BA Cover A57 sw.QXD 13.05.2004 13:30 Uhr Seite 1 s s mobile mobile Issued by Information and Communication mobile Haidenauplatz 1 D-81667 Munich © Siemens AG 2004 All rights reserved. Subject to availability. Rights of modification reserved. Siemens Aktiengesellschaft www.siemens-mobile.
right page (1) of A57 Jaguar, short, en A31008-H5830-A1-2-7619 (24.06.2004, 06:22) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\JaguarIVZ.fm Contents This is a short version of the operating instructions. You can down load the detailed version from the Internet at: www.siemens-mobile.com/a57 Safety precautions ............................. 2 Overview of the phone ...................... 3 Display symbols (selection) ................ 5 Getting Started .......
left page (2) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:22) Safety precautions Safety precautions Information for parents Please read the operating instructions and safety precautions carefully before use. Explain the content and the hazards associated with using the phone to your children. Remember to comply with legal requirements and local restrictions when using the phone. For example in aeroplanes, petrol stations, hospitals or while driving.
right page (3) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:22) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Overview.fm Overview of the phone 1 Integrated antenna Do not interfere with the phone above the battery cover unnecessarily. This reduces the signal strength. 2 3 Loudspeaker Display indicators Signal strength/battery level.
left page (4) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:22) Overview of the phone 1 Scroll key In lists and menus: G Scroll up and down. During a call: G Volume adjustment. In standby mode: E F Press at the top: read new message. Press at the bottom: open Phonebook. Edit Text: G G Short press at top or bottom: Move cursor character by character. Long press at top or bottom: Move cursor word by word. Read Text (e.g. SMS): G Scroll line by line.
right page (5) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:22) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_DisplaySymbols.fm Display symbols (selection) Display indicators _ h d n j k l y µ ¢ ¡ v ² p,o Q Signal strength. Charging. Battery level. All calls are diverted. Ringer off. Short ringer (beep) only. Ringer only, if the caller is stored in the Phonebook. Alarm clock active. Key lock active.
blank page (6) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Getting Started Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Main.fm Getting Started The front and back covers of the phone and the keypad (CLIPit™ Covers, my-CLIPit™: p. 31) can be changed in seconds – no tools required. Please switch the phone off first.
right page (7) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) o n Press latch in the direction indicated by the arrow p, lift battery at the cutout on the side of the phone, then tilt upwards and remove q. p t Replace cover and press downwards until it engages. Always switch off phone before removing the battery! Only 3V SIM cards are supported. Please contact your service provider if you have an older card. Charge battery The battery is not fully charged when delivered.
left page (8) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Switch on/off, PIN entry this range). The voltage specified on the power supply unit must not be exceeded. To use the full performance of the battery, the battery must be fully charged and discharged at least five times. Charge icon not visible If the battery is totally discharged no charge icon is displayed when the charger is plugged in. It is displayed after 2 hours at most.
right page (9) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Main.fm Security The phone and SIM card are protected against misuse by several security codes. Keep these confidential numbers in a safe place where you can access them again if required. §Menu§ ¢ Setup ¢ Security ¢ Select a function: PIN control The PIN is usually requested each time the phone is switched on.
left page (10) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Making a phone call When a number is busy For automatically dialling the phone number for up to 15 minutes at increasing intervals, press §Auto dial§ . For phone ringing when the busy number is free, press §Call back§ ( L ). Press §Prompt§ and a beep will remind you to redial the dispayed phone number after 15 minutes. Accept call The phone must be switched on (standby mode).
right page (11) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Main.fm All calls in the conference are ended simultaneously when the End key B is pressed. Additional costs will be incurred for every additional phone connection.
left page (12) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) 1 Phonebook Writes blank. Press twice = skip line. Call/search for an entry Open PhonebookF, select name by typing first letter or scroll and dial withA. Call with record no. A record number is automatically assigned to every new entry in the Phonebook. J Enter record number (in standby mode) ¢ ¢ A Edit entry G ¢ Select entry ¢ §Options§ ¢ Edit ¢ G (select required input field) ¢ Make changes ¢ §Save§ .
right page (13) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Main.fm Change group assignment You can assign a Phonebook entry to a group when you enter it (p. 11). F ¢ Select entry ¢ §View§ ¢ §Edit§ ¢ G(scroll to group) ¢ §Change§ ¢ Select a new goup ¢ §Save§ SMS to group A memo (SMS) can be sent as a "circular" to all members of a group.
left page (14) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Voicemail/CB services Charge settings §Menu§ ¢ Call records ¢ Duration/charges ¢ Charge settings Currency (PIN 2 query) Currency for charge display. Personal rate (PIN 2 query) Charges per unit/period. A/c limit b b b (PIN 2 query) Fix a credit/usage period on a special SIM card. §Select§ ¢ Setup (enter PIN 2) ¢ A/c limit ¢ enter number of units ¢ §OK§ Confirm the credit or reset the counter.
right page (15) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Main.fm Receive CB b 15 CB languages You can activate and deactivate the CB service. If activated, the standby time of the phone will be reduced. You may define whether you want to receive Cell Broadcast messages in a specific language only or in all languages. Read new CB Displays o, p Topic activated/deactivated.
left page (16) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Messages (SMS) Compose a message §Menu§ ¢ Messages ¢ New SMS ¢ write text ¢ A ¢ Q / J(enter phone number or select from Phonebook) ¢ §OK§ The SMS is sent to the service centre for transmission. Text menu §Options§ Open the text menu.
right page (17) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Main.fm 17 Correct a word Predefined text Words created using T9: With G move left or right, word by word, until the required word is §inverted§. With » scroll through the T9 word suggestions again.
