EF02 Bluetooth Reader ——Product Introduction(Rev.
1. Product introduction and description Table 1.1 Model Name Function and description Product Picture ●2D bar code scanner ring type ●Bluetooth HID, Bluetooth SPP, upload data offline ●The Zebra SE2707 scan engine ●Using OMRON B3F-5000 touch switch EF02 button ●550mA battery capacity, long standby time over 30 days ●The keys can be rotated 180 degrees, freely changing left and right hands ●IP65 waterproof grade ●1.5m drop test (200 times) Dimension：55.0×39.2×51.
2. Using manual 2.1 On & Off Turn on: At the push of a button, the green light will shinning once time, at the same time the buzzer will ring once, and the device will vibrate keep a short time(100ms), then the reader is started. Turn off: After pressing the button for 6s, the green light is on, the buzzer sounds, the device vibrates keep for 0.6s, and the scanner shuts down. (Automatic shutdown after 20min standby) 2.2 Equipment working status indication Table 2.
2.4 Battery disassembly Table 2.3 A. Push the push button to the left in the direction of the arrow B. Keep the push button on the left and pull the battery cover up to open the battery cover and remove the battery. A. With the battery electrode facing down and into the battery slot, insert the two buckles on the battery cover into the holes on the top of the machine. B.
2.5 Charging and adapter function ( optional ) Table 2.4 ① Battery charging slot With the electrode end facing down and the electrode facing inward, insert into the battery charging slot ① ② Battery charging slot status indicator After the base is powered on, put the battery into the battery charging slot. The red light on the battery charging slot status indicator is on. When the battery is fully charged, the red light is off.
FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
