NANTUCKET / OAKLEY / WESTWOOD CONSOLE SOFA TABLE MODEL # 3AXCNTT-04 1/13
Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am – 4 pm EST or go to www.simpli-home.
IMPORTANT : for Please read this manual carefully before beginning assembly of this product. keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. hardware package may have spare parts. WARNING: This item contains small parts which can be swallowed by children and pets. keep children and pets away during assembly.
IMPORTANT: Keep this manual for future reference. CARE and MAINTENANCE Wood Furniture Care Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally along different grain directions.
PRE-ASSEMBLY INFORMATION PARTS DESCRIPTION MODEL # 3AXCNTT-04 A B TOP QTY 1 C LEG QTY 2 BOTTOM SHELF QTY 1 PRE-ASSEMBLY INFORMATION HARDWARE DESCRIPTION 1 MODEL # 3AXCNTT-04 2 ALLEN KEY BOLT M6 X 18 mm QTY 12 ALLEN KEY BOLT M6 X 10 mm QTY 16 4 3 LOCK WASHER Ø 15 / Ø 8 X 1.5 mm QTY 16 5 WASHER Ø 17 / Ø 8 X 1.5 mm QTY 12 ALLEN KEY QTY 1 NEED HELP? for help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext.
COMPONENTS - KEY DIAGRAM MODEL # 3AXCNTT-04 P1 B A P2 C P3 P4 B 6/13
ASSEMBLY MODEL # 3AXCNTT-04 STEP 1 P1 B A P1 B A B 1 4 3 2 5 1. Align Leg B to Top A by matching the letters P1 to P1 . 2. Use four Allen key Bolts 2 and four Lock Washers 3 to attach Top A and Leg B (front and back of Leg). 3. Use three Allen Key Bolts 1 and three Washers 4 to secure Top A and Leg B (middle of Leg). 4. Use Allen Key 5 to tighten Bolts. Do not over tighten.
ASSEMBLY MODEL # 3AXCNTT-04 STEP 2 B 1 4 P3 B B C 2 5 3 P3 C 1. Align Leg B to Bottom Shelf C by matching the letters P3 to P3 . 2. Use four Allen Key Bolts 2 and four Lock Washers 3 to attach Bottom Shelf C and Leg B (front and back of Leg). 3. Use three Allen Key Bolts 1 and three Washers 4 to secure Top A and Leg B (middle of Leg). 4. Use Allen Key 5 to tighten Bolts. Do not over tighten.
ASSEMBLY MODEL # 3AXCNTT-04 STEP 3 P1 A B P3 C P2 B P4 1. Align other Leg B to Top A and Bottom Shelf C by matching the letters P2 to P2 and P4 to P4 .
ASSEMBLY MODEL # 3AXCNTT-04 STEP 4 A P2 B C 3 B 2 4 5 1 1. Align Leg B to Top A by matching the letters P2 to P2 . 2. Use four Allen Key Bolts 2 and four Lock Washers 3 to attach Top A and Leg B (front and back of Leg). 3. Use three Allen Key Bolts 1 and three Washers 4 to secure Top A and Leg B (middle of Leg). 4. Use Allen Key 5 to tighten Bolts. Do not over tighten.
ASSEMBLY MODEL # 3AXCNTT-04 STEP 5 A B C B P4 3 2 4 5 1 1. Align Leg B to Bottom Shelf C by matching the letters P4 to P4 . 2. Use four Allen Key Bolts 2 and four Lock Washers 3 to attach Bottom shelf C and Leg B (front and back of Leg). 3. Use three Allen Key Bolts 1 and three Washers 4 to secure Top A and Leg B (middle of Leg). 4. Use Allen Key 5 to tighten Bolts. Do not over tighten.
ASSEMBLY MODEL # 3AXCNTT-04 STEP 6 Note: Levelers on bottom of legs can be adjusted if floor is uneven.
WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. This warranty does not affect your statutory rights. In case of any malfunction of your product (failure, missing parts, etc.) please contact us at our toll free service line at 1-866-518-0120 ext.
