Data sheet 6ES7193-6BP00-0BA1
SIMATIC ET 200SP, BaseUnit BU15-P16+A0+2B/T, BU type A1,
Push-in terminals, without AUX terminals, bridged to the left, WxH:
15x 117 mm, with temperature acquisition
General information
Product type designation BU type A1
HW functional status FS10 and higher
Supply voltage
Rated value (DC) 24V
external protection for power supply lines Yes; 24 V DC/10 A miniature circuit breaker with type B or C
tripping characteristic
Current carrying capacity
For P1 and P2 bus, max. 10A
For process terminals, max. 2A
Hardware configuration
Temperature sensor Yes
Formation of potential groups
● New potential group
No
● Potential group continued from the left
Yes
Isolation
Isolation tested with 707 V DC (type test)
