DC2C1BZ001 User’s Manual << DOC NO.EU-01Z05A DESCRIPTION >> This user’s manual covers the Sharp BluetoothTM CF Card model DC2C1BZ001 intended for design application use with PDAs, Notebook PCs, mobile phones, digital cameras or PC peripherals. (Source: Bluetooth V.1.1 Radio specification Part A) Ref no. of QPN : 010-7LI_1 *QPN : Qualification Product Notice This device complies with Part 15 of the FCC Rules.
DC2C1BZ001 User’s Manual 1. INSTALL a) Insert CF card to CF card slot or PC card slot with CF card Adapter card. b) PC detect CF card and pop up the window. Push Next button. c) Select “Display a list of all …..” and push Next button. 3 DOC NO.
DC2C1BZ001 User’s Manual d) Select “Ports[COM & LPT]” and push Next button. e) Select “Communication Point” and push Next button. f) Pop up the warning window, push Yes button. 4 DOC NO.
DC2C1BZ001 User’s Manual g) Push Next button. h) Push Finish button. 5 DOC NO.
DC2C1BZ001 User’s Manual 2. HOW TO USE BLUETOOTH This Bluetooth Card has under HCI protocol. You can use the HCI command through the COM port There is Bluetooth specification on http://www.bluetooth.com/ 3.
DC2C1BZ001 User’s Manual 4. DIMENSION AND MOUNTING DETAILS DRAFT 7 DOC NO.
