1 Introduction 1 Introduction Silver Spring Networks’ Distribution Automation (DA) network is designed to help electrical utilities manage field devices such as reclosers, capacitor banks, voltage regulators, and transformers, through more efficient two-way communication. The utilities’ primary tools for monitoring power distribution systems are called Remote Terminal Units (RTUs).
1 Introduction or more RTUs. The RF interface connects all bridges together in a routable RF wireless network for DA communications. A serial port can also be used for RTU connections. Figure 1. Front and back view of the eBridge Front Back Power Serial port USB GPIO Ethernet SMA female RF conn. The sBridge Note: sBridges can be used for meter connectivity and for DA RTU connectivity.The application described in this guide is for DA connectivity. sBridges are not designed for use as a master bridge.
1 Introduction Figure 3 shows an example of an RTU, which provides an Ethernet port, two serial ports and terminals for the electrical equipment to which it connects. Figure 3. An RTU Note: For more information about network deployments of the eBridge and sBridge, refer to Chapter 2, Deploying Silver Spring Networks Bridges on page 8. For instructions on how to configure eBridges and sBridges, refer to the Bridge Configurator 2.0 User’s Guide.
1 Introduction Customer Support Silver Spring Networks offers expert technical support and guaranteed response times. Table 1. Support Information Country Email Telephone Hours Australia aus-support@silverspringnet.com +03 9607 8521 9:00 AM - 6:00 PM Canada support@silverspringnet.
2 Deploying Silver Spring Networks Bridges 2 Deploying Silver Spring Networks Bridges Essential to the complete creation of a DA network are the Silver Spring primary devices: the eBridge and the sBridge. The DA network is designed to help utilities effectively communicate with field-installed remote terminal units (RTUs) and power system device controllers in the electrical distribution network.
2 Deploying Silver Spring Networks Bridges 4. Interface Connections: Connect the required interface cables between the bridge and the RTU. Table 2. Available antennas for Silver Spring Network bridges SSN Antenna Part # Description 315-00012 Rev. 5 JPole antenna 315-000002 Rev.
2 Deploying Silver Spring Networks Bridges Deployment Considerations Before deploying bridges, allow for the following deployment considerations: • Network topology • Interfaces and protocols • Deployment modes Table 3 summarizes bridge deployment choices in the network. Table 3.
2 Deploying Silver Spring Networks Bridges Supported Network Topologies To accommodate placements of existing RTUs in the field, bridge units can be deployed in the following network topologies: • Master/Remote Topology • Teaming Topology on page 13 • A combination of Master/Remote and Teaming Topology In the Master/Remote topology, a master bridge connects to the SCADA (Supervisory Control And Data Acquisition) master.
2 Deploying Silver Spring Networks Bridges the DA (Distribution Automation) network, as indicated in Figure 5. Here, the pre-existing electrical distribution grid is overlaid with the bridge-based DA network deployment. Figure 5. Master/Remote Example Relays are used to extend the RF signal to greater distances and to extend the signal around obstacles in the field. Centralized and Decentralized Master/Remote Deployments A Master/Remote deployment can be centralized or decentralized.
2 Deploying Silver Spring Networks Bridges In a decentralized Master/Remote deployment, multiple SCADA systems exist (for example, substations in different locations) and data is drawn back to multiple points. Larger DA networks will roughly follow this model. Figure 7. Example of a Decentralized Master/Remote Deployment Teaming Topology In the Teaming topology, a small set of bridges send each other messages to accomplish specific tasks.
2 Deploying Silver Spring Networks Bridges Serial In serial mode, the remote or teaming bridge connects to an RTU through a serial interface. Because serial RTUs have DNP addresses, the end point of the IP network is the bridge device. Note: The Silver Spring Networks sBridge provides two DB-9 serial interfaces. (The eBridge provides a single DB-9 serial port.
2 Deploying Silver Spring Networks Bridges master bridge into DNP messages, and pass them on to the RTU. The remote bridges require the DNP address of the RTU to which they are serially connected. Figure 8. Example of a Mixed IPv4 Deployment Serial Master/Serial Remote IPv6 Sample Deployment In Serial Master/Serial Remote deployments, no Ethernet/IP network appears at the master bridge location. The master connects to the SCADA network using DNP3 over serial.
