301

HOTEL SOLUTION™

Hardware overview

HOTEL SOLUTION™

Function Name Type Data sheet

Room control

Room controller

HRC3.1 6313

Room controller

HRC3.2 6314

HRC3.1 HRC3.2

Room operator units

Room operator unit

HTC3.1/A 6319

Room operator unit with built-in sensor

HTC3.1S/A 6319

Room operator unit

HTC3.2 6320

HTC3.1.. HTC3.2/..

Access control

Magnetic card Magnetic card reader

HMR3.1/A 6334

Magnetic card holder

HMH3.1/A 6335

Magnetic card holder with doorbell

HML3.1/A 6335

Magnetic card encoder

HBC1.M 6339

HMR3.1/A HMH3.1/A HBC1.M

Transponder card Transponder card reader

HTR3.1/B 6337

Transponder card holder

HTH3.1/B 6336

Transponder card encoder

HTW3.1/B 6338

HTR3.1/B HTH3.1/B HTW3.1/B

CM2N6301en

01.09.2008

Building Technologies

Summary of content (4 pages)

PAGE 1
6 301 HOTEL SOLUTION™ Hardware overview HOTEL SOLUTION™ Function Name Type Room control Room controller HRC3.1 6313 Room controller HRC3.2 6314 Room operator unit HTC3.1/A 6319 Room operator unit with built-in sensor HTC3.1S/A 6319 Room operator unit HTC3.2 6320 Magnetic card reader HMR3.1/A 6334 Magnetic card holder HMH3.1/A 6335 Magnetic card holder with doorbell HML3.1/A 6335 Magnetic card encoder HBC1.M 6339 HRC3.1 Room operator units Data sheet HRC3.2 HTC3.1..
PAGE 2
Chipcard Chipcard reader HCR3.2/.. 6332 Chipcard holder HCH3.2/.. 6333 Chipcard encoder HCW3.2 6340 HCR3.2/BB Accessories HCH3.2/BB HCW3.2 Temperature sensors HSE1.1, HSE1.2 6221 Adapter and cable set HCS3.2 6355 HSE1.1 HSE1.2 OPC server OPC server – interface for HOTEL SOLUTION room controller HRC3.1 / HRC3.2 HSO3.1 6325 Management software Guest room control system HSW3.
PAGE 3
Front Office System Sample topology PC3: Workspace Front desk Fidelio or Hogatex / Bosch FOS TCP/IP TCP/IP PC1: Database server PC2: Technical workspace (Operate & Monitor) - Database - DGUdriver - User interface - Key client RS232 Encoder2 TCP/IP Encoder1 Building automation and control IP / KNX IP Building autom & control system Siemens Hotel Solution- system RS232 Hotel rooms KNX ... ... RCU...
PAGE 4
Equipment combinations Compatibility of other devices Device Type Operator units QAX84.1/PPS2 Actuators SSB81 SSP81 STP72E STA72E Valves VXP45.10-1.6 VXP47.10-1.6 VDN2.. VPD.. Application HRC3.1 HRC3.2 Description Data sheet Flush-mounted room unit with temperature sensor, setpoint adjustment, Auto/Fan speed button, and LCD display N1649 X Electro-motoric actuator, 200 N, 5.
