TM101W635L User’s Guide
Customer Service NuVision Customer Service www.nuvision.com/assistance Phone: (800) 890-1288 Hours: 8:30am to 5:30pm PST M-F Email: cs@nuvision.com Register your tablet today at www.nuvision.
Introduction Thank you for purchasing the NuVision Duo 10. The 10.1” NuVision DUO 10 is our most versatile 2-in-1 tablet/laptop yet. The superior and reliable performance of the DUO 10 starts with a certification process that requires higher end components during the manufacturing process resulting in a cleaner, faster and more secure Windows experience. The DUO 10 includes Finger ID protection so only you can access your laptop and protect its contents.
Features & Package Contents Tablet AC Adapter (Connects to USB Type-C) Pen Keyboard 4
Important Safety Instructions This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Please read the following instructions and notices before using your tablet. 1. Avoid using in extremely hot, cold, dusty, damp or wet environments. 2. The tablet is not moisture or water-resistant.
Tablet Overview 3 1 4 3 5 6 7 7 8 10 11 2 14 13 6 15 16 9
1. 2. Camera: Built in 2.0MP front camera to take HD photos or videos. Window: Press to return to Home/Start Menu. Microphone: Built in microphones. Use to speak to Cortana or for making personal recordings. 4. Camera: Built in 5.0MP rear camera to take HD photos or videos. 5. Power / Standby: Press and hold for 3 seconds to turn on the tablet. Press momentarily to enter Sleep mode. This will turn off display and save battery life. Press and hold to turn off. 6.
2 Overview Keyboard 14 15 16 13 12 17 18 19 8 20
12. 13. 14. 15. 16. 17. 18. 19. 20. Mouse Pad Lock: Press to temporarily disable the Mouse Pad (indicator light above the Mouse Pad Lock icon will glow RED). Press again to re-enable. Full Size USB 2.0 Port (Left side of keyboard) Mouse Pad Lock / CAPS Light Indicator Tablet Connector to Keyboard: Magnetic hinge and tabs to secure the tablet in a laptop configuration. Full USB 2.
Connecting the Tablet and Keyboard Your tablet features a specially designed magnetic hinge that attaches and secures the tablet and keyboard together, enabling quick and easy docking. 1. Dock Port Connect the 5-pin magnetic dock port to support the keyboard and USB functions. 2. Hinge Tabs Align and insert tabs into their respective holds to attach the tablet.
Undocking the Tablet Firmly grasp the tablet and secure the keyboard at the same time, then gently pull out the tablet.
Charging the Battery Connect the power adapter to a wall outlet, then to the tablet’s USB Type-C port as shown. It is recommended to fully charge the battery before first use. A battery status indicator appears in the lower right corner of the Task Bar. Tap to view the current battery level, time remaining, brightness control, and settings for power and sleep modes. It is normal for the tablet to become warmer while charging, streaming video, or multitasking.
Battery Care Operating temperature: Your device is designed to function between 32°F and 95°F (or 0°C to 35°C). Lithium-ion batteries are sensitive to higher temperatures so keep away from direct sun light. Don’t leave in a closed environment susceptible to extreme temperatures (ie: a vehicle on a hot sunny day). Recharge anytime: You may recharge the internal battery at any time however do not allow battery to discharge below 15% before recharging. Disconnect charger immediately after battery reaches 100%.
Starting your Tablet Power On/Off/Standby Mode/Reset ON: Press and hold the side POWER button on the side for a couple of seconds until the logo screen appears, then release. button on the side of the tablet. When prompted, slide finger downward to shut down your PC. STANDBY MODE: While the tablet is on, press the side Power button quickly to turn off the display only. The tablet will enter Sleep mode to minimize battery functions. Press the Power button quickly to wake from Sleep mode.
Fingerprint ID / Lock Screen and Password The Lock Screen is the starting point when the tablet is turned ON. Swipe your finger upward from the bottom of the display to exit the Lock Screen, then enter your Password. To use Fingerprint ID, first go to Settings/Accounts and select ‘Sign-in options’. In the window to the right, scroll down to Windows Hello and select ‘Set up’. Follow the prompts to activate the Fingerprint ID function. NOTE: To reset your Password, go to ACCOUNT.LIVE.
Start Menu / Tablet Task Bar Overview 1 2 3 4 5 6 7 8 15 9 10 11 13 14 12 16
