Specifications

Date Rate & Modulation
BR_1Mbps: GFSK;
EDR_2Mbps: π/4-DQPSK;
EDR_3Mbps: 8DPSK;
LE_125Kbps: GFSK (Coded_S=8);
LE_500Kbps: GFSK (Coded_S=2);
LE_1Mbps: GFSK (Uncoded);
LE_2Mbps: GFSK (Uncoded);
Bluetooth Receiver Specifications
Items
Sensitivity Maximum Input Level
Input Level
(Typ: dBm）
BER
Input Level
(Typ: dBm）
BER
BR_1M -90 ≦0.1% -5dBm ≦0.1%
EDR_2M -80 ≦0.01% -5dBm ≦0.1%
EDR_3M -70 ≦0.01% -5dBm ≦0.1%
Input Level(Typ) PER Input Level (Typ) PER
LE_125K -80 ≦30.8% -5dBm ≦30.8%
LE_500K -80 ≦30.8% -5dBm ≦30.8%
LE_1M -80 ≦30.8% -5dBm ≦30.8%
LE_2M -80 ≦30.8% -5dBm ≦30.8%
Note: For BER receiver sensitivity test, bit error rate (BER) better than 0.1% for a minimum of 1600000
bits transmitted by the tester; For EDR receiver sensitivity test, bit error rate (BER) better than 0.01% for
a minimum of 16000000 bits transmitted by the tester; For LE receiver sensitivity test, packet error rate
(PER) better than 30.8% for a minimum of 1500 packets transmitted by the tester.
