2
FORTRESS SERIES FT02
Advancing computer chassis construction and
thermodynamics
Material
Motherboard
Model
Drive Bay
Cooling System
Expansion Slot
Front I/O Port
Power Supply
Expansion Card
Dimension
4.5mm aluminum unibody frame, 0.8mm steel body
SSI CEB, ATX (maximum 12” x 11”), Micro ATX
SST-FT02B (black)
SST-ST02S (silver)
SST-FT02B-W (black + window)
SST-FT02S-W (silver + window)
Exposed
Internal
Bottom
Top
7
USB 3.0 x 2, Audio x 1, MIC x 1
1 x optional standard PS2 (ATX)
Support 12.2”
212mm (W) x 497mm (H) x 616mm (D)
5.25" x 5
3.5" x 5 , 2.5” x1
3 x 180mm intake fan 700/1200rpm, 18/34dBA
1 x 120mm exhaust, 1200rpm, 19dBA
