MERRIN / WESTVILLE / BEAUFORT EURO RECLINER MODEL # AXCEUREC-03
FOR REPLACEMENT PARTS OR HELP WITH ASSEMBLY PLEASE CONTACT US AT: simpli-home.
ENTER TO WIN Upload an image of our furniture in your home with a short review to our facebook page for a chance to Win up to $3000 of Simpli Home furniture!!! www.facebook.
IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts. WARNING: This item contains small parts which can be swallowed by children and pets. Keep children and pets away during assembly.
PRE-ASSEMBLY INFORMATION PARTS DESCRIPTION 1 3 2 CHAIR QTY 1 4 OTTOMAN CUSHION QTY 1 ARMREST (RIGHT and LEFT) QTY 1 CHAIR BASE QTY 1 6 5 U-BOARD QTY 1 OTTOMAN BASE QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext.
PRE-ASSEMBLY INFORMATION HARDWARE DESCRIPTION A B ALLEN KEY SCREW M6 X 18 mm QTY 8 D C M8 X 25 mm QTY 2 E ALLEN KEY SCREW M8 X 60 mm QTY 2 G F SMALL WASHERS QTY 4 H M6 ALLEN KEY QTY 1 ALLEN KEY SCREW M8 X 35 mm QTY 4 CONNECTOR PINS and NUTS LARGE WASHERS QTY 4 I M8 ALLEN KEY QTY 1 WRENCH 13mm QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext.
ASSEMBLY STEP 1 Align the Chair (1) to the Chair Base (2). Use Screws (D) to attach to the Chair Base (2). Use M8 Allen Key (H) to tighten.
ASSEMBLY STEP 2 Secure Chair (1) to the Chair Base (2) with Connector Pins and Nuts (B). Use M6 Allen Key (G) and Wrench (I) to tighten.
ASSEMBLY STEP 3 Attach left and right Armrests (3) to the Chair Base (2) with Screws (A). Use M6 Allen Key (G) to tighten.
ASSEMBLY STEP 4 OTTOMAN ASSEMBLY Attach Ottoman Base (6) to the U-board (5) with Screws (C) and Large Washers (F). Use M6 Allen Key (G) to tighten.
ASSEMBLY STEP 5 OTTOMAN ASSEMBLY Attach Ottoman Cushion (4) to brackets on the U-Board (5) using Screws (A) and Small Washers (E). Use M6 Allen Key (G) to tighten.
ASSEMBLY TO ADJUST TILT FUNCTION While seated, reach underneath the right side of the recliner and turn the handle. The recliner will tilt backward when you rotate the handle. Rotate the handle until the desired angle is reached.
WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. This warranty does not affect your statutory rights. In case of any malfunction of your product (failure, missing parts, etc.) please contact us at our toll free service line at 1-866-518-0120 ext.
Question, problems, missing parts? Before returning your product please email Customer Support at customerservice@simpli-home.com or call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am – 4 pm EST For more information visit us on our website www.simpli-home.com Like us on facebook www.facebook.
