Specifications

5G TX HT20 MCS8 @ 13dBm (RF-Test) 448 479 mA
5G TX HT20 MCS15 @ 13dBm (RF-Test) 327 255 mA
5G TX HT40 MCS8 @ 13dBm (RF-Test) 442 470 mA
5G TX HT40 MCS15 @ 13dBm (RF-Test) 290 322 mA
5G TX HT80 MCS0 @ 12dBm (RF-Test) 381 415 mA
5G TX HT80 MCS9 @ 11dBm (RF-Test) 252 285 mA
5G RX Active VHT80 MCS9 (RF-Test) 115 145 mA
BT
BT Unassociated (Linux Driver) 21.8 35 mA
Bluetooth TX @ 5dBm 159 186 mA
Bluetooth RX 138 165 mA
4. WIFI& Bluetooth RF Specifications
2.4G WIFI RF Specification
Conditions : VDD=5V ; Ta:25℃
Features Description
WLAN Standard IEEE 802.11b/g/n, CSMA/CA
Frequency Range 2.4~2.4835GHz (2.4GHz ISM Band)
Channels Ch1~Ch13 (For 20MHz Channels)
Modulation
802.11b (DSSS): CCK, DQPSK, DBPSK;
802.11g (OFDM): BPSK, QPSK, QAM16, QAM64;
802.11n (OFDM): BPSK, QPSK, QAM16, QAM64;
Date Rate
802.11b: 1, 2, 5.5, 11Mbps;
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps;
802.11n (HT20): MCS0~MCS7(1T1R_SISO) 6.5~72.2Mbps;
802.11n (HT20): MCS8~MCS15(2T2R_MIMO) 13~144.4Mbps;
802.11n (HT40): MCS0~MCS7(1T1R_SISO) 13.5~150Mbps;
802.11n (HT40): MCS8~MCS15(2T2R_MIMO) 27~300Mbps;
Frequency Tolerance ≦±15ppm
MT7668BU Receiver Specifications
RX Rate Min Input Level（dBm） Max InputLevel（dBm） PER
802.11b@1Mbps -95 0 < 8%
