Specification Sheet

1.800.221.3379
All dimensions and specifications are nominal and may vary. Use actual products for accuracy in critical situations.
26"
(660 mm)
65" ~ 78"
(1651 mm ~ 1981 mm)
9-13/16" (250 mm)
2-3/4"
(70 mm)
45
8-1/2" (216 mm)
1/2" (13 mm) -14NPT
4-1/2"
(114 mm)
7" (178 mm)
4-7/8" (124 mm)
5-3/8" (137 mm)
°
7-1/4" (184 mm)
KEY WEST
PAGE 2
Code: SHKW8020GBN
SHKW8020GCP/SHKW8020GORB
CODES/STANDARDS
cUPC
ASME A112.18.1/CSA B125.1
ADA compliant (when installed according
to ADA standards)
WaterSense
CEC Listed
Cal Green
Massachusetts Accepted
SIGNATURE HARDWARE
LIFETIME WARRANTY
See website for warranty information
FEATURES
Shower Head Diameter: 4-1/2"
Shower Arm Extension: 7"
Shower Head IPS: 1/2"
Valve Trim Width: 7-1/4"
Valve Trim Height: 7-1/4"
NPT Connection: 1/2"
PRESSURE BALANCE SHOWER SET
SKU: 948308
