The link quality and signal strength bar chart is only active when the node is in
infrastructure mode. The bar graph displays the quality and strength of the link between the node
and its Access Point. Link Quality is a measurement of receiving and transmitting performances
over the radio.And the Network Address is shown in the red pane.
Tx/Rx Frame displays the instantaneous wireless Transmit and Receive throughput in bytes
per second. These values are updated every two seconds. The Configuration Tool contains
several fields where operating parameters of the driver can be viewed or changed. Changes to
any of the parameters in this panel can be applied to the driver without a need to restart the
computer.