left page (18) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Surf & fun Surf & fun Internet browser (WAP) §Menu§ ¢ Surf & fun ¢ Select a function. Get the latest WAP information from the Internet that is specifically adapted to the display options of your phone. In addition, you can download sounds, pictures and animations to your phone via WAP. Internet access may require registration with the service provider.
right page (19) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Setup Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Main.fm §Menu§ ¢ Surf & fun ¢ Games ¢ Setup You can activate and deactivate the following functions for the games: Sounds, Illumination, Silent alert Own pictures/Own animations §Menu§ ¢ Surf & fun ¢ Own animations or ¢ Own pictures Set animations, logos and screensavers as required in your phone.
left page (20) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Profiles Profiles §Menu§ ¢ Profiles Several settings can be stored in a phone profile in order, for example, to adapt the phone to the surrounding level of noise. • Five profiles are standard with default settings, they can be changed however: Normal environment, Quiet environment, Noisy environment, Car Kit, Headset • You can set two personal profiles (). • The special profile Aircraft mode cannot be changed.
right page (21) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Main.fm Call waiting b If you are registered for this service, you can check whether it is set and you can activate/deactivate it with Call waiting. Minute beep During the call, you will hear a beep after each minute as a reminder of the time elapsed.
left page (22) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Setup Buddhist year Switch to the Buddhist calendar (not available in all models). Line Security §Menu§ ¢ Setup ¢ Security ¢ Select a function. Network info The list of GSM networks currently available is displayed. Choose network Direct call Only one phone number can be dialled. Press and hold control key on the right. This SIM only b Your phone is prevented from being used with a different SIM card.
right page (23) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Main.fm Master reset §Menu§ ¢ Setup ¢ Master reset Key tones The phone is reset to the default values (does not apply to SIM card and network settings).
left page (24) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:24) Fast access key Fast access key You can program an important phone number or a function on the left soft key. You can program an important phone number on the number keys 2 to 9 (speed dialling numbers). The phone number can then be dialled or the function can be started at the touch of a button. Left soft key Assign a function/phone number to this key. Change (example) §Internet§ ¢ §Change§ ¢ Search for application, e.
right page (25) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:22) 25 Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_FAQ.fm Questions & Answers If you have any questions about using your phone, visit us at www.siemens-mobile.com/customercare anytime. In addition we have listed some frequently asked questions and answers below. Question Possible causes Possible solution Phone cannot On/Off key not pressed long enough.
left page (26) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:22) Questions & Answers Question Possible causes No entries possible in Phone- Phonebook is full. book. Voice mail does not work Call divert to the mailbox not set. SMS (text message) T SMS memory full. flashes. Function cannot be set. Not supported by service provider or registration required. Memory problems with ring- Phone memory full. tones, pictures, SMS.
right page (27) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:28) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Maintenance.fm Customer Care We offer fast, individual advice! You have several options: Our online support on the Internet: www.siemens-mobile.com/customercare We can be reached any time, any place. You are given 24 hour support on all aspects of our products.
left page (28) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:28) Care and maintenance Romania .........................................02 12 04 60 00 Russia..........................................8 80 02 00 10 10 Saudi Arabia .....................................0 22 26 00 43 Serbia .............................................01 13 80 95 50 Singapore ............................................62 27 11 18 Slovak Republic ..............................02 59 68 22 66 Slovenia .........
right page (29) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:28) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Maintenance.fm Battery quality statement The capacity of your mobile phone battery will reduce each time it is charged/ emptied. Storage at too high or low temperatures will also result in a gradual capacity loss.
left page (30) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.
right page (31) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:21) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_Accessories.fm Accessories Energy Li-Ion Battery (700 mAh) EBA-510 Spare battery for additonal standby and talk time. Travel Charger Travel Charger ETC-500 (EU) Travel Charger ETC-510 (UK) Travel charger with an extended input voltage range of 100–240V for international use.
left page (32) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:23) SAR – European Union (RTTE) SAR – European Union (RTTE) INFORMATION ON RF EXPOSURE/SPECIFIC ABSORPTION RATE (SAR) THIS MOBILE PHONE MEETS THE LIMITS SET BY THE EU (1999/519/EC) FOR PROTECTION OF THE HEALTH OF THE PUBLIC FROM THE EFFECTS OF EXPOSURE TO ELECTROMAGNETIC FIELDS These limits are part of comprehensive recommendations for the protection of the public.
right page (33) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:23) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\Jaguar_SAR_en.fm SAR – International (ICNIRP) INFORMATION ON RF EXPOSURE/SPECIFIC ABSORPTION RATE (SAR) THIS MOBILE PHONE MEETS THE LIMITS FOR PROTECTION OF THE HEALTH OF THE PUBLIC FROM THE EFFECTS OF EXPOSURE TO ELECTROMAGNETIC FIELDS Your mobile phone is a radio transmitter and receiver.
left page (34) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:23) Index Index A Accepted calls, call list......................... 13 Accessories ......................................... 31 Account limit ...................................... 14 Aircraft mode, profile.......................... 20 Alarm clock......................................... 23 Alarm tones ........................................ 23 All calls, divert ....................................
right page (35) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:23) Siemens AG 2003, C:\Projekte\Siemens\10210-001\A57\Produkt\A57_sug_v2_en_040519_bw_pk_druck\JaguarSIX.fm G Games ................................................ 18 Getting Started ..................................... 6 Group call to group ................................... 13 SMS to group.................................. 13 Guarantee certificate .......................... 29 H Handsfree function ......................
left page (36) of A57 Jaguar, short, en, A31008-H5830-A1-2-7619 (24.06.2004, 06:23) Index Security codes....................................... 9 Service tones ...................................... 23 Setup call ................................................. 20 Car Kit ............................................ 21 clock .............................................. 21 display............................................ 20 divert ............................................. 21 games ...............
