Data Sheet

Data sheet 3TH4262-0BG8

Contactor relay, 62E, DIN EN 50011, 6 NO + 2 NC, screw terminal

DC operation 90 V-140 V DC

Product designation Auxiliary contactor

Product type designation 3TH4

Size of contactor 0

Protection class IP on the front IP20

Reference code acc. to DIN 40719 extended

according to IEC 204-2 acc. to IEC 750

Reference code acc. to DIN EN 81346-2 K

Reference code acc. to DIN EN 61346-2 K

Type of voltage of the control supply voltage DC

Control supply voltage at DC

● rated value

110V

● rated value

90...140V

Number of NC contacts for auxiliary contacts 2

● delayed switching

● lagging switching

● make-before-break switching

Number of NO contacts for auxiliary contacts 6

● delayed switching

● leading contact

3TH4262-0BG8 Subject to change without notice

Page 1/

PAGE 1
Data sheet 3TH4262-0BG8 Contactor relay, 62E, DIN EN 50011, 6 NO + 2 NC, screw terminal DC operation 90 V-140 V DC Product designation Auxiliary contactor Product type designation 3TH4 Size of contactor 0 Protection class IP on the front IP20 Reference code acc. to DIN 40719 extended according to IEC 204-2 acc. to IEC 750 K Reference code acc. to DIN EN 81346-2 K Reference code acc.
PAGE 2
● make-before-break switching 0 Number of CO contacts for auxiliary contacts 0 Identification number and letter for switching elements 62 E Operating current at AC-15 ● at 230 V rated value 10 A ● at 400 V rated value 6A Mounting type screw and snap-on mounting onto 35 mm standard mounting rail according to DIN EN 50022 Height 78 mm Width 45 mm Depth 135 mm Type of electrical connection for auxiliary and control current circuit screw-type terminals B10 value with high demand rate acc.
