Data Sheet

Data sheet 5TD4706

DELTA flaeche IP44, AP Dark gray/light gray button, 10A 250V with

separate feedback signal with white window, 66x 75 mm

Model

Product brand name DELTA

Design of the product single pushbutton

Design of the switching function 1 NO contact

Type of composition basic element with complete enclosure

Design of the operating mechanism pushbutton/momentary pushbutton

General technical data

Printed marking Other

Mounting type fixing with screw

Surface processing others

Material others

Supply voltage

Operating voltage / Rated value 230V

Protection class

Protection class IP IP44

Switching capacity

Switching capacity current 10A

5TD4706 Subject to change without notice

Page 1/

PAGE 1
Data sheet 5TD4706 DELTA flaeche IP44, AP Dark gray/light gray button, 10A 250V with separate feedback signal with white window, 66x 75 mm Model Product brand name DELTA Design of the product single pushbutton Design of the switching function 1 NO contact Type of composition basic element with complete enclosure Design of the operating mechanism pushbutton/momentary pushbutton General technical data Printed marking Other Mounting type fixing with screw Surface processing others Material o
PAGE 2
Main circuit Operating current / rated value 10 A Appearance Appearance shiny Color grey Product details Product component ● Labeling field No ● Integrated / Light source Yes ● Signaling contact Yes Product feature ● halogen-free Yes ● transparent No Number Number of actuating rockers 1 Mechanical Design Height 75 mm Width 66 mm Depth 54 mm Mounting type surface mounted Material / of the enclosure plastic Certificates General Product Approval Declaration of Conformity Test Cert
