300M Wireless-N Access Point
300M Wireless-N Access Point Copyright Statement is the registered trademark of Shenzhen Tenda Technology Co., Ltd. All the products and product trademarks names or mentioned registered herein trademarks are of the their respective holders. Copyright of the whole product as integration, including its accessories and software, belongs to Shenzhen Tenda Technology Co., Ltd. Without the permission of Shenzhen Tenda Technology Co.
00M Wireless-N Access Point Content Chapter 1 Product Overview .........................1 1.1 Features ..........................................2 1.2 Package Contents..............................3 1.3 LED Indicator and Panel Description.....4 Chapter 2 Hardware Installation ....................7 Chapter 3 Web Configuration ........................9 3.1 Web Login........................................9 3.2 Wizard........................................... 11 3.3 Running Status ...................
300M Wireless-N Access Point 4.3 WPS Settings.................................. 55 4.4 Access Control ................................ 57 4.5 Connection Status ........................... 59 4.6 PING ............................................. 60 Chapter 5 SNMP Setting ............................. 61 5.1 SNMP Introduction .......................... 61 5.2 SNMP Setting ................................. 62 Chapter 6 System Tools ............................. 64 6.1 Password Change ...........
300M Wireless-N Access Point Chapter 1 Product Overview W300A, with 2T3R antennas, is an IEEE802.11n (Draft 2.0)-compliant wireless access point with one Gigabit LAN switch port, which utilizes the latest MIMO technology and provides up to 300Mbps stable transmission rate from wireless radio to wired network. With backward compatible with IEEE802.11b/g device, it is suitable for SOHOs and small-sized enterprises to share the wireless network.
300M Wireless-N Access Point 1.1 ¾ Features Complies with IEEE802.11n (Draft 2.0), IEEE802.11b and IEEE802.11g standards ¾ Supports five working modes: wireless AP, Repeater, P2P, P2MP and wireless client ¾ Provides 300Mbps receiving rate and 300Mbps sending rate ¾ MIMO technology utilizes reflection signal to increase 8 times transmission distance of original 802.
300M Wireless-N Access Point Bridge, WDS P2MP Bridge, WDS AP Bridge and ¾ Client Supports Auto MDI/MDIX ¾ Supports Firefox1.0, IE5.5 or above ¾ Supports authorization access over thirty-two MAC addresses ¾ Supports auto wireless channel selection ¾ Provides three detachable antennas Wireless local network usually is used in a planned environment where each access point is located steadily and with stable radio coverage area.
300M Wireless-N Access Point If any of listed items are missing or damaged, please contact the Tenda reseller from whom you purchased for replacement immediately. 1.3 LED Indicator and Panel Description z LED indicator description on front panel (from L to R) WPS When blinking, it indicates the device is negotiating with client in WPS mode. POWER When turns green, Always ON indicates the power connects well.
300M Wireless-N Access Point SYS When turns green, blinking indicates the system runs well. WLAN Wireless signal LED indicator. When turns green, Always ON indicates the wireless function is enabled; blinking indicates the device is transmitting and/or receiving data. LAN Wired local network LED indicator.
300M Wireless-N Access Point z Rear Panel：（From L to R） POWER The jack is for power adapter connection. Please use the included 12V DC power adapter. LAN The Gigabit Ethernet port is for computer’s NIC or switch connection. It also can be used as PoE interface. When PoE and external power adapter power on the device, the include power adapter is preferred. RESET/WPS Compound button is for system reset and WPS.
300M Wireless-N Access Point Chapter 2 Hardware Installation This chapter explains how to connect the Access Point (take the AP mode installation as example, other installation modes please refer to the Quick Installation Guide). The detailed processes are shown as below: 1. Connect one end of the network cable to your Ethernet broadband router, switch or PC, and the other end to the W300A’s LAN port. 2. Connect the power adapter to the AP’s Power jack.
