CV_54374_SFE450A1_LB6.qxd 17.06.2010 10:16 Uhr Seite 1 KITCHEN TOOLS Juicer SFE 450 A1 6 Juicer Operating instructions KOMPERNASS GMBH BURGSTRASSE 21 · D-44867 BOCHUM www.kompernass.com ID-Nr.
CV_54374_SFE450A1_LB6.qxd 17.06.
IB_54374_SFE450A1_LB6.qxd 17.06.
IB_54374_SFE450A1_LB6.qxd 17.06.
IB_54374_SFE450A1_LB6.qxd 17.06.2010 15:23 Uhr • This appliance is not intended for use by individuals (including children) with restricted physical, physiological or intellectual abilities or deficiences in experience and/or knowledge unless they are supervised by a person responsible for their safety or receive from this person instruction in how the appliance is to be used. Children should be supervised to ensure that they do not play with the appliance.
IB_54374_SFE450A1_LB6.qxd 17.06.2010 15:23 Uhr Tips for safety: Seite 4 1. Place the juice catchment bowl t on the appliance base u, so that the three tenons and the juice outlet y are securely caught in the recesses. 2. Place the filter d on the drive shaft f and press it down so that it perceptibly engages. Ensure that it is firmly seated before continuing with the assembly. 3.
IB_54374_SFE450A1_LB6.qxd 17.06.2010 15:23 Uhr • The main stalk is to be removed from grapes. • Cut the fruit or vegetables into pieces that are sized to fit into the loading shaft w. • Before juicing, place the carrots in water for about 24 hours. Afterwards, guide them one after the other into the filling shaft w: thereby, the thicker end of the carrot, where the leaves were, must be facing down and the thinner root tip must be upmost. Seite 5 2.
IB_54374_SFE450A1_LB6.qxd 17.06.2010 15:23 Uhr Warning: Seite 6 Warning: Remove the plug from the power source when emptying the filter d. This prevents an unintended starting of the motor. To avoid receiving an electrical shock, NEVER submerse the motor/appliance base u in water or other fluids. When the extracted juices suddenly become thicker, or when you hear that the motor is running slower, the filter d must be emptied.
IB_54374_SFE450A1_LB6.qxd 17.06.2010 15:23 Uhr Storage Seite 7 The warranty period will not be extended by repairs made under warranty. This applies also to replaced and repaired parts. Any damage and defects extant on purchase must be reported immediately after unpacking the appliance, at the latest, two days after the purchase date. Repairs made after the expiration of the warranty period are subject to payment.
IB_54374_SFE450A1_LB6.qxd 17.06.2010 15:23 Uhr Seite 8 Troubleshooting Problem The appliance does not function. Possible Causes Possible solutions • The power plug i is not connected. • Connect the appliance to a power socket. • The appliance is not switched on. • Switch the appliance on with the On/Off switch o. • The clasps r are not secured. • Secure the clasps r. The motor stays still while juicing or it turns noticeably slow or un- • The filter d is blocked. regularly.
