3-Port DVI Splitter

Quick Installation Guide

Introducing the 3-Port DVI Splitter

The 3-Port DVI Splitter provides an easy solution for

distributing one DVI video signal to three displays.

Features and Benefits

• Connects a DVI video source to 3 DVI compatible

displays

• Perfect as a repeater by regenerating the DVI signal

• Stackable; up to 8 devices to support up to 17

outputs

• Reads and remembers EDID of displays

Technical Specifications

• Input connector: 1 x DVI-I

• Output connector: 2 x DVI-I

• Maximum resolution: 1600 x 1200

• LEDs: 1 x Green (ID), 1 x Red (power)

• DIP switch: 2

• Dimensions: 12mm (L) x 88mm (W) x 25mm (H)

• Weight: 300g

Package Contents

• 3-Port DVI Splitter

• DVI Y-cable (DVI to DVI x2, 100/180 cm)

• Power Adapter (5V, 2A)

• Quick Installation Guide

04-0493A

Summary of content (8 pages)

PAGE 1
3-Port DVI Splitter Quick Installation Guide Introducing the 3-Port DVI Splitter The 3-Port DVI Splitter provides an easy solution for distributing one DVI video signal to three displays.
PAGE 2
Front Panel Connect to DVI Display Connect to DVI Y-cable Note: When cascading, use the short cable of the DVI Y-cable to connect to the next splitter's DVI-IN. Rear Panel Power Jack • • • • • • 2 Connect to DVI output (PC) Rotary switch Green LED Red LED Infrared receiver Power Jack: connect to the power supply DVI-In: connect to DVI output source, such as PC Rotary switch: used when cascading, assign different ID for each switch. Ignore when only a single splitter is used.
PAGE 3
DIP Switch • • • • 1 ON: open EQ. Less noise but more power consumption 1 OFF: Close EQ 2 ON: Writing Default EDID. Set switch to ON, plug in the power adapter. The green light will turn on after the writing process in completed. 2 OFF: Recording EDID of the Connected Display via DVI-Out 1 connector. Plug in the DVI cable first from the display and then plug in the power adapter. The recording process will be initated and the green LED lights up.
PAGE 4
Hardware Installation We suggest to connect the monitor with the lowest resolution to DVI-OUT 1. Unless you would like to use the default universal EDID, please set DIP switch 2 at OFF position, which allows the 3-Port DVI Splitter to read the first connected monitor's EDID. Single Splitter 1. 2. 3. 4. 5. Connect a monitor, projector or other displays with DVI inputs to DVI-Out 1 of the 3-Port DVI Splitter. Plug the DVI Y-cable into the DVI-Out 2 of the 3-Port DVI Splitter.
PAGE 5
6. 7. For each splitter, plug the power adapter into the Power Jack, then plug the power adapter into a reliable power outlet. Connect a PC or other device with DVI output to the DVI-In of the first 3-Port DVI Splitter. Safety Precautions Like all electronic equipment the 3-Port DVI Splitter should be used with care. Please read and follow the safety precautions to protect yourself from possible injury and minimize the risk of damage to the unit.
PAGE 6
Blank Page 6
PAGE 7
Technical Support and Warranty QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at www.siig.com and click Support. Our online support database is updated daily with new drivers and solutions. Answers to your questions could be just a few clicks away. You can also submit questions online and a technical support analysts will promptly respond. SIIG offers a 2-year manufacturer warranty with this product. Please see our web site for more warranty details.
PAGE 8
About SIIG, Inc. Founded in 1985, SIIG, Inc. is a leading computer upgrade manufacturer of I/O connectivity products, including PCIe, PCI & ISA serial and parallel ports, USB, Serial ATA & UltraATA controllers, FireWire (1394a/b), networking, sound cards, and other accessories. SIIG is the premier one-stop source of upgrades. SIIG products offer comprehensive user manuals, many user-friendly features, and are backed by an extensive manufacturer warranty.