300M Wireless-N Access Point The topology plan of AP mode connection 8
300M Wireless-N Access Point Chapter 3 Web Configuration 3.1 Web Login Connect to W300A via wired cable and configure 192.168.0.x(x ranges 1-253) as your PC’s IP address, and 255.255.255.0 as subnet mask. (Please refer to the Appendix II for details on TCP/IP setting) Launch Internet Explorer or Netscape Navigator. In the address bar, enter the AP’s default IP address, 192.168.0.254 Press Enter key and the login screen will appear. Enter admin both in the user name and password field.
300M Wireless-N Access Point Click OK to enter the first web page of the device.
300M Wireless-N Access Point 3.2 Wizard Click “Next” in the first page and the next page appears. On this page, you can select one from five wireless network modes: Wireless AP, P2P Bridge Mode, P2MP Bridge Mode, Repeater Mode and Client. And to secure your network, you can configure its corresponding security setting.
300M Wireless-N Access Point 3.3 Running Status This page shows the wireless AP’s current status, including wireless status, LAN status and system information.
300M Wireless-N Access Point Channel, Encryption mode, etc. LAN Interface information z Here shows LAN IP obtain way, MAC address, IP address, subnet mask, etc. System information z Here shows the device’s current software version, hardware version, etc. 3.4 LAN Settings This section mainly deals with LAN’s basic settings. Static IP：The default IP address is 192.168.0.254.
300M Wireless-N Access Point address, subnet mask and gateway manually for the device. Dynamic IP：Automatically obtain IP address, subnet mask and gateway from DHCP server. (Unless you have got permission to obtain this information from the uplink connected device, otherwise, it is not recommended to select this way). Note: If the LAN IP address is changed, you need use the new IP address to login the wireless AP’s Web interface next time.
300M Wireless-N Access Point Chapter 4 Wireless Settings 4.1 Working Mode Select “Wireless Setting->Working Mode” to enter the following window. From the drop-down menu of Working Mode, the device supports five working modes: AP, P2P Bridge, P2MP Bridge, AP Repeater and Client.
300M Wireless-N Access Point 4.1.1 Access Point (AP) Mode The AP mode is the basic mode of the device. When the system is reset to the default factory settings, the operating mode reverts to AP mode. In this mode, the AP will act as a central hub for different wireless LAN clients. For example, when traveling to a hotel that has high-speed internet access, you can connect to the internet through the AP which is connected to an Ethernet cable in the room. 4.1.1.
300M Wireless-N Access Point 4.1.1.2 AP Mode Settings In the working mode, select “AP” to enter the next window.
300M Wireless-N Access Point z Basic Wireless Settings Network Mode：Select one mode from the following. The default is 11b/g/n mode. 11b mode：Allow the wireless client to connect with the device in 11b mode at the maximum speed of 11Mbps. 11g mode：Allow the 11g/11n-compliant client device to connect with the AP at the maximum speed of 54Mbps.
300M Wireless-N Access Point When this feature is enabled, wireless clients connected with the same SSID can not communicate with each other. For example, configure main SSID as AP1, minor SSID as AP2. PC1 and PC2 connect to AP1 via wireless adapter, and configure PC1 and PC2 in the same segment. After the feature is enabled, two PCs can not communicate and share network resource each other, but they can communicate with wireless clients connected with AP2.
300M Wireless-N Access Point connecting to AP2. After the feature is enabled, two PCs can not communicate and share network resource each other. This feature is to isolate the communication of wireless clients connected with different SSID. Tip: If you want to isolate all connected wireless client's communication, please enable MBSSID AP Isolation and AP Isolation simultaneously. BSSID：Basic Service Set Identifier of wireless network. In IEEE802.11, BSSID is the MAC address of wireless access point.
300M Wireless-N Access Point encryption methods, including Mixed WEP, WPA-personal, WPA-enterprise, WPA2-personal, WPA2- enterprise, etc.
