HI FI-KOMPONENTEN-SYSTEM SYSTÈME HI FI SISTEMA HI FI COMPONENTE HI FI KOMPONENT SYSTEM HI FI SISTEMA HI FI SYSTEEM SISTEMA DE COMPONENTE HI FI HI FI-KOMPONENTTIJÄRJESTELMÄ ZESTAW HI-FI HI-FI SYSTÉM HI FI KOMPONENTŲ SISTEMA HI FI COMPONENT SYSTEM BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUAL DE MANEJO BRUKSANVISNING MODELL MODÈLE MODELO MODELL MODELLO MODEL MODELO MALLI MODEL MODEL MODELIS MODEL XL-HF202PH(S) XL-HF202PH(BK) XL-HF302PH(T) MANUALE DI ISTRUZIONI GEBRUIKSAANWIJZING MANUAL DE OPERAÇÃO KÄYTTÖOHJE
BESONDERE ANMERKUNGEN REMARQUES SPÉCIALES NOTAS ESPECIALES SÄRSKILDA ANMÄRKNINGAR NOTE PARTICOLARI BIJZONDERE OPMERKINGEN NOTAS ESPECIAIS ERITYISHUOMAUTUS WAŻNE INFORMACJE SPECIÁLNÍ POZNÁMKY SPECIALIOS PASTABOS SPECIAL NOTES ● SHARP Electronics vakuuttaa täten että SHARP Hi Fikomponenttijärjestelmä XL-HF202PH(S)/XL-HF202PH(BK)/XLHF302PH(T) tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Vakuutus on nähtävissä osoitteessa: http://www.
● När ON/STAND-BY knappen är i läge STAND-BY, finns nätspänning i apparaten. Med ON/STAND-BY knappen i läge STAND-BY kan apparaten startas med timerfunktion eller fjärrkontrollen. Varning: Apparaten innehåller inga delar som kan åtgärdas av kunden. Höljet får endast öppnas av kvalificerad personal. Apparaten innehåller farliga spänningar. Stickkontakten ska därför dras ut från nätuttaget före reparationsarbeten och bör dras ut om apparaten inte ska användas på mycket länge.
● El material audiovisual puede consistir en trabajos que tengan derechos de autor y que no deben grabarse sin la autorización del poseedor de dichos derechos de autor. Sírvase consultar las leyes aplicables en su país. ● Attenzione: Per prevenire incendi o scosse elettriche, non fare gocciolare nessun liquido sull’apparecchio e non bagnarlo. Non collocarvi sopra nessun oggetto riempito d’acqua, come per esempio vasi.
● ATTENZIONE Questo prodotto contiene un dispositivo laser a bassa potenza. Per garantire una sicurezza continua, non togliete alcuna protezione e non cercate di accedere all’interno del prodotto. Fate sempre riferimento ad un personale qualificato. ● Dieses Produkt ist ein Laserprodukt der Klasse 1. ● Ce produit est classifié comme étant un LASER DE CLASSE 1. ● Este producto está clasificado como un PRODUCTO LÁSER DE CLASE 1. ● Denna produkt LASERPRODUKT.
„Made for iPod“, „Made for iPhone“ und „Made for iPad“ bedeutet, dass ein elektronisches Zubehörteil speziell für den Anschluss an einen iPod, iPhone oder iPad konzipiert wurde und der Entwickler sich dafür verbürgt, dass das Gerät den Leistungsstandards von Apple entspricht. Apple ist nicht verantwortlich für den Betrieb dieses Gerätes oder dafür, dass es Sicherheits- und Regulierungsstandards einhält.
Die Wortmarke Bluetooth® und die zugehörigen Logos sind Eigentum der Bluetooth SIG, Inc. und werden von SHARP unter Lizenz verwendet. Andere Marken und Produktnamen sind Eigentum der jeweiligen Rechteinhaber. Die Markierung N ist ein Markenzeichen oder ein registrierte Markenzeichen von NFC Forum, Inc. in den USA und in anderen Ländern registriert. N Mark est une marque ou une marque déposée de NFC Forum, Inc. enregistrée aux États Unis et dans d’autres pays.
