Specifications

Block Diagram
General Specifications
Module Name BL-
M2268BU1
Chipset MT7668BU
WLAN Standards
IEEE802.11a/b/g/n/ac
Host Interface USB2.0
Antenna
WLAN: PIFA antenna, BT: PCB printed antenna
Dimension 200*19*5.5
mm (L
Power Supply MT7668BU
: DC 5.0
Operation Temperature -20℃ to +
70
Operation Humidity
10% to 95% RH (Non
Storage Temperature -40℃ to +
85
Storage Humidity
10% to 95% RH (Non
M2268BU1
-B 867Mbps WLAN + BT5.0 USB2.0 Module
IEEE802.11a/b/g/n/ac
WLAN: PIFA antenna, BT: PCB printed antenna
mm (L
*W*H)
: DC 5.0
V±0.3V @ 500 mA (Max),
70
℃
10% to 95% RH (Non
-Condensing)
85
℃
10% to 95% RH (Non
-Condensing)
