User Manual

Industry
Building Technologies
Designation
Product line
Siemens Switzerland Ltd.
Building Technologies Division
Gubelstrasse 22
CH-6301 Zug
Management System since by
ISO 14001 (Environment) 06.12.2002 Gerling Cert
ISO 9001 (Quality) 06.11.1989 SQS / VdS
Typical energy consumption 62kWh/a
Maintenance
Fire load 27MJ
20-PAP Corrugated fiber board Folding box 815g
20-PAP Corrugated fiber board Insert 235g
E-por Edge protection 50g
PE Plastic bags 10g
Notes on disposal
Total weight of device 5'542g
The total wei
g
ht of a device ma
y
deviate from the total of the wei
g
hts of all individual com
p
onents due to roundin
g.
PPE / PS Cable cannel L=430 98g
PPE / PS Cable cannel L=300 68g
PVC Flat cable mounting 4g
Steel; zinc plated Shielding plate 1'164g
Steel; zinc plated Shielding cap 222g
Steel; zinc plated Frontpanel to Commmunication card 122g
Steel; zinc plated 19" Supporter 2'125g
Steel; zinc plated Screws, Bolts, Nuts 77g
Steel; zinc plated Shielding cap 273g
Steel; zinc plated Neutral busbar 23g
Steel; zinc plated Schirmanschlussklemme 72g
PA, Cu, CrNi connectors (28p) 90g
PA, Cu, CrNi Adapter PMI to Card Cage CPU 10g
PA, Cu, CrNi Cable set (2p) 20g
PA, Cu, CrNi Cable 158g
FR4; TBBA; solder SnAgCu PCB ass. To Card cage FCC2003 384g
Others
PCBAs (Printed Circuit Board
bl d)
Environmentally compatible
product design
Process control
Product responsibility of Siemens covers the entire product life cycle. Siemens already assesses, avoids and minimizes
the environmental impact of its products with respect to production, procurement, sales, use, services and disposal
durin
g
the product and process plannin
g
phases b
y
compl
y
in
g
Siemens Standard SN 36350 "Environmentall
y
compatibl
e
products".
Metals
Product use
Plastics
Materials
Packaging
FS20
One-way, recyclable
Environmental
Product Declaration
FCC2002-A1 / S54400-B17-A1
Not necessary
Type of equipment /
Product No.
Control unit (19", FC2080)
Product
Building Technologies A5Q00030128D-01-78.xls; 06.12.2011
Page 1/2
Siemens AG Industry Secto
r