Información sobre la eliminación Entsorgungsinformationen A. Entsorgungsinformationen für Benutzer aus Privathaushalten 1. In der Europäischen Union Achtung: Werfen Sie dieses Gerät zur Entsorgung bitte nicht in den normalen Hausmüll! Gemäß einer neuen EU-Richtlinie, die die ordnungsgemäße Rücknahme, Behandlung und Verwertung von gebrauchten Elektro- und Elektronikgeräten vorschreibt, müssen elektrische und elektronische Altgeräte getrennt entsorgt werden.
Informazioni per un corretto smaltimento Attenzione: Il dispositivo è contrassegnato da questo simbolo, che segnala di non smaltire le apparecchiature elettriche ed elettroniche insieme ai normali rifiuti domestici. Per tali prodotti è previsto un sistema di raccolta a parte. A. Informazioni sullo smaltimento per gli utenti (privati) 1.
Informacja dotycząca prawidłowego usuwania zużytego sprzętu Uwaga: Państwa produkt jest oznaczony tym symbolem. Oznacza on, że zużytych urządzeń elektrycznych i elektronicznych nie można łączyć ze zwykłymi odpadami z gospodarstw domowych. Dla tych produktów istnieje oddzielny system zbiórki odpadów. Netinkamo eksploatuoti gaminio pašalinimas A. Informacje dla użytkowników (prywatnych gospodarstw domowych) dotyczące usuwania odpadów 1.
Informationen zur Batterieentsorgung Die für dieses Produkt mitgelieferte Batterie kann Spuren von Blei enthalten. Für die EU: Die durchgestrichene Abfalltonne bedeutet, dass gebrauchte Batterien nicht mit dem Haushaltsmüll entsorgt werden sollten! Es gibt getrennte Sammelsysteme für gebrauchte Batterien, welche eine ordnungsgemäße Behandlung und Verwertung entsprechend gesetzlicher Vorgaben erlauben. Weitere Einzelheiten erhalten Sie von IhrerGemeindeverwaltung.
ENGLISH ●● XL-HF202PH(S) Hi Fi Component System consisting of XL-HF202PH(S) (main unit) and CP-HF202H (speaker system). ●● XL-HF202PH(BK) Hi Fi Component System consisting of XL-HF202PH(BK) (main unit) and CP-HF202H (speaker system). ●● XL-HF302PH(T) Hi Fi Component System consisting of XL-HF302PH(T) (main unit) and CP-HF301H (speaker system). Introduction Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully.
Precautions ■■ General ●● Keep your equipment at least 10 cm (4”) of free space along the sides, top and back for proper ventilation. 10 cm (4”) 10 cm (4”) 10 cm (4”) 10 cm (4”) ●● Use the unit on a firm, level surface free from vibration. ●● Place the speakers at least 30 cm (12”) away from any CRT TV to avoid colour variations across the TV screen. If the variations persist, move the speakers further away from the TV. LCD TV is not prone to such variation.
Controls and indicators (continued) ■■ Remote control 1 2 18 19 20 21 3 22 23 24 25 26 4 5 6 7 8 27 28 29 9 10 11 12 13 14 15 30 31 32 33 34 35 36 37 16 38 39 17 9 1 23 4 5 17 18 19 20 21 6 7 8 22 15 10 1112 13 14 16 23 24 25 26 Dome-Tweeter Woofer Bass Reflex Duct Speaker Terminal 1 3 2 4 ■■ Speaker grilles are removable Make sure nothing comes into contact with the speaker diaphragms when you remove the speaker grilles. ■■ Display 27 28 29 ■■ Speaker system 1. 2. 3. 4.
System connections Make sure to unplug the AC power lead before making any connections. To select Line In function: Press FUNCTION button (main unit) or AUDIO/LINE (INPUT) button (remote control) repeatedly until Line in is displayed. Notes: ●● No sound is heard from the subwoofer without a builtin amplifier. ●● Subwoofer Pre-out (audio signal): 200mV / 10k ohms at 70 Hz. TV Right speaker Audio cable (not supplied) Commercially available Subwoofer (Amplifier Built-In) To TV audio output socket.
