Applications in production halls and warehouses GAMMA building control for economical and future-proof operation Answers for infrastructure.
Contents 2 Successful operation of production halls 04 Efficient building management 05 Economic efficiency pays 06 – 07 Security is of prime importance 08 – 09 Overview of functions 10 – 11 Well conceived in every respect 12 – 13 Offering by a single source 14 – 15
Future-proof solutions We are familiar with the requirements of your working environment and your daily business. On this basis we offer you flexible and powerful support, thanks to proven GAMMA building control, the system that enables you to focus on your customers and their needs.
Successful operation of production halls Using the future-oriented GAMMA building control system, production plants and warehouses can be matched to the needs of their users – energy-efficiently, quickly and at affordable prices. The requirements placed on such facilities are demanding: All sectors shall provide optimum conditions for efficient working processes, ensuring low operating costs, and high levels of economic efficiency.
Efficient building management Economical management of production halls Energy- and cost-efficient operation, preventive protection for people and assets, well conceived and easy-to-use electrical building functions – facility managers who want to benefit from all the advantages offered by advanced building control in production halls opt for GAMMA instabus, the future-oriented system that ensures more economic efficiency, security, and comfort.
Constant light control including the use of daylight ensures that the amount of light provided meets exactly the demand – less light near the windows, more light near the walls. Economic efficiency pays off Complex requirements call for particularly intelligent solutions. For this reason, Siemens offers a universal system, especially developed for the requirements of production halls.
Flexible when usage of space changes GAMMA instabus develops its abilities to the full when usage of space changes. Be it a change of tenants or organizational changes, there is no need for costly rewiring. New parameter settings is all that‘s needed and the various functions and connections are reassigned. This means that expensive downtimes due to reconstruction work or modifications are considerably reduced. If required at a later stage, functions can be straightforwardly extended at affordable prices.
Security is of prime importance In the building infrastructure security plays an important role – to protect people and assets and to avoid damage plus consequential costs. Preventing is better than reacting Corridor lighting is switched depending on demand, which means that it always ensures the right level of brightness. Also, outdoor and pathways lighting can be switched depending on brightness, movement or time, thus ensuring it is always on when needed.
When it comes to safety and security, compromises are inacceptable. With GAMMA instabus, emergency and escape route lighting is easy to implement. The fire alarm system can be integrated into GAMMA instabus: In the event of a fire, the electrical consumers are immediately switched off, escape route lighting is switched on, and the evacuation of elevators is triggered. Efficiency thanks to central visualization Visualization is provided to show all important events.
Overview of functions Interested? Are the described function examples interesting for your production hall project? In the affirmative case, please contact your Siemens partner. He will be pleased to assist you and provide more detailed information.
Economic efficiency se of daylight without glare U (tracking of blinds) Blinds with daylight control Constant light control Lighting depending on presence Corridor lighting depending on presence and main usage times Heating, ventilation, and air conditioning depending on demand Reduced heating when windows are left open “Central off“ for heating, ventilation, and air conditioning Usage changes with no need for rewiring Straightforward extension of functions Wireless plant extensions Efficient b
Well conceived in every respect The economic and energy efficiency plus the convenience of a solution for a specific production hall become apparent when all requirements shall be satisfied. Production hall The link between production lines and offices is established via interfaces, such as Profibus DP, Logo, Desigo Bacnet, as well as Synco KNX. Both lighting and air conditioning can be easily adapted to the respective requirements, for example for reconstruction projects or change of machines.
Lobby Access control for company personnel can be implemented through GAMMA instabus. Garages/underground parking lots In garages or underground parking lots without daylight, lighting is usually controlled depending on main usage times and presence. When people are present, the lighting system can be programmed to ensure full brightness. During absence, lighting is reduced to a minimum, or is completely switched off outside main usage hours. This saves energy costs and extends the lamps‘ life cycle.
Offering by a single source With GAMMA building control, your production hall will meet all requirements in terms of economic efficiency, security, and comfort – today and in the future. 14 Social/sanitary facilities/kitchenettes An extract air system controlled depending on presence and air quality improves the room’s climate and helps save energy. Automatic disconnection of power outlet circuits outside main usage hours increases security and saves costs.
1. Replacement 2. Replacement 3. Replacement 3-sectional switching without with Onetime replacement of all lamps Savings Basic costs of replacement (service visits, order) Cost of lamps Due to even loads on the lamps in the case of “3-sectional switching“, all lamps can be replaced at the same time, thus lowering maintenance costs.
