NETWORK CONFIGURATION
The section provides options to configure the IP configuration.
Field
Description
IP Configuration
Either DHCP (Automated) or FIXED IP (Manual).
NOTE: In FIXED mode the IP Address, Subnet Mask and Default Gateway IP
Address can be set manually, while in DHCP mode they are assigned by a server.
Changes do not become effective until after a reboot of the PowerGrid unit.
IP Address /
Subnet Mask
These values define the location of the PowerGrid unit on the
local area network.
Default Gateway
IP Address
The IP address of the router that forwards traffic to a
destination that is out of reach of the PowerGrid unit.
DNS server
IP Address
The IP address of the server that provides Domain Name
System (DNS) services such as hostname IP lookup.
PHY CONFIGURATION
This section provides options to configure the physical parameters of the network.