Remote control ■■ Battery installation 1 Open the battery cover. 2 Insert the supplied battery according to the terminal indicated in the battery compartment. When inserting or removing the battery, push it towards the (–) battery terminals. 3 Close the cover. Notes concerning use: ●● Replace the battery if the operating distance is reduced or if the operation becomes erratic. Purchase an “AA” size battery (UM/SUM-3, R6, HP-7 or similar).
Setting the clock (Remote control only) 5 To adjust the hour, press the or button and then press the ENTER button. Press the or button once to advance the time by 1 hour. Hold it down to advance continuously. To adjust the minutes, press the or button and then press the ENTER button. Press the or button once to advance the time by 1 minute. Hold it down to advance the time by 5 minutes interval. 6 In this example, the clock is set for the 24-hour (0:00) display.
Bluetooth one touch connection via NFC (continued) ■■ NFC tag set up ■■ NFC connection for audio playback The NFC tags can be placed anywhere convenient to you. The velcro tapes supplied will help to secure the tags onto the desired location. Caution : ●● Make sure that the NFC tag is placed on a flat and level Check that: ●● Your device (smartphone / tablet) has an NFC function. ●● NFC function on your device is turned on. ●● Screen lock function of the device is off. ●● This unit is not in Eco mode.
Listening to Bluetooth enabled devices (continued) If a steel concrete or metallic wall is between the device and the main unit, the system may not operate at all, because the wireless signal cannot penetrate metal. ■■ Pairing Bluetooth devices Bluetooth devices need to be initially paired first before they can exchange data. Once paired, it is not necessary to pair them again unless: ●● pairing is made with more than 8 devices. Pairing can only be made one device at a time.
Listening on Android™ devices ■■ Introduction : Open Accessory Open Accessory support allows external USB hardware (an Android USB accessory) to interact with an Androidpowered device in a special accessory mode. When an Android-powered device is in accessory mode, the connected accessory acts as the USB host (powers the bus and enumerates devices) and the Android-powered device acts in the USB accessory role.
Listening to the iPod, iPhone or iPad Made for: ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● ●● iPhone 5 iPhone 4S iPhone 4 iPhone 3GS iPhone 3G iPhone iPad (4th generation) iPad mini iPad (3rd generation) iPad 2 iPad iPod touch (5th generation) iPod touch (4th generation) iPod touch (3rd generation) iPod touch (2nd generation) iPod touch (1st generation) iPod classic iPod nano (7th generation) iPod nano (6th generation) iPod nano (5th generation) iPod nano (4th generation) iPod nano
Listening to the iPod, iPhone or iPad (continued) 2 Dock your iPod or iPhone into the unit. ■■ Various iPod, iPhone and iPad functions iPhone (bottom) Function iPhone Main unit Remote control Dock/USB Dock USB Play Lightning connector iPod CD/USB Pause Track up/ down Lightning connector Dock for iPhone ■■ iPod or iPhone playback (Dock) 1 Press the ON/STAND-BY button to turn the power on.
Listening to a CD or MP3/WMA disc ■■ Various disc functions Function Main unit Remote control Play Pause Stop Track up/down Fast forward/ reverse ■■ Disc playback 1 Press the ON/STAND-BY button to turn the power on. 2 Press the CD button on the remote control or FUNCTION button repeatedly on the main unit to select CD function. 3 Press the OPEN/CLOSE button to open the disc compartment. 4 Place the disc in the disc compartment, label side front. 5 Press the OPEN/CLOSE button to close the disc tray.
Listening to a CD or MP3/WMA disc (continued) ■■ Repeat play Repeat play can play one track, all tracks or a programmed sequence continuously. To repeat one track: Select desired track using the Numeric buttons. Press the REPEAT button repeatedly until “Repeat One” appears. Press the / (CD/USB / ) button. To repeat all tracks: Press the REPEAT button repeatedly until “Repeat All” appears. Press the / (CD/USB / ) button.
