Data Sheet

Data sheet 6ES7131-4EB00-0AB0
SIMATIC DP, 5 electronic modules for ET 200S, 2 DI 120 V AC 15
mm width, 5 units per packing unit
Supply voltage
Rated value (AC)
● 120 V AC
Yes; From power module
Input current
from supply voltage L1, max. Dependent on encoder
from backplane bus 3.3 V DC, max. 6mA
Power loss
Power loss, typ. 0.5W
Address area
Address space per module
● Address space per module, max.
1byte
● with packing
2bit
Digital inputs
Number of digital inputs 2
Input characteristic curve in accordance with IEC
61131, type 1
Yes
6ES7131-4EB00-0AB0 Subject to change without notice
Page 1/
3
09/16/2019 © Copyright Siemens