2 Deploying Silver Spring Networks Bridges The Bridge Configurator program provides the settings to associate the DNP3-based RTU address with each Remote bridge. IPv6 Addressing in the RF Network When a device registers with a subnet, the master bridge assigns it an IPv6 prefix, which the device appends to its MAC address to create a globally unique IPv6 unicast address, formatted according to the IEEE EUI-64 standard.
2 Deploying Silver Spring Networks Bridges determine the routing paths to all other members of the team. Figure 10 shows the path of various messages between the teaming members. Figure 10. Example of an Ethernet Teaming Deployment Mode 3. This bridge receives the “Open” message from IPx1 and sends it, through Ethernet, to the recloser at IPy2. 1. The recloser IPx2 sends an “Open” message to the recloser at IPy2 through the predetermined path. 192.168.0.5 Ethernet 2.
A Specifications A Specifications Specifications are provided in the following topics: • Overview • eBridge and sBridge Features • Silver Spring Networks eBridge Specifications on page 19 • Silver Spring Networks sBridge Specifications on page 22 • Regulatory Compliance - Module Certifications on page 24 Overview The eBridge and sBridge are Commercial and Industrial SCADA products that are attached to the Silver Spring Networks Smart Energy Networks.
A Specifications Silver Spring Networks eBridge Specifications This section contains the following tables to provide eBridge specifications: • eBridge Communications Specifications • eBridge Approvals • eBridge Environmental Specifications • eBridge Protocols/Security • eBridge Interfaces • eBridge DB-9 Interface Definition • eBridge Isolated Input/Output • eBridge RJ-45 Hub Interface Definition • eBridge Power Consumption Table 4.
A Specifications Table 6. eBridge Interfaces RS-232 DB-9 Serial, DCE device, RS-232 levels Ethernet RJ-45, 10-100BaseT Hub, 36-57 VDC PoE input Mini-USB USB Serial device DC Voltage Input 10-30VDC DC Input Table 7. eBridge Isolated Input/Output Pin# Signal Direction Description Current 1 Input Input Isolated Output 1 mA (min) 2 mA (max) 2 Output Output Isolated Input 1 mA (min) 2.
A Specifications Table 11. eBridge DB-9 Interface Definition Pin# Signal Direction Description 1 DCD Output Data Carrier Detect 2 TXD Output Transmit Data 3 RXD Input Receive Data 4 DTR Input Data Terminal Ready 5 GND -- Signal Ground 6 DSR Output Data Set Ready 7 RTS Input Request To Send 8 CTS Output Clear To Send 9 RI Output Ring Indicator All RS-232 receptacles are standard DB-9 receptacle DCE pinout. Table 12.
A Specifications Silver Spring Networks sBridge Specifications This section contains the following tables to provide sBridge specifications: • sBridge NAN Transceiver • sBridge Environmental • sBridge NAN Network • sBridge DB-9 Interface Definition • sBridge Processing • sBridge DC Power Input • sBridge Physical • sBridge Physical • sBridge Interfaces Table 13.
A Specifications Table 17. sBridge Interfaces RS-232 DB-9 Serial, DCE device, RS-232 levels DC Voltage Input 10-30VDC DC Input Table 18. sBridge Environmental Temperature, operating -40°C to +85° Humidity 95%, non-condensing Table 19.
A Specifications Regulatory Compliance - Module Certifications This section contains the following regulatory compliance information: • FCC Certification (Radiated/Conducted Emissions Compliance FCC Part 15.
A Specifications This device has been designed to operate with the antennas listed below, and having a maximum gain of 3 dBi (sBridge) and 6 dBi (eBridge). Antennas not included in this list or having a gain greater than 3 dBi (sBridge) or 6 dB (eBridge), are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. Table 21. Available antennas for Silver Spring Network bridges SSN Antenna Part # Description 315-00012 Rev. 5 JPole antenna 315-000002 Rev.
A Specifications • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver disconnected. • Consult the dealer or an experienced Radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by Silver Spring Networks could void the user's authority to operate the equipment.
