User Manual

RATED SPEAKER IMPEDANCE:
6 OHMS MIN.
AC INPUT
ANTENNA
RIGHT
RIGHT LEFT
FM
75 OHMS
AM
LOOP
VIDEO/AUX
IN
SUBWOOFER
PRE-OUT
SPEAKERS
LEFT
Black
Red
FM
75 OHMS
1 Accessories
Remote control × 1
TINSEA094AWZZ
05C R KI 2
AM loop aerial × 1
FM aerial × 1
2 Remote control battery installation
1 Open the battery cover.
2 Insert the batteries as shown.
3 Close the cover.
Use 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).
Batteries are not included.
Wall socket
(AC 230-240V, 50 Hz)
Left speaker
FM aerial
AM loop aerial
Right speaker
MODEL
XL-MP110E
MICRO COMPONENT SYSTEM
This Quick Start Guide will help you to correctly install and
operate your system.
3 System connections
4 Turning on your system
The first time the unit is plugged in, the unit will
enter the demonstration mode. You will see
words scroll.
1 Press the X-BASS/DEMO button to cancel
the demonstration mode.
2 Press the ON/STAND-BY button to turn the
power on.
