Congratulations! You have bought a great, innovative product from Showtec. The Showtec Shogun DJ RG-100 brings excitement to any venue. Whether you want simple plug-&-play action or a sophisticated DMX show, this product provides the effect you need. You can rely on Showtec, for more excellent lighting products. We design and manufacture professional light equipment for the entertainment industry. New products are being launched regularly. We work hard to keep you, our customer, satisfied.
Showtec Showtec Shogun DJ RG-100™ Product Guide Warning..…...................................................................................………………………………………….. Safety-instructions………………………………………………………………………………………….…. Operating Determinations……………………………………………………………………………………. Rigging…………………………………………………………………………………………………………. 2 2 4 5 Description..…..............................................................................……….………………………………… Features and Overview ………………………………...….……………….………….………………….….
WARNING CAUTION ! EYEDAMAGES !!! NEVER LOOK DIRECTLY INTO THE LIGHTSOURCE !!! NEVER PROJECT A SINGLE LASER POINT !!! CAUTION! Keep this device away from rain and moisture! Unplug mains lead before opening the housing! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! SAFETY INSTRUCTIONS Every person involved with the installation, operation and maintenance of this device has to: be qualified follow the instructions of this manual CAUTION! Be careful with your opera
• • • • • • • • • • • • • • • • • • • • • • • • • • Never leave any cables lying around. Do not insert objects into air vents. Do not connect this device to a dimmerpack. Do not switch the device on and off in short intervals, as this would reduce the lamp’s life. Do not shake the device. Avoid brute force when installing or operating the device. Only use device indoor, avoid contact with water or other liquids. Only operate the device after having familiarized with its functions.
Product Classification and Manufacturing Label Identification Laser Classification: Class IIIB Laser medium: wavelength 532 nm / Green wavelength 650 nm / Red Output: 100mW (60mW Red/ 40mW Green) Cooling: TE Cooling CAUTION: The use of corrective eye wear or optics for viewing at distances such as telescopes or binoculars within a distance of 100mm may pose an eye hazard. This laser product is a Class IIIB laser and has an Interlocked housing. There are no user serviceable parts inside.
Rigging Please follow the European and national guidelines concerning rigging, trussing and all other safety issues. Do not attempt the installation yourself ! Always let the installation be carried out by an authorized dealer ! Procedure: • • • • • If the laser is lowered from the ceiling or high joists, professional trussing systems have to be used. Use a clamp to mount the laser, with the mounting-bracket, to the trussing system. The laser must never be fixed swinging freely in the room.
Description of the device Features The Showtec Shogun DJ RG-100 is a laser effect with a high output and great effects. • 60 mW red laser (650nm) • 40 mW green laser (532nm) • DMX-control via standard DMX-controller • 100 pre-programmed effects • 8 DMX-control channels required • Sound-controlled via built-in microphone • Fuse 2A / 250V Overview Fig. 1 Frontside Fig.
Backside Fig. 3 6) Dip Switches 7) Remote Interlock Connector 8) Sound Sensitivity control 9) Key System 10) Power ON/OFF 11) DMX signal connector (OUT) 12) IEC Power Connector / Fuse 2A / 250V 13) DMX signal connector (IN) Remote Interlock Connector: Use a DB9 connector to connect to the Remote Interlock, which stops the beam being emitted once the connection loop has been opened.
One Shogun DJ RG-100 (Stand-alone) There are 4 possibilities: Stand Alone Sound-active mode (Master) Auto Mode (Master) DMX 1. Fasten the Shogun onto firm trussing. Leave at least 0,5 meter on all sides for air circulation. 2. Plug the cord into a proper electric power supply socket.
Multiple Shoguns DJ RG-100 (DMX Control) 1. Fasten the effect light onto firm trussing (Use a 30-kg rated or stronger C-clamp bolted onto the Showtec Shogun bracket). Leave at least 0,5 meter on all sides for air circulation. 2. Use a 3-p XLR cable to connect the Shoguns and other devices. The pins: 1. 2. 3. Earth Signal Signal + 3. Link the units as shown in (figure 4), Connect a DMX signal cable from the first unit's DMX "out" socket to the second unit's "in" socket.
DMX Dip Switch Setting DMX products must have their own "address" to receive DMX signals. Addresses on the Showtec Shogun DJ RG-100 are set by flipping the appropriate DMX dip switches. A standard DMX address for a Showtec Shogun DJ RG-100, which has 8 channels is as follow: Shogun DJ RG-100 Unit 1 Unit 2 Unit 3 Unit 4 Address Value 1 9 17 25 DMX Dip Switches "ON" #1 and for DMX # 10 and # 12. #1, #4 and for DMX # 10 and # 12. #1, #5 and for DMX # 10 and # 12. #1, #4, #5 and for DMX # 10 and # 12.
DMX Address Quick Reference Chart Dip Switch Position DMX DIP SWITCH SET #9 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0=OFF #8 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1 1=ON #7 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 #6 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 #1 #2 #3 #4 #5 0 0 0 0 0 32 64 96 128 160 192 224 256 288 320 352 384 416 448 480 1 0 0 0 0 1 33 65 97 129 161 193 225 257 289 321 353 385 417 449 481 0 1 0 0 0 2 34
DMX Channels Channel 1 –Mode 0-10 11-120 121-250 251-255 Laser Off Dynamic Patterns Static Patterns Reset Channel 2 –Pattern Selection 0-255 Num n Static / Dynamic Channel 3 –X-Position 0-255 Adjust X-Position Channel 4 –Y-Position 0-255 Adjust Y-Position Channel 5 –Scanning Speed 0-255 From Fast (0) to Slow (255) Channel 6 –Dynamic Pattern Play Speed 0-255 From Fast (0) to Slow (255) Channel 7 –Static Patterns Pattern Size 0-255 From Fast (0) to Slow (255) Channel 8 –Color Selection 0-101 102
Maintenance The Showtec Shogun DJ RG-100 requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Carefully wipe both mirrors clean with glass cleaner and a soft cloth. Do not use alcohol or solvents. The mirrors will require regular cleaning, as smoke-fluid tends to build up residues, reducing the lightoutput quickly.
Product Specification Model: Showtec Shogun DJ RG-100 Voltage: 240V-50Hz (CE) Fuse: 2A / 250V Dimensions: 390x285x135mm (LxWxH) Weight: 5 kg Operation and Programming DMX Channels: 8 Signal input 3-pin XLR male Signal output 3-pin XLR female DMX-control via standard DMX-controller Laser 60 mW red Laser (650nm) 40 mW green Laser (532nm) Minimum distance: Minimum distance from flammable surfaces: 0.5m Minimum distance to lighted object: 0.
