Specification Sheet

ManualsBrandsSignature Hardware ManualsShop All Signature HardwareSignature Hardware Sitka 60" x 30" Three Wall Alcove Acrylic Whirlpool Tub - Right Drain

REVISED 09/11/2019

CODE: SHSKS6030LWH/SHSKS6030RWH/SHSKW6030LWH

SHSKW6030RWH/SHSKS6030LBS/SHSKS6030RBS

1.800.221.3379

X 30

SITKA

ACRYLIC ALCOVE SOAKING TUB

SKU: 948062, 948274

FEATURES

Overﬂow Hole: Yes

Shape: Rectangle

Material: Acrylic

Length: 60"

Width: 30"

Height: 21-1/4"

Tub Interior Length: 44-7/8"

Tub Interior Width: 20-1/4"

Tub Slope: 25°

Water Depth To Overﬂow: 15-3/4"

Drain Included: Optional

Drain Placement: End

Faucet Included: No

Water Capacity (Gallons): 62

SIGNATURE HARDWARE Lifetime Warranty

See website for detailed warranty information.

CONTENTS

AIR & WHIRLPOOL TUB

60" X 30 TUB

PAGE 2

PAGE 3

.............................

Summary of content (3 pages)

PAGE 1
60" X 30" SITKA ACRYLIC ALCOVE SOAKING TUB SKU: 948062, 948274 FEATURES Overﬂow Hole: Yes Shape: Rectangle Material: Acrylic Length: 60" Width: 30" Height: 21-1/4" Tub Interior Length: 44-7/8" Tub Interior Width: 20-1/4" Tub Slope: 25° Water Depth To Overﬂow: 15-3/4" Drain Included: Optional Drain Placement: End Faucet Included: No Water Capacity (Gallons): 62 SIGNATURE HARDWARE Lifetime Warranty See website for detailed warranty information. CONTENTS AIR & WHIRLPOOL TUB .............................
PAGE 2
AIR TUB AND WHIRLPOOL TUB COMPONENTS LIST • Powerful whirlpool pump with variable ﬂow device • Heated blower for air bath system INSIDE OF BATH • (8) HIGH-FLOW DIRECTIONAL AND VOLUME-ADJUSTABLE WHIRLPOOL JETS • (56) CHANNEL-FED AIRJETS (air bath and total massage) INSTALLATION • Whirlpool and Total Massage units require dedicated 20 Amp, 120V service • You must provide a receptacle with a 20 Amp conﬁguration • Electrical outlet must be mounted 4” (101mm) above the ﬂoor line and 12” max (305mm) inside from
PAGE 3
60" X 30" SITKA ACRYLIC ALCOVE SOAKING TUB SKU: 948062, 948274 60" 1-1/4" 25° 21-1/4" 3-1/2" 44-7/8" 30" 15-3/4" 20-1/4" 8-3/4" FEATURES Overﬂow Hole: Yes Shape: Rectangle Material: Acrylic Length: 60" Width: 30" Height: 21-1/4" Tub Interior Length: 44-7/8" Tub Interior Width: 20-1/4" Tub Slope: 25° Water Depth To Overﬂow: 15-3/4" Drain Included: Optional Drain Placement: End Faucet Included: No Water Capacity (Gallons): 62 All dimensions and specifications are nominal and may vary.
