Video Optimization Mode
Description
Automatic Optimization
Optimization based on video traffic type (TCP or UDP).
Optimized for Media Player
Improved transmission of TCP video.
Optimized for IPTV Service
Improved transmission of UDP video.
POWERSAVING MECHANISM
This function activates a low power mode when the PowerGrid 9020 is inactive,
unless that unit is assigned as a master or repeater within the Powerline network.
Field
Description
PowerSaving
mechanism
Enabled = PowerSaving On
Disabled = PowerSaving Off
Hysteresis time
(Ethernet Link)
PowerSaving mode becomes active when it is Enabled
and there is no Ethernet Link for {x} number of
seconds, where {x} is the Hysteresis time. It is
inactivated when an Ethernet Link is detected.
VLAN STATUS
With this function an 802.1Q VLAN Tag is added to the data packet header. This
enables a physical LAN to be divided into several discrete virtual LANs. Data
packets are given priority based upon their VLAN Tag and VLAN Priority settings.
Note, the PowerGrid 9020 does not filter data packets; it merely tags them.
Field
Description
VLAN Configuration
Enabled = VLAN tagging on
Disabled = VLAN tagging off
VLAN Tag
A number in the range of 2 to 4094.
VLAN Priority
A number between 0 and 7 (highest priority).
