Data Sheet

Data sheet 6ES7954-8LL03-0AA0

SIMATIC S7, MEMORY CARD FOR S7-1X00 CPU, 3,3 V FLASH,

256 MBYTE

General information

Product type designation SIMATIC Memory Card

Memory

Type of memory Flash-EPROM

Flash Yes

Memory size 256Mbyte

Number of write/delete operations, min. 200000

Data retention (after final programming action), min. 10y; If the delete/write processes < 20 000 (1 a if the delete/write

processes > 180 000)

Dimensions

Width 24mm

Height 32mm

Depth 2.1mm

Weights

Weight, approx. 3g

6ES7954-8LL03-0AA0 Subject to change without notice

Page 1/

PAGE 1
Data sheet 6ES7954-8LL03-0AA0 SIMATIC S7, MEMORY CARD FOR S7-1X00 CPU, 3,3 V FLASH, 256 MBYTE General information Product type designation SIMATIC Memory Card Memory Type of memory Flash-EPROM Flash Yes Memory size 256 Mbyte Number of write/delete operations, min. 200 000 Data retention (after final programming action), min. 10 y; If the delete/write processes < 20 000 (1 a if the delete/write processes > 180 000) Dimensions Width 24 mm Height 32 mm Depth 2.1 mm Weights Weight, approx.
