MICRO COMPONENT SYSTEM MIKROWIEŻA MIKROSYSTÉM MODEL MODEL MODEL XL-E15H OPERATION MANUAL INSTRUKCJA OBSŁUGI NÁVOD NA POUŽITÍ Downloaded From Disc-Player.
ENG - SPECIAL NOTES When the ON/STAND-BY button is set at STAND-BY position, mains voltage is still present inside the unit. When the ON/STAND-BY button is set at STAND-BY position, the unit may be brought into operation by the timer mode or remote control. Warning: This unit contains no user serviceable parts. Never remove covers unless qualified to do so. This unit contains dangerous voltages, always remove mains plug from the socket before any service operation and when not in use for a long period.
GR - ΕΙΔΙΚΕΣ ΣΗΜΕΙΩΣΕΙΣ LT - SPECIALIOS PASTABOS Όταν το πλήκτρο ON/STAND-BY βρίσκεται στη θέση STAND-BY, τα τμήματα στο εσωτερικό της συσκευής είναι ακόμα υπό τάση. Όταν το πλήκτρο ON/STAND-BY είναι στη θέση STAND-BY, η συσκευή μπορεί να ξεκινήσει να λειτουργεί από το χρονοδιακόπτη ή το τηλεχειριστήριο. Προειδοποίηση: Η συσκευή δεν περιέχει εξαρτήματα που μπορούν να συντηρηθούν από το χρήστη. Μην αφαιρείτε ποτέ το κάλυμμα εκτός αν έχετε τα απαραίτητα προσόντα. Η συσκευή περιέχει επικίνδυνες τάσεις.
ENG - INFORMATION ON PROPER DISPOSAL A. Information on Disposal for Users private households) 1. In the European Union Attention: If you want to dispose of this equipment, please do not use the ordinary dustbin! Used electrical and electronic equipment must be treated separately and in accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic equipment.
CZ - INFORMACE O LIKVIDACI POUŽITÉHO VYBAVENÍ A. Informace o likvidaci pro uživatele (domácnosti) 1. V zemích Evropské unie UpozornČní: Toto zaĜízení nelikvidujte v bČžných odpadkových koších! Použíté elektické a elektronické vybavení je tĜeba likvidovat samostatnČ a v souladu s legislativou, která vyžaduje Ĝádnou likvidaci, obnovení a recyklaci použitého elektického a elektronického vybavení.
RO - INFORMAğII DESPRE RECICLAREA SAU DISTRUGEREA ADECVATĂ A. InformaĠii despre dispunerea deúeurilor pentru Utilizatori (gospodării particulare) 1. În Uniunea Europeană AtenĠie: Dacă doriĠi să aruncaĠi acest echipament, nu utilizaĠi un container obiúnuit pentru gunoi! Produsele electrice úi electronice uzate trebuie tratate separat úi conform legilor în vigoare care cer un tratament special, recuperarea úi reciclarea echipamentului electric úi electronic uzat.
HU - TÁJÉKOZTATÓ A MEGFELELė ÁRTALMATLANÍTÁSRÓL A. Hulladék-elhelyezési tájékoztató felhasználók részére (magán háztartások) 1. Az Európai Unióban Figyelem: Ha a készüléket ki akarja selejtezni, kérjük, ne a közönséges szemeteskukát használja! A használt elektromos és elektronikus berendezéseket külön, és a használt elektromos és elektronikus berendezések szabályszerĦ kezelésérĘl, visszanyerésérĘl és újrahasznosításáról rendelkezĘ jogszabályokkal összhangban kell kezelni.
ENGLISH XL-E15H Micro Component System consisting of XL-E15H (main unit) and CP-E15H (speaker system). Introduction Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product.
Precautions General z Please ensure that the equipment is positioned in a wellventilated area and ensure that there is at least 10 cm (4") of free space along the sides, top and back of the equipment. 10 cm (4") 10 cm (4") z Do not remove the outer cover, as this may result in electric shock. Refer internal service to your local SHARP service facility.
Controls and indicators (continued) 1 2 3 4 5 Display Reference page 1. AM Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 2. FM Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 3. FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . 12 4. Timer Play Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 5. Memory Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10, 12 6.
System connections Make sure to unplug the AC power lead before making any connections. Aerial connection (see page 4) AM loop aerial Right speaker Speaker connection (see page 5) FM aerial Left speaker AC power connection (see page 5) Wall socket (AC 220 - 240 V ~ 50/60 Hz) Downloaded From Disc-Player.
Remote control System connections (continued) Speaker connection Connect the black wire to the minus (–) terminal, and the red wire to the plus (+) terminal. Red Using antislip speaker cushions You can install the speakers either vertically or horizontally. Affix the cushions (supplied) to the bottom of the speakers to prevent them from sliding or falling due to vibration. (Vertical position) Downloaded From Disc-Player.com Sharp Manuals 1 Open the battery cover.