300M Wireless-N Access Point Mixed WEP WEP (Wired Equivalent Privacy), a basic encryption method, usually encrypts wireless data using a series of digital keys (64 bits or 128 bits in length). By using the same keys on each of your wireless network devices, you can prevent unauthorized wireless devices from monitoring your transmissions or using your wireless resources. WEP is based on RSA algorithm from RC4.
300M Wireless-N Access Point Setting Explanation Select SSID：Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu. Security Mode：From the drop-down menu select the corresponding security encryption modes. WEP Key1~4 ： Set the WEP key with the format of ASCII and Hex. You can enter ASCII code (5 or 13 ASCII characters. Illegal character as “/” is not allowed.) Or 10/26 hex characters.
300M Wireless-N Access Point enter the following window: Setting Explanation Select SSID ： Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu. WPA Algorithms：Provides TKIP [Temporal Key Integrity Protocol] or AES [Advanced Encryption Standard]. The default is TKIP mode. Pass Phrase： Enter the encrypted characters with 8-63 ASCII characters. Key Renewal Interval：Set the key’s renewal period.
300M Wireless-N Access Point WPA2-PSK WPA2 provides more secure features than WEP and WPA. Select “WPA2-PSK” from the drop-down menu to enter the following window: Setting Explanation Select SSID ： Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu. WPA Algorithms：Provides TKIP [Temporal Key Integrity Protocol] or AES [Advanced Encryption Standard]. The default is TKIP mode.
0M Wireless-N Access Point Pass Phrase： Enter the encrypted characters with 8-63 ASCII characters. Key renewal Interval：Set the key’s renewal period. WPA This security mode is used when a RADIUS server is connected to the device. Select “WPA” from the drop-down menu to enter the following window: Setting Explanation Select SSID ： Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu.
300M Wireless-N Access Point [Advanced Encryption Standard]. The default is TKIP mode. Key Renewal Interval：Set the key’s renewal period. Radius Server：Enter the IP address of the Radius server. Radius Server port：Enter the authentication port of the Radius server. The default is 1812. Shared Secret：Enter the shared key for authentication server with 8~63 ASCII characters. Session Timeout： The authentication interval period between AP and authentication server. The default is 3600s.
300M Wireless-N Access Point Setting Explanation Select SSID ： Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu. WPA Algorithms：Provides TKIP [Temporal Key Integrity Protocol] or AES [Advanced Encryption Standard]. The default is TKIP mode. Key Renewal Interval：Set the key’s renewal period. Radius Server：Enter the IP address of the Radius server.
300M Wireless-N Access Point authentication port of the Radius server. The default is 1812. Shared Key：Enter the shared key for authentication server with 8~63 ASCII characters. Session Timeout： The authentication interval period between AP and authentication server. The default is 3600s.
300M Wireless-N Access Point 802.1x Authentication This security mode is used when a RADIUS server is connected to the device. 802.1x, a kind of Port-based authentication protocol, is an authentication type and strategy for users. The port can be either a physic port or logic port (such as VLAN). For wireless LAN users, a port is just a channel. The final purpose of 802.11x authentication is to check if the port can be used.
300M Wireless-N Access Point Setting Explanation Select SSID ： Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu. 802.1x WEP：Click “Enable/Disable” to enable or disable the WEP algorithm. Radius Server：Enter the IP address of the Radius server. Radius Server Port ： Enter the authentication port of the Radius server. The default is 1812. Shared Secret：Enter the shared key for authentication server with 8~63 ASCII characters.
300M Wireless-N Access Point 4.1.2 P2P (Point to Point) Bridge Mode Two wired local networks communicate and share network resource via two W300A’s wireless signals which also can extend the wired network. In this mode, AP can not connect with wireless clients, but serve as wireless bridge. 4.1.2.1 Application Plan P2P bridge mode can connect with two wired network via wireless access points, which communicate by wireless signals and not by cables. This mode can free from the cable trouble.
