Manual

Form ZCE731A 3 Date 2014October6/F
LUBRICATION
All models may operate without airline lubrication. However, operating the tool without airline lubrication may reduce tool performance and vane life.
If an airline lubrication is not used, it is recommended that the tool be oiled daily before use to improve performance. Add 2-4 drops of air motor oil and run the
tool for 10-20 seconds to distribute oil through the tool.
For maximum performance and tool life, an air line lubricator, set to deliver 2 drops per minute, is recommended. SIOUX No. 288 Air Motor Oil is
recommended.
MAINTENANCE
Water, dust and other airline contaminants can cause rust and vane sticking. For long periods between tool use, flush the tool with a few drops of oil and run
for 10 seconds. This will help remove contaminants and reduce the formation of rust.
OPERATION
The tool is equipped with a locking type lever in order to prevent accidental start-up.
Speed of the tool may be adjusted by turning the regulator, which is located opposite the throttle lever.
INSTALLING MOUNTED WHEELS
Insert the mounted wheel into the collet. Make sure the wheel shank and the collet size match. Do not allow the wheel to extend beyond the collet an excessive
distance.
Hold the collet body with a 9/16” (14mm) wrench and the collet nut with a 3/4” (19 mm) wrench.
Turn the collet nut to the right and firmly tighten the collet on to the wheel shank.
REMOVING MOUNTED WHEELS
To remove the mounted wheel, hold the collet body with a 9/16” (14 mm) wrench and the collet nut with a 3/4” (19 mm) wrench.
Turn the collet nut to the left and loosen the collet.
Remove the mounted wheel.
WARNING
Disconnect tool from air supply before installing or removing wheel or making any adjustments
NOISE AND VIBRATION READINGS
Catalog
Number
Noise* (Tested in accordance with ISO Standard 15744) Vibration* (Tested in accordance with ISO Standard 8662-13:1997)
*Sound Pressure (dBA) *Sound Power (dBA) Uncertainty (dBA) *Vibration m/s
2
Uncertainty m/s
2
SDG03S25 83.3 94.9 3.0 3.21 0.91
SDG05S18R 87.4 99.0 3.0 3.22 0.09
SDG05S23 85.1 96.7 3.0 1.98 0.68
SDG7S18F 81.8 93.4 3.0 2.92 0.05
SDG7S25F 79.6 91.2 3.0 2.59 0.08
SDG10S12F 85.9 97.7 3.0 4.52 1.88
SDG10S12R 85.9 97.7 3.0 4.52 1.88
SDG10S18F 80.3 91.9 3.0 2.60 0.04
SDG10S18R 76.4 88.0 3.0 2.63 0.04
SDG10S25F 83.3 94.9 3.0 1.88 0.06
SDG10S25R 81.1 92.7 3.0 2.28 0.05
SDG10SHT08 85.6 97.7 3.0 4.52 0.63
SDG10SHT12 84.0 95.6 3.0 4.45 0.27
SDGS1S12 90.4 102 3.0 2.04 0.17
SDGA1S12 90.9 102.5 3.0 1.19 0.02
SDGS1S18 85.8 97.4 3.0 2.54 0.29
SDGA1S18 87.4 99.0 3.0 1.49 0.10
SDGS1S25 85.1 96.7 3.0 2.10 0.14
SDGA1S25 86.2 97.8 3.0 2.19 0.18
SDGS1S12G 92.8 104.4 3.0 1.21 0.11
SDGA1S12G 91.3 102.9 3.0 0.91 0.06
SDGS1S18G 86.5 98.1 3.0 1.87 0.16
SDGA1S18G 86.8 98.4 3.0 1.79 0.23
SDGS1S25G 82.5 94.1 3.0 2.13 0.11
SDGA1S25G 85.4 97.0 3.0 2.06 0.11
SXG05S18 86.7 98.3 3.0 1.80 0.15
SXG05S23 85.9 97.5 3.0 3.00 1.88
SXG10S12R 83.6 95.2 3.0 3.53 0.14
SXG10S18R 82.2 93.8 3.0 4.40 0.09
SXG10S23R 82.1 93.7 3.0 2.94 0.08
STXG10S
