User's Manual

3.1.1 Transmitter Display Area Divide
3.2 Interface
3.1.2 Transmitter Interface Area explanation
1、Current Interface Indication Area
This interface is used to indicate the user the current status. The interface
including: client single calling, service single calling, service group calling, One key
call, setting up, USB connection, Testing interface. Each interface is indicated in the
different indicator.
2、Time indication area
The time indication only could show the hour and minute, this time used to
compare with the swipe the card time. It would fresh once each 10s.
3、Company Name Area
User information area used to display the user's name, it could edit and download
through the upper computer, the length has to less than 22 including the spacebar.
Current Interface
User information
Time
Icon
Indicator
From Left
to Right :
wireless
sending,
timely
paging 、
Open
Voice 、
input
method
Main Information
Input the
sending
Serial No
area
Sending
message
inputting
area
6