300M Wireless-N Access Point z Basic wireless Settings Network Mode：Select one mode from the following. The default is 11b/g/n mode. 11b mode：Allow the wireless client to connect with the device in 11b mode at the maximum speed of 11Mbps. 11g mode：Allow the 11g/11n-compliant client device to connect with the AP at the maximum speed of 54Mbps.
300M Wireless-N Access Point client device to connect with the AP with auto-negotiation speed, and 11n wireless client to connect the device with 11g speed. 11b/g/n mode：Allow 11b/g/n-compliant client device to connect with the AP with auto- negotiation speed. Main SSID：SSID (Service Set Identifier) is the unique name of the wireless network. This device has two SSID and the main SSID is necessary. Minor SSID：It is optional.
300M Wireless-N Access Point extension channel range is used in 11n mode. z Wireless Distribution System (WDS)Setting Encryption Type ： Select the data encryption method from WEP, TKIP, AES or NONE. The default is NONE. WEP Encryption Description WEP Key 1~4：Set the WEP key with the format of ASCII and Hex. You can enter ASCII code (5 or 13 ASCII characters. Illegal character as “/” is not allowed.) Or 10/26 hex characters.
300M Wireless-N Access Point characters with 8-63 ASCII characters. AP MAC Address：Input the MAC address of remote access point by manual or scan. Open Scan：Enable scan to obtain remote AP MAC address, select one and Click “Save” to complete this part’s setting. The AP will reboot automatically, the setting will go into effect. Note: In this mode, the two devices should keep the same channel method.
300M Wireless-N Access Point 4.1.3 P2MP Bridge Mode The P2MP Bridge Mode which connects scattered wired network together is more complicated than P2P Bridge mode. P2MP usually transmit wireless signals from one access point, and other access points are in charge of receiving signals so as to share network resource. Support up to 4 remote access point connection. In this mode, wireless clients are not allowed to connect. 4.1.3.
300M Wireless-N Access Point least two wireless APs are needed. For better performance, it is recommended to use the AP with same model. 4.1.3.2 P2MP Setting In the working mode, select “P2MP Bridge” to enter the next screen.
300M Wireless-N Access Point Network Mode：Select one mode from the following. The default is 11b/g/n mode. 11b mode：Allow the wireless client to connect with the device in 11b mode at the maximum speed of 11Mbps. 11g mode：Allow the 11g/11n-compliant client device to connect with the AP at the maximum speed of 54Mbps. 11b/g mode：Allow the 11b/g-compliant client device to connect with the AP with auto-negotiation speed, and 11n wireless client to connect the device with 11g speed.
300M Wireless-N Access Point wireless network. In IEEE802.11, BSSID is the MAC address of wireless access point. Channel：Specify the effective channel (from 1 to 13\Auto) of the wireless network. Extension channel：To increase data throughput of wireless network, the extension channel range is used in 11n mode. z Wireless Distribution System (WDS)Setting Encryption Type ： Select the data encryption method from WEP, TKIP, AES or NONE. The default is NONE.
300M Wireless-N Access Point AES Encryption Description Pass Phrase ： Enter the encrypted characters with 8-63 ASCII characters. AP MAC Address：Input the MAC addresses (no more than four) of remote access points by manual or scan.
300M Wireless-N Access Point 4.1.4 Wireless Repeater Mode Repeater Mode can repeat and amplify wireless signals to extend wireless network coverage. In this mode, wireless clients are allowed to connect. 4.1.4.1 Application and Topology Plan When two LAN’s transmission distance is over the wireless device’s maximum transmission value, or there is much block among devices, you can use the Repeater mode to deal with these problems by adding MAC addresses. The topology shows below: 4.1.4.
300M Wireless-N Access Point z Basic wireless Settings Network Mode：Select one mode from the following. The default is 11b/g/n mode. 11b mode：Allow the wireless client to connect with the device in 11b mode at the maximum speed of 11Mbps. 11g mode：Allow the 11g/11n-compliant client device to connect with the AP at the maximum speed of 54Mbps.
