Specification Sheet

1.800.221.3379

REVISED 01/07/2020

FEATURES

Shape: Square

Assembly Required: No

Installation Type: Ceiling Mount

Shower Head Spray: Single Function (Full Spray)

Shower Arm Included: Yes

Shower Head Spray: Rainfall

Shower Head Swivel: Yes

Easy Clean Rubber Nozzles

Brass Ball Joint & Threaded Connection

Easy Installation

Escutcheon Included

Shower Head Flow Rate: 1.8 gpm (6.8L/min) max @ 80 psi

SIGNATURE HARDWARE Lifetime Warranty

See website for detailed warranty information.

CONTENTS

SHOWER HEAD

SHOWER ARM

PAGE 2

PAGE 3

..................

RIGI

RAINFALL SHOWER HEAD WITH SQUARE CEILING-MOUNT SHOWER ARM

SKU: 949055

PAGE 1
RIGI RAINFALL SHOWER HEAD WITH SQUARE CEILING-MOUNT SHOWER ARM SKU: 949055 FEATURES Shape: Square Assembly Required: No Installation Type: Ceiling Mount Shower Head Spray: Single Function (Full Spray) Shower Arm Included: Yes Shower Head Spray: Rainfall Shower Head Swivel: Yes Easy Clean Rubber Nozzles Brass Ball Joint & Threaded Connection Easy Installation Escutcheon Included Shower Head Flow Rate: 1.8 gpm (6.
PAGE 2
RIGI SQUARE RAINFALL SHOWER HEAD SKU: 949055 1/2" (13 mm) 7-7/8" (200 mm) 2-1/16" (52 mm) 7-7/8" (200 mm) FEATURES Material: ABS Length: 7-7/8" Width: 7-7/8" Height: 2-1/16" IPS: 1/2" CODES/STANDARDS cUPC ASME A112.18.1/CSA 125.1 WaterSense Massachusetts Accepted All dimensions and specifications are nominal and may vary. Use actual products for accuracy in critical situations. SIGNATURE HARDWARE LIFETIME WARRANTY See website for warranty information PAGE 2 Code: SHSB3020BN/SHSB3020CP 1.800.221.
PAGE 3
RIGI CEILING-MOUNT SHOWER ARM SKU: 949055 4" (102 mm) -or- 6" (152 mm) -or- 12" (305 mm) 1/4" (6 mm) 2-3/8" (60 mm) 1/2" (13 mm) -14NPT 1/2" (13 mm) -14NPT 1" (25 mm) 9/16" (14 mm) 9/16" (14 mm) 2-3/8" (60 mm) 1" (25 mm) 1/2" (13 mm) FEATURES Material: Brass Base Plate Length: 2-3/8" Base Plate Width: 2-3/8" IPS: 1/2" All dimensions and specifications are nominal and may vary. Use actual products for accuracy in critical situations.
