Available Connections
PLC Connections
The total number of PowerGrid units in the network.
PLC PORT
The PLC data connection port for each connection.
MAC Address
This is a code that identifies all remote devices
connected to this unit. On PowerGrid units, it is printed
on the back label under the barcode.
Phy Tx/Rx Throughput
Physical Transmission / Reception Throughput is a
measure of network bandwidth. Available data
transmission capacity is roughly half this value.
Bridge State
Enabled indicates there is a data connection.
Disabled indicates no data connection.
Network Id
Network ID is used for network security. If present, it
means the remote device is on the same network.
External Interfaces
Interface
EXTA = Ethernet
Phy Throughput
Physical Throughput = Data Transmission Capacity
Bridge State
Forwarding = Active
General Information
MAC Type
The MAC Address shown above is an In-Home AV type.
MAC Address
This code identifies the PowerGrid unit that is currently
being managed with the WUI. The MAC Address is
printed on the back label of the unit, under the barcode.
IP Address
The IP Address defines the location of the PowerGrid
unit on the local area network.
Node Type
This will show as Fixed AP, EP or AP.
Number of Boots
The number of times this PowerGrid unit has been
rebooted since the last Factory Reset.
NOTE: The remaining fields are advanced settings used for technical support.