300M Wireless-N Access Point 11b/g mode：Allow the 11b/g-compliant client device to connect with the AP with auto-negotiation speed, and 11n wireless client to connect the device with 11g speed. 11b/g/n mode：Allow 11b/g/n-compliant client device to connect with the AP with auto- negotiation speed. Main SSID：SSID (Service Set Identifier) is the unique name of the wireless network. This device has two SSID and the main SSID is necessary. Minor SSID：It is optional.
300M Wireless-N Access Point adapter, and configure PC1 and PC2 in the same segment. After the feature is enabled, two PCs can not communicate and share network resource each other, but they can communicate with wireless clients connected with AP2. This feature is to isolate the communication of wireless clients connected with the same SSID. AP Isolation: One access control feature based on wireless MAC address.
300M Wireless-N Access Point wireless client's communication, please enable MBSSID AP and AP Isolation simultaneously. BSSID：Basic Service Set Identifier of wireless network. In IEEE802.11, BSSID is the MAC address of wireless access point. Channel：Specify the effective channel (from 1 to 13\Auto) of the wireless network. Extension channel：To increase data throughput of wireless network, the extension channel range is used in 11n mode.
300M Wireless-N Access Point encryption method from WEP, TKIP, AES or NONE. The default is NONE. WEP Encryption Description WEP Key 1~4：Set the WEP key with the format of ASCII and Hex. You can enter ASCII code (5 or 13 ASCII characters. Illegal character as “/” is not allowed.) Or 10/26 hex characters. Default Key：Select one key from the four configured keys as the current available one. TKIP Encryption Description Pass Phrase ： Enter the encrypted characters with 8-63 ASCII characters.
300M Wireless-N Access Point MAC Address 2：Input AP2’s MAC address; MAC Address 3：Input AP3’s MAC address; MAC Address 4：Input AP4’s MAC address; Open Scan：Enable scan to obtain remote AP MAC address, select one and Click “Save” to complete this part’s setting. The AP will reboot automatically, the setting will go into effect. Note: 1. in this mode, the two devices should keep the same channel and encryption method. 2.
300M Wireless-N Access Point 4.1.5 Wireless Client Mode In this mode, connect the device’s LAN port to wired network adapter port. In this case, AP is used as a wireless Adapter. When you select this mode, please keep the device and the connecting network in the same segment. 4.1.5.
300M Wireless-N Access Point 4.1.5.2 Client Mode Settings In the working mode, select “Client” to enter the next window. Security Mode：Select wireless encryption method from WEP, WPA-PSK and WPA2- PSK (Note: when you select “NONE”, the security mode is disabled.). WEP Encryption Description WEP Type：Select the connected device’s WEP authentication method. OPEN and SHARED is supported.
300M Wireless-N Access Point format of ASCII and Hex. You can enter ASCII code (5 or 13 ASCII characters. Illegal character as “/” is not allowed.) Or 10/26 hex characters. Default Key：Select one key from the four configured keys as the current available one. WPA-PSK Encryption Description WPA-WPA2 Algorithms：Select one from TKIP and AES. Pass Phrase ： Enter the encrypted characters with 8-63 ASCII characters.
300M Wireless-N Access Point Open Scan：Enable scan to obtain remote AP MAC address. Select one and Click “Save” to complete this part’s setting. The AP will reboot automatically, and then the setting will go into effect.
300M Wireless-N Access Point 4.2 Advanced Settings This section mainly deals with wireless advanced settings, including Speed, Beacon Interval, Fragment Threshold, etc. Select “Wireless Setting->Advanced Setting” to enter the following screen: Setting Explanation： BG Protection Mode：For 11b/g wireless client, it is easier to connect with 11n wireless device. The default is “Auto”.
