWER button to turn the power ON/OFF.
Touch action Touch action Touch actions that can be used with this monitor differ according to operating system and application. The functions of touch actions are also different. For details, check Windows or Mac Help and the application’s support documentation. OS Windows 8.
Touch action Drag-and-drop Same action as drag-and-drop with a mouse. Touch the screen with your finger/touch pen and move without lifting. When you have finished the movement, lift your finger/ touch pen. nFinger actions Zoom Use in a screen that is capable of enlargement/reduction. Touch the screen with two fingers and move your fingers closer together to reduce the view, or apart to enlarge the view. Flicks Flick your finger/touch pen in the direction of the function you want to use.
Touch action Rotate Use this action in a screen that is capable of image rotation. Touch the center point of the rotation with one finger. While holding that finger still, move another finger in the desired direction of rotation.
Basic Operation Using the buttons on the remote control unit and monitor Remote control unit 11 12 13 1 5. VOLUME +/- (Volume adjustment) When the menu does not appear, press + or - to display the volume menu and adjust the volume. * If you do not press any buttons for about 3 seconds, the VOLUME menu automatically disappears. 6. INFORMATION You can check the input signal and input terminal. • The display automatically disappears after about 5 seconds. 7. FUNCTION Use this to display the FUNCTION menu.
Basic Operation 16. BRIGHT +/- (Brightness adjustment) When the menu does not appear, press + or - to display the brightness menu and adjust the brightness. * If you do not press any buttons for about 3 seconds, the brightness menu automatically disappears. 17. INPUT (Input mode selection) The menu is displayed. Press or buttons to select the input mode, and press ENTER button to enter. * You can select the input mode by pressing the input button.
Basic Operation nSwitching the screen size Even when the screen size is changed, the display may remain the same depending on the input signal. INPUT SIGNAL WIDE *1 UNDERSCAN Dot by Dot NORMAL 16:9 video 1920×1080, 1280×720 etc. Displays image so it fills the entire screen. Displays the video according to the input signal. Display to the edge of the input signal is possible.
Menu Items Displaying the menu screen Video and audio adjustment and settings of various functions are enabled. This section describes how to use the menu items. See pages 26 to 28 for details of each menu items. TIPS • The menu will differ depending on the input mode. Caution • Do not turn the main power switch off while the menu items are being displayed. Doing so may initialize the settings. nExample of operation (Adjusting CONTRAST in the PICTURE menu) 1.
Menu Items Menu item details The menu will differ depending on the input mode. ■ PICTURE PICTURE MODE Video and audio settings can be changed to match the scene, such as a movie or computer monitor image. PC ���������������������������� Configure the settings for use with a computer. DYNAMIC ����������������� Increase the contrast for action video such as sports. DYNAMIC (FIXED) ��� This provides a clearer image than DYNAMIC. When this is selected, the settings cannot be changed.
Menu Items ■ AUDIO AUDIO SETTINGS Set by the currently selected picture mode. TREBLE Adjusts the volume of treble-level sound. BASS Adjusts the volume of bass-level sound. BALANCE Adjusts the balance of the audio sound between right and left. RESET Resets the values of the AUDIO menu items of the currently selected picture mode to the factory default settings. ■ ECOLOGY POWER SAVE MODE When OFF is selected, startup time from standby mode is reduced.
Menu Items ■ OTHERS AUDIO OUTPUT For audio output that allows volume adjustment, select the internal speakers or the audio output terminal. FIXED �������������You can adjust the volume of the speakers. The volume of the audio output terminal is fixed and cannot be adjusted. VARIABLE �������The speaker volume is muted and the volume of the audio output terminal can be adjusted. INPUT SELECT (INPUT4) When INPUT4 input is selected, set AV component input or AV video input.
Menu Items Adjustments for PC screen display nAutomatic adjustment When you use D-SUB (PC) (INPUT5) to display a computer screen for the first time, or when you change the setting of the computer, use the automatic screen adjustment. 1. Switch the input to D-SUB (PC) and display the adjustment pattern. (See the description below.) 2. Press MENU button and use or button to display the OTHERS menu. 3. Press or button to select SCREEN, and press ENTER button. 4. Press or button to select AUTO SYNC.. 5.
