Table 2-1 Description of SC700 General View
“Red” color Reading barcode 1 Scanner LED Indicator
“Green” color Successful reading
“Red” color Charging battery 2 Charge LED Indicator
“Green” color Battery charged full
3 LCM / Touch Panel Do specific action through touch panel by stylus
4 Left Scan key
Right Scan key
Scan key
Start scanning the barcode by pressing any one of
these three scan keys
5 Power key Puts the terminal into and wakes the terminal from
suspend mode.
6 F1 ~ F4 key The four application keys, hot keys of application
program defined by end user.
7 Navigation key Navigation keys for left, right, up and down
directions
8 Alpha-Numeric keys Numeric keys, Change to Alpha keys after pressing
Alpha key.
9 Alpha key Toggle Alpha-mode for Alpha-Numeric keys
10 Fn key This key is used in combination with other keys to
type special characters and perform system functions.
11 Enter key This key confirms data entry
12 Earphone Jack
Connector
A connector to plug a earphone
13 USB / Serial /
Synchronization port
A connector to support USB Host/Client and serial
functions
14 Scan window A window for scanning of barcode reader
15 Stylus Use the stylus for selecting items and entering
information.
16 Battery Cover Protect Battery pack, keep the switch of battery cover
to leave system from suspend mode
17 Battery cover Latch To keep Battery Cover locked
18 Hand Strap This strap can be sealed tighter or looser
19 Speaker 1W speaker for audio sound
20 DC Power Jack A connector to support AC power.
21 End Cap Protect CF slot and SD slot from dust and water
