Data Sheet

Data sheet 6AG1193-6AP00-2AA0

SIPLUS ET 200SP -40...+60°C start up -25°C with conformal coating

based on 6ES7193-6AP00-0AA0 . Bus Adapter BA 2xSCRJ, 2 SCRJ

FO connections, for PROFINET

General information

Product type designation BA 2xSCRJ

Interfaces

Number of PROFINET interfaces 1; 2 ports (switch) SCRJ FO

Supports protocol for PROFINET IO

● Number of SCRJ ports

Cable length

— PCF

100m

— Plastic FOC (POF)

50m

— PCF-GI

250m

Ambient conditions

Ambient temperature during operation

● min.

-40°C; = Tmin (incl. condensation/frost); start-up @ -25 °C

● max.

60°C; = Tmax

Altitude during operation relating to sea level

● Installation altitude above sea level, max.

5000m

6AG1193-6AP00-2AA0 Subject to change without notice

Page 1/

PAGE 1
Data sheet 6AG1193-6AP00-2AA0 SIPLUS ET 200SP -40...+60°C start up -25°C with conformal coating based on 6ES7193-6AP00-0AA0 . Bus Adapter BA 2xSCRJ, 2 SCRJ FO connections, for PROFINET General information Product type designation BA 2xSCRJ Interfaces Number of PROFINET interfaces 1; 2 ports (switch) SCRJ FO Supports protocol for PROFINET IO ● Number of SCRJ ports 2 Cable length — PCF 100 m — Plastic FOC (POF) 50 m — PCF-GI 250 m Ambient conditions Ambient temperature during operation ● min.
PAGE 2
● Ambient air temperature-barometric pressurealtitude Tmin ... Tmax at 1 140 hPa ... 795 hPa (-1 000 m ... +2 000 m) // Tmin ... (Tmax - 10 K) at 795 hPa ... 658 hPa (+2 000 m ... +3 500 m) // Tmin ... (Tmax -20 K) at 658 hPa ... 540 hPa (+3 500 m ... +5 000 m) Relative humidity ● With condensation, tested in accordance with IEC 60068-2-38, max. 100 %; RH incl.
PAGE 3
● Qualification and Performance of Electrical Insulating Compound for Printed Board Assemblies according to IPC-CC-830A Yes; Conformal coating, Class A Dimensions Width 20 mm Height 69.5 mm Depth 59 mm Weights Weight, approx.