Functional Restriction Setting (FUNCTION) You can restrict operations. 1. Press the FUNCTION button and then press the MENU button within 10 seconds. FUNCTION POWER BUTTON LOCK RC LOCK MONITOR LOCK MENU LOCK EXECUTE 2. Press or [OFF [OFF [OFF [OFF ] ] ] ] button to select and set the items. POWER BUTTON LOCK You can disable the remote control POWER button or the monitor POWER button. OFF ����������������������� Enables operation.
Controlling the Monitor with a PC (RS-232C) You can control this monitor from a PC via RS-232C (COM port) on the PC. The current value can be returned by using “????” as the parameter. Example: PC connection Connect with RS-232 straight cable between the PC’s COM port (RS-232C connector) and the RS-232C input terminal on the monitor. VOLM ? ? ? ? ← From PC to monitor (How much is current volume setting?). 30 ← From monitor to PC (Current volume setting: 30).
Controlling the Monitor with a PC (RS-232C) RS-232C command table How to read the command table Command: Command field (See page 31.) Parameter: Parameter field (See page 31.) *: Enter the number in brackets in the settings : Enter a space TIPS • In the standby mode, the only command that is used is POWER CONTROL. The operation of commands not indicated in the table below is not guaranteed. Function POWER CONTROL Command Parameter Settings P O W R 0 Switches to standby mode.
Troubleshooting If you are experiencing any problem with your display, before calling for service, please review the following troubleshooting tips. There is no picture or sound. • Is the power cord disconnected? (See page 14.) • Is the main power switch off? (See page 18.) • Make sure correct input mode is selected. (See page 23.) • If any external equipment is connected, make sure the equipment is operating (playing back). Remote control does not work.
Troubleshooting The Power LED lights blue and orange alternately. (At intervals of 1 second.) When “TEMPERATURE” is displayed in the corner of the screen. • To prevent high-temperature-related problems, “TEMPERATURE” is displayed on the screen when the internal temperature of the monitor rises excessively. • If the internal temperature rises further, the monitor automatically enters standby mode. The Power LED lights blue and orange alternately. (At intervals of 1 second.
Specifications nProduct Specifications PN-C705B PN-C805B 80" Class [80 inch (203.2cm) 70" Class [69-1/2 inch (176.6cm) diagonal] TFT LCD diagonal] TFT LCD Max. resolution (pixels) 1920 x 1080 Max. colors Approx. 1.07 billion colors*1 Pixel pitch 0.923 mm (H) × 0.923 mm (V) 0.802 mm (H) × 0.802 mm (V) 2 2 350 cd/m Max.
Specifications nDimensional Drawings Note that the values shown are approximate values.
Specifications nDDC (plug and play) The monitor supports the VESA DDC (Display Data Channel) standard. DDC is a signal standard for plug and play between monitors and computers. Information about resolution and other parameters is exchanged between the two. This function can be used if the computer supports DDC and it has been configured to detect plug-and-play monitors. There are several types of DDC, depending on the communication method used. This monitor supports DDC2B.
Specifications nCompatible signal timing (AV) Screen resolution 1920 × 1080p 1920 × 1080i 1280 × 720p 720 × 576p 720 × 480p 640 × 480p(VGA) 720(1440) × 576i 720(1440) × 480i Frequency 24Hz 50Hz 59.94Hz 60Hz 50Hz 59.94Hz 60Hz 50Hz 59.94Hz 60Hz 50Hz 59.94Hz 60Hz 59.94Hz 60Hz 50Hz 59.
Specifications nD-sub input terminal (Mini D-sub 15 pin) No. Function nHDMI input terminal (HDMITM Connector) pins No. Function No. Function pins No. Function 1 Red video signal input 9 +5V 1 TMDS data 2+ 11 TMDS clock shield 2 Green video signal input 10 GND 2 TMDS data 2 shield 12 TMDS clock- 3 Blue video signal input 11 N.C. 3 TMDS data 2- 13 CEC 4 N.C. 12 DDC data 4 TMDS data 1+ 14 N.C.
Mounting Precautions (For SHARP dealers and service engineers) • When installing, removing or moving the monitor, ensure that this is carried out by at least 4 people. (PN-C705B: at least 3 people.) • Be sure to use a wall-mount bracket designed or designated for mounting the monitor. • This monitor is designed to be installed on a concrete wall or pillar. Reinforced work might be necessary for some materials such as plaster / thin plastic board / wood before starting installation.
PN-C805B-C705B M EN16L(1)
