UserManua

WirelessHeadphone：EP‐B60(FCCID ：2AFHP‐EP‐B60)

ThankyouforpurchasingtheAUKEYEP‐B60MagneticWirelessEarbuds.Pleasereadthisusermanual

carefullyandkeepitforfuturereference.Ifyouneedanyassistance,pleasecontactoursupportteamwith

yourproductmodelnumberandAmazonordernumber.

PackageContents

MagneticWirelessEarbuds

Micro‐USBCable

ThreeSetsofEar‐Tips(S/M/L)

ThreePairsofIn‐EarEar‐hooks(S/M/L)

CarryingPouch

UserManual

WarrantyCard



ProductDiagram



Volume+/NextTrack

Multi‐FunctionButton

Volume‐/PreviousTrack

LEDIndicator

Micro‐USBChargingPort

Microphone

Summary of content (6 pages)

PAGE 1
User Manua Wireless Headphone：EP‐B60(FCC ID ：2AFHP‐EP‐B60) Thank you for purchasing the AUKEY EP‐B60 Magnetic Wireless Earbuds. Please read this user manual carefully and keep it for future reference. If you need any assistance, please contact our support team with your product model number and Amazon order number.
PAGE 2
Specifications Model EP‐B60 Technology BT 4.1, A2DP, AVRCP, HSP, HFP Driver 8mm(D) x 5mm(H) / 0.31”(D) x 0.2”(H) Impedance 16 ohm Sensitivity 95±3 dB Frequency Range 20Hz –20kHz Microphone Noise Reduction 6th generation cVc audio technology Input DC 5V Charging Time 1.5 hours Play Time 8hours Standby Time 120 hours Battery Type Li‐Polymer (2 × 60mAh) Operating Range Up to 10m / 33ft Weight 15g / 0.53oz Getting Started Fully charge your earbuds before first use.
PAGE 3
Pairing Starting with yourearbuds powered off: 1. Press and hold the multi‐function buttonfor 5 seconds until the LED indicator flashesblue and red alternately 2. Turn on the pairing function of the device you want to pair with the earbuds 3. In the list of available devices, find and select “AUKEY EP‐B60”. When connected, the LED indicator will flash bluetwice every 5 seconds 4. If a code or pin is required for pairing, enter “0000” Simultaneous Pairing with Two Devices 1.
PAGE 4
Siri / Google assistant Press multi‐function button for only 1 second and then must release your finger, you will hear a tone Streaming Audio Once paired, you canwirelessly stream audio from your device to your earbuds. Music willautomatically pausewhen you receive an incoming phone call, and resume once the call has ended.
PAGE 5
What is the wireless range of the earbuds? The maximum range is 33ft (10m). However, the actual range will depend on environmental factors. For optimal performance, keep your devices connected with the earbuds within a 15ft‐25ft range and make sure that there are no major obstacles (like reinforced steel walls) between the earbuds and your devices. My earbuds won’t turn on even when I have fully charged them Connect the earbuds to a USB charger port with the included micro‐USB cable.
PAGE 6
FCC Rules This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