General control ON/ STAND-BY Extra bass control (X-BASS) MICRO COMPONENT SYSTEM XL-E15 ON/ STAND-BY REMOTE SENSOR FUNCTION When the X-BASS button is pressed, the unit will enter the extra bass mode which emphasises the bass frequencies and “X-BASS ON” will appear. To cancel the extra bass mode, press the X-BASS button until “X-BASS OFF” appear.
Setting the clock Listening to a CD or MP3/WMA disc ON/ STAND-BY MICRO COMPONENT SYSTEM XL-E15 This system can play back a standard CD, CD-R/RW in the CD format and CD-R/RW with MP3 or WMA files, but cannot record on them. Some audio CD-R and CD-RW discs may not be playable due to the state of the disc or the device that was used for recording.
Listening to a CD or MP3/WMA disc (continued) ON/ STAND-BY To fast reverse audibly: During playback, press and hold down the the button to resume playback. MICRO COMPONENT SYSTEM XL-MP15 ON/ STAND-BY To stop playback: Press the (CD ) button. REMOTE SENSOR FUNCTION Caution: z Do not play discs of special shapes (heart, octagon, etc.). It may cause malfunctions. z If a disc is damaged, dirty, or loaded upside down, “NO DISC” will appear on the display. z Keep foreign objects out of the disc compartment.
Advanced CD or MP3/WMA disc playback Direct track search (REMOTE CONTROL ONLY) In case of a MP3/WMA disc mode: “NORMAL” The normal playback. By using the Direct Search buttons, the desired tracks on the current disc can be played. “RPT ONE” Repeat the current playing track. Use the Direct Search buttons on the remote control to select the desired track whilst playing or in the stop mode. “RPT FLD” Repeat the current playing folder. “RPT ALL” Repeat the current playing disc.
Advanced CD or MP3/WMA disc playback (continued) Programmed play 1 Whilst in the stop mode, press the MEMORY/DISP button to enter the programming save mode. 2 Press the tracks. 3 or Programmed play (Folder mode) 1 Whilst in the stop mode, press the MEMORY/DISP button to enter the programming save mode. "MEM" icon light up to indicate programming save mode. 2 Press the TUNING/FOLDER ( or control to select the desired folder.
MP3/WMA folder mode (only for MP3/WMA files) To play back MP3/WMA (Windows Media Audio) file There are many music sites on the internet that you can download MP3/WMA (Windows Media Audio) music files. Follow the instructions from the website on how to download from the music files. You can then play back these downloaded music files by burning them to a CD-R/RW disc. z Your downloaded song/files are for personal use only. Any other usage of the song without owner’s permission, is against the law.
Listening to the radio ON/ STAND-BY MICRO COMPONENT SYSTEM XL-E15 ON/ STAND-BY REMOTE SENSOR FUNCTION You can store 40 FM and AM stations in memory and recall them at the push of a button (PRESET ( or )). 1 Perform steps 1 - 3 in “Tuning” on page 12. 2 Press the MEMORY/DISP button to enter the preset tuning saving mode. 3 Within 5 seconds, press the PRESET ( the channel to be preset. 4 Press the MEMORY/DISP button. In this example, “103.25 MHz” FM station is preset on FM channel 9.
Timer and sleep operation XL-E15 PRESET AUDIO IN 10 To select CD, press the / the CLOCK/TIMER button. (CD / ) button and then press 11 To select TUNER, press the TUNER (BAND) button and then press the CLOCK/TIMER button. Timer playback Before setting timer: 1 Check that the clock is set to the correct time (refer to page 7). If it is not set, you cannot use the timer function. 2 For timer playback, load the disc to be played back. 1 Press the ON/STAND-BY button to turn the power on.
Timer and sleep operation (continued) Sleep operation Enhancing your system The connection lead is not included. Purchase a commercially available lead as shown below. The radio, compact disc and audio in mode can all be turned off automatically. 1 Play back the desired sound source. 2 Press the SLEEP button repeatedly to select the time. (Maximum: 90 minutes - Minimum: 10 minutes) Portable audio player, etc.
Troubleshooting chart Many potential problems can be resolved by the owner without calling a service technician. If something is wrong with this product, check the following before calling your authorised SHARP dealer or service centre. General Symptom Possible cause z The clock is not set to the correct time. z Did a power failure occur? Reset the clock. (Refer page 7) z When a button is pressed, the unit does not respond. z Set the unit to the power standby mode and then turn it back on.
Maintenance Specifications Cleaning the cabinet Periodically wipe the cabinet with a soft cloth and a diluted soap solution, then with a dry cloth. Caution: z Do not use chemicals for cleaning (petrol, paint thinner, etc.). It may damage the cabinet finish. z Do not apply oil to the inside of the unit. It may cause malfunctions. Cleaning the CD pickup lens Do not touch the laser pickup lens. If finger prints or dust accumulate on the pickup, clean it gently with a dry cotton swab.
Downloaded From Disc-Player.
