Technical Specifications

51
XXXTJNFSQVNQDPNt
t
High output shallow well pump
t
Ideal for compact installations
t
Superior performance at depths to water of 25’ or less
t
Pre-charged pressure tank with 7 gallon capacity
t
Corrosion-resistant pressure tank with heavy-gauge
steel construction and baked-on nish
t
Durable cast-iron pump housing, heavy-duty rugged
construction
t
Ready-to-install, heavy-duty dual-voltage motor
preset at 115 volts
t
1-1/4” NPT suction and 1” NPT discharge pipe size
JET PUMP &
TANK SYSTEM
MODEL 2806E 1/2 HP
1
YEAR
WARRANTY
*All performances shown in gallons per minute at 40 PSI (pound per square inch) discharge pressure at top of well.
Pressure Switch GPM Pumped at Different Depths to Water* Max Pressure
Model HP Warranty Voltage On Off 5’ 10’ 15’ 20’ 25’ Shut-off
2806E 1/2 1-year 115/230 30 50 8.5 7.8 6.8 5.6 4.6 69 PSI
PERFORMANCE
Model UPC Carton (L x W x H) Cube Pallet Qty. Weight
2806E 0 17561 14103 5 26.063” x 15.063” x 28.563” 6.489 4 59 lbs.
ORDERING INFORMATION
JET PUMP & TANK SYSTEM
MODEL 2806E
