Data Sheet for Product

2/8
Siemens CE1N2111en--_-b
Smart Infrastructure 2020-05-11
Type summary
Type reference Description
RTN51 RAL 9016, matt
RTN51G RAL 9016, glossy
RTN71 Version with remote sensor
RTN81 Version with remote adjuster
Adapter type For valve makes Adapter type For valve makes
AV52
1)
Comap AV57 Herz
AV53 Danfoss RA-N (RA2000) AV58 Oventrop < 2002
AV54 Danfoss RAVL AV59
1)
Vaillant
AV55 Danfoss RAV AV60 TA < 2002
AV56 Giacomini AV61 MMA Markaryd
1)
While stocks last
Type reference Description
ATN2 Fitting to prevent dismantling of actuator
Ordering
Valves and accessories are packed separately.
See overview, page 7.
Equipment combinations
Valve type reference Description k
vs
V
&
PN class Data Sheet
[m
3
/h] [l/h]
VDN.., VEN.., VUN.. Radiator valves 0.09…1.4
PN10
2105, 2106
VPD.., VPE.. MCV radiator valves 25…483 2185
For other radiator valves with type AV.. adapters, refer to «Type summary / Accessories»
Radiator valves (M30 x 1.5) from other manufacturers, without adapter:
· Heimeier · Honeywell-Braukmann
· Cazzaniga · MNG
· Junkers · Beulco new
· Oventrop M30 x 1,5 (since 2001)
k
vs
= Nominal flow rate of cold water (5 to 30 °C) through the fully open valve (H
100
) at a differential
pressure of 100 kPa (1 bar)
Technical design / mechanical design
The fluid-filled sensor responds to deviations from the room temperature setpoint.
When the room temperature rises, the fluid inside the metal capsule expands, exerting
pressure on the bellows and the stem, which causes the valve to continuously close so
that the radiator's heat output will be reduced. When the room temperature falls, the
bellows expands, thereby opening the valve so that the radiator's output will be
increased again.
Accessories
Example:
Product number Stock number Description Quantity
RTN51 RTN51 Thermostatic actuator 6
AV57 AV57 Adapter 1
Delivery
Rev. no.
Mode of operation
