Data Sheet

Data sheet 6AG1124-0JC01-4AX0
SIPLUS HMI TP900 Comfort for medial exposure with conformal
coating based on 6AV2124-0JC01-0AX0
General information
Product type designation TP900 Comfort
Display
Design of display TFT
Screen diagonal 9in
Display width 195mm
Display height 117mm
Number of colors 16777216
Resolution (pixels)
● Horizontal image resolution
800Pixel
● Vertical image resolution
480Pixel
Backlighting
● MTBF backlighting (at 25 °C)
80000h
● Backlight dimmable
Yes; 0-100 %
Control elements
Keyboard fonts