300M Wireless-N Access Point default value is (1-2-5.5-11Mbps…). It is recommended not to modify the default value. Beacon Interval：The frequency interval of the beacon, which is a packet broadcast by an AP to synchronize a wireless network. The default value is 100 ms. Fragment Threshold ： The fragmentation threshold defines the maximum transmission packet size in bytes. The packet will be fragmented if the arrival is bigger than the threshold setting. The default size is 2346 bytes.
300M Wireless-N Access Point 4.3 WPS Settings WPS (Wi-Fi Protected Setting) can be easy and quick to establish the connection between the wireless network clients and the device through encrypted contents. The users only enter the PIN code or the WPA button on the front panel to configure it without selecting encryption method and secret keys by manual. In the “Wireless settings” menu, click “WPS settings” to enter the next screen.
300M Wireless-N Access Point WPS mode ： Provide two ways: PBC (Push-Button Configuration) and PIN code. PBC：Select the PBC or press the WPS button on the front panel of the device for about one second (Press the button for about one second and WPS indicator will be blinking for 2 minutes, which means the WPS is enabled. During the blinking time, you can enable another device to implement the WPS/PBC negotiation between them. At present, the WPS only supports up to 32 clients access.
300M Wireless-N Access Point 4.4 Access Control To secure your wireless LAN, the wireless access control is actually based on the MAC address management. Select “Wireless Setting->Access Control” to display the following screen: Setting Explanation MAC Address Filter ： Enable/disable MAC address filter.
300M Wireless-N Access Point to finish the MAC add operation. MAC list： Show the added MAC address. You can add or delete them. Note: This AP can support no more than 32 MAC addresses.
300M Wireless-N Access Point 4.5 Connection Status This page shows wireless client’s connection status, including MAC address, Channel bandwidth, etc. Select “Wireless Setting->connection status” to enter the following screen: Explanation： MAC Address：Shows current connecting host’s MAC address. Bandwidth：Shows current connecting host’s (wireless client) bandwidth (20MHz or 40MHz).
300M Wireless-N Access Point 4.6 PING Ping is used to check device’s connectivity. If the connecting device has established connection with AP, the result will show “connected”, otherwise, shows “destination host unreachable”. Select “Wireless Setting->Ping” to show the following window: Explanation： IP Address：Enter the device’s IP address. ping ： Click “Diagnose” button to show connectivity result after a few seconds.
300M Wireless-N Access Point Chapter 5 SNMP Setting 5.1 SNMP Introduction Simple Network Management Protocol (SNMP) is a popular protocol for network management. It is widely used in local area networks (LAN) for collecting information, and managing and monitoring, network devices, such as servers, printers, hubs, switches, and routers from a management host.
300M Wireless-N Access Point 5.2 SNMP Setting This device supports SNMP v1 and SNMP v2c. Please click “SNMP Setting” in the left page to enter the following window: Click “enable” or “disable” to enable and disable SNMP management. Setting Explanation： Contact：Set the name to access the AP. Usually set the administrator’s name. Device Name：Set the AP’s name, such as Location：Set the AP’s network location. Read Community: Indicates the community Tenda_300A.
300M Wireless-N Access Point SNMP information. The default is Public. Read/Write Community: Indicates the community read/write access string to permit reading and re-writing this AP’s SNMP information. The default is Private.
300M Wireless-N Access Point Chapter 6 System Tools This section focuses on how to maintain AP, including Restore to Factory Default Setting, Backup/Restore, Firmware Upgrade, Reboot, Password Change, Syslog. 6.1 Password Change This section is to set a new user name and password to better secure your device and network. Click “Apply” to finish changing password. User Name: Enter a new user name for the device. Old Password: Enter the old password.
300M Wireless-N Access Point New Password: Enter a new password. Re-enter to Confirm: Re-enter to confirm the new password. NOTE: It is highly recommended to change the password to secure your network and the device. 6.2 Restore to Factory This button is to reset all configurations to the default values. It means the device will lose all the settings you have set. Restore: Click this button to restore to default settings. Factory Default Settings: User Name: admin Password: admin IP Address: 192.168.0.