Listening to USB mass storage device/MP3 player iPad Note: This product is not compatible with MTP and AAC file systems from USB mass storage device or MP3 player. ■■ To play back USB/MP3 player with folder mode on / off 1 Press the USB button (remote control) or FUNCTION button (main unit) repeatedly to select USB function. Connect the USB memory device that has MP3/WMA format files on the unit. When the USB memory is connected to the main unit, the device information will be displayed.
Listening to the radio 4 Within 30 seconds, press the MEMORY button to store that station in memory. If the “MEM” and preset number indicators disappear before the station is memorised, repeat the operation from step 2. 5 Repeat steps 1 - 4 to set other stations, or to change a preset station. When a new station is stored in the memory, the station previously memorised for that preset channel number will be erased.
Using the Radio Data System (RDS) (continued) ■■ Information provided by RDS You can control the RDS by using the buttons on the remote control only. Each time the RDS DISPLAY button is pressed, the display will switch as follows: Station name (PS) Frequency Programme type (PTY) Notes: ●● If the same station is broadcasting on different frequencies, the strongest frequency will be stored in memory. ●● Any station which has the same frequency as the one stored in memory will not be stored.
Using the Radio Data System (RDS) (continued) 4 While the selected programme type is flashing (within 6 seconds), press the RDS PTY button again. After the selected programme type has been lit for 2 seconds, “SEARCH” will appear, and the search operation will start. Notes: ●● If the display has stopped flashing, start again from step 2. If the unit finds a desired programme type, the corresponding channel number will lit for about 8 seconds, and then the station name will remain lit.
Timer and sleep operation (Remote control only) (continued) 11 Press the ON/STAND-BY button to enter the power ■■ Sleep operation stand-by mode. “TIMER” indicator lights up. 12 When the preset time is reached, playback will start. The volume will increase gradually until it reaches the preset volume. The timer indicator will blink during timer playback. 13 When the timer end time is reached, the system will enter the power stand-by mode automatically. Once timer: The timer will be cancelled.
Enhancing your system Troubleshooting chart The connection lead is not included. Purchase a commercially available lead as shown below. If something is wrong with this product, check the following before calling your authorised SHARP dealer or service centre. ■■ General Symptom ●●The clock is not set to the correct time. ●●When a button is pressed, the unit does not respond. Portable audio player, etc. ●●No sound is heard.
Troubleshooting chart (continued) ■■ Open Accessory Symptom ●●No sound is produced. ●●Device will not charge. ■■ USB Possible cause ●●The device is not playing. ●●The device is not properly connected to the unit. ●●The AC power lead of the unit is not plugged in. ●●The device is not making full contact with the USB terminal. ■■ iPod, iPhone or iPad Symptom ●●No sound is produced. ●●iPod, iPhone or iPad will not charge.
Specifications Troubleshooting chart (continued) ■■ Factory reset, clearing all memory 1 Press the ON/STAND-BY button to turn the power on. 2 Press FUNCTION button (main unit) repeatedly or AUDIO/LINE (INPUT) button (remote control) to enter Audio In mode. 3 Press button (main unit) once. 4 Press and hold button (main unit) until “RESET” appears. Caution: This operation will erase all data stored in memory including clock, timer settings and tuner preset.
Specifications (continued) ■■ CD player Type Signal readout D/A converter Frequency response Dynamic range ■■ Tuner Single disc multi-play compact disc player Non-contact, 3-beam semiconductor laser pickup Multi bit D/A converter 20 - 20,000 Hz Support file Bitrate support Other File system support ■■ Speaker (XL-HF202PH) Type 90 dB (1 kHz) ■■ USB (MP3 / WMA) USB host interface Frequency range FM: 87.5 - 108 MHz Preset 40 (FM station) ●● Complies with USB 1.1 (Full Speed)/2.0 Mass Storage Class.