300M Wireless-N Access Point 6.3 Backup/Restore The device provides backup/restore settings, so you need set a directory to keep these settings. Backup: Click this button to back up the device’s configurations. Browse: Click this button to browse the directory where you backup or save the device’s settings. Restore: Click this button to restore the device’s configurations.
300M Wireless-N Access Point 6.4 Time Settings This section is to select the time zone for your location. You can select your own time or obtain the standard GMT time from Internet. Setting Explanation： Time Zone: Select your time zone from the drop-down menu. Customized time: Enter the time you customize.
300M Wireless-N Access Point 6.5 Reboot System This page is used to reboot wireless access point. Rebooting the device makes the settings configured go into effect. Reboot: Click this button to reboot the device. 6.6 Firmware Upgrade The device provides the firmware upgrade by clicking the “Upgrade” after browsing for the firmware upgrade packet which you can download from www.tenda.cn. After the upgrade is completed, the device will reboot automatically.
300M Wireless-N Access Point Upgrade Steps： 1. Download the higher firmware version from our website: www.tenda.cn. 2. Extract the firmware file on your computer. 3. On the Firmware Upgrade screen, enter the location directory of the firmware file in the field provided, or click the Browse button and find the file. 4. Click Upgrade button, and follow the on-screen instructions. 5. After the upgrade is completed, the device will reboot automatically.
300M Wireless-N Access Point 6.7 Syslog The section is to view the system log. Click the “Refresh” to update the log. Click “Clear” to clear all shown information. If the log is over 150 records, it will clear them automatically. Refresh: Click this button to update the log. Clear: Click this button to clear the current log.
300M Wireless-N Access Point Appendix I: Glossary Access Point(AP): Any entity that has station functionality and provides access to the distribution services, via the wireless medium(WM) for associated stations.
300M Wireless-N Access Point this setting is the same for all devices in your wireless network. WEP: Wired Equivalent Privacy (WEP) is the method for secure transmission. encryption to transmitted network. wireless data WEP adds data every single packet in The the 40bit wireless and 64bit encryption are the same because of out 64 bits, 40 bits are private. Conversely, 104 and 128 bit are the same. WEP uses a common KEY to encode the data.
300M Wireless-N Access Point product use different method for key generation, it might not work for different products. Therefore, it is NOT recommend using. WPA/WPA2: A security protocol for wireless networks that builds on the basic foundations of WEP. It secures wireless data transmission by using a key similar to WEP, but the added strength of WPA is that the key changes dynamically. The changing key makes it much more difficult for a hacker to learn the key and gain access to the network.
300M Wireless-N Access Point Appendix II: TCP/IP Address Setting (Take Winxp as example) Click the “Start—>Settings—>Control Panel” (Fig- 1): Click “Network and Internet Connections”, windows as below will appear (Fig- 2): Click the “Network Connections”, as Fig-3: 74 the
300M Wireless-N Access Point Choose “Local Area Connection”, right-click on the icon, choose the “Properties”, then the “Local Area Connection Properties”windows appear, choose the “Internet Protocol (TCP/IP)” in the “This connection uses the following items”, click the “Properties”.
300M Wireless-N Access Point Choose the “Use the following IP address”, enter the IP address as: 192.168.0.xxx. (xxx ranges 1~253), Subnet mask is: 255.255.255.0(As Showed in Fig- 5) Click “OK” to apply and return to the “Local Area Connection Properties” windows. Continue click “OK” to exit the setting windows.
300M Wireless-N Access Point FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable interference in a protection residential against harmful installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
300M Wireless-N Access Point -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). “The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
300M Wireless-N Access Point Caution! The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment. Canada Statement This Device complies with RSS-210 of the IC Rules; Operation is subject to the following two conditions: (1). This device may not cause interference and (2).
