Auto LANStreamer PCI Adapter 04H8095 Installation Guide
Notice The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
1 Connecting to a Netware 3.12 Server Windows for Workgroups 1 Connecting to a Netware 3.12 Server Windows for Workgroups Requirements • HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed. • IBM LANStreamer 16/4 PCI TR adapter and drivers diskettes ver 1.04 (2/24/97). • Driver Name: IBMMPC.DOS Size:60KB Date: 4/4/96 • Novell Netware server that supports Net BEUI, NWLink IPX/SPX, and NWLink NetBIOS transfer protocols. • Netware client for DOS and MS-Windows.
1 Connecting to a Netware 3.12 Server Windows for Workgroups C:\WINDOWS ❒ NO ❒ IBM Auto LANStreamer PCI Adapter (use the driver on disk 3 of 5, Netware DOS requester Installation disk) 7 Highlight option 6 to continue with installation. 8 When prompted, insert the corresponding disks to complete file transfer and driver installation. 9 When the install utility is finished, press to restart the machine.
1 Connecting to Netware 3.12 Server Windows 95 SR2 Windows 95 SR2 Requirements • HP Vectra with Windows 95 SR2 installed. • IBM LANStreamer 16/4 PCI TR adapter and drivers diskettes ver 1.04. • Driver Name: Windows 95 Default • Novell Netware server that supports Net BEUI, NWLink IPX/SPX, and NWLink NetBIOS transfer protocols.
1 Connecting to Netware 3.12 Server Windows 95 SR2 10 Insert disk 1 of 5 (Auto LANStreamer PCI Driver Diskette), set the path to “A:\” and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\MASTERS\LAN\LNSTRM\DISK2\”) 11 At the “Copying Files” window, click on “OK.” 12 Click “OK” to provide your Computer and Workgroup names. 13 Enter your Computer Name, Workgroup Name, Computer Description, and click on “Close.” 14 Accept the default properties, and click on “OK.
2 Connecting to a Netware 4.11 Server Windows for Workgroups 2 Connecting to a Netware 4.11 Server Windows for Workgroups Requirements • HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed. • IBM LANStreamer 16/4 PCI TR adapter and drivers diskettes ver 1.04. • Driver Name: IBMMPC.DOS Size: 60KB Date: 4/4/97 • Novell Netware 4.11 server that supports Net BEUI, NWLink IPX/SPX, and NWLink NetBIOS transfer protocols. • Netware client for DOS and MS-Windows.
2 Connecting to a Netware 4.11 Server Windows for Workgroups ❒ NO ❒ IBM Auto LANStreamer PCI Adapter (use the driver on disk 3 of 5, Netware DOS requester Installation disk) 7 Highlight option 6 to continue with installation. 8 When prompted, insert the corresponding disks to complete file transfer and driver installation. 9 When the install utility is finished, press to restart the machine. 10 After windows loads, open the “NETWORK” folder, and double-click the “NETWORK SETUP” icon.
2 Connecting to a Netware 4.11 Server Windows 95 SR2 Windows 95 SR2 Requirements • HP Vectra with Windows 95 SR2 installed. • IBM LANStreamer 16/4 PCI TR adapter and drivers diskettes ver 1.04. • Driver Name: Windows 95 Default • Novell Netware 4.11 server that supports Net BEUI, NWLink IPX/SPX, and NWLink NetBIOS transfer protocols.
2 Connecting to a Netware 4.11 Server Windows 95 SR2 10 Insert disk 1of 5 (Auto LANStreamer PCI Driver Diskette), set the path to “A:\” and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\MASTERS\LANDRV\LNSTRM\DISK2\”) 11 At the “Copying Files” window, click on “OK.” 12 Click “OK” to provide your Computer and Workgroup names. 13 Enter your Computer Name, Workgroup Name, Computer Description, and click on “Close.” 14 Accept the default properties, and click on “OK.
3 Connecting to a Windows NT 3.51 Server Windows for Workgroups 3 Connecting to a Windows NT 3.51 Server Windows for Workgroups Requirements • HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed. • IBM LANStreamer 16/4 PCI TR adapter and drivers diskettes ver 1.04. • Driver Name for Vectra VL8 and VL7: IBMMPC.DOS Size: 60KB Date: 4/ 4/97. • Driver Name for Vectra VE7/VE8: Streamer.386 Size:85KB Date: 09/13/ 96. • Microsoft Windows NT 3.
3 Connecting to a Windows NT 3.51 Server Windows for Workgroups 7 Click on “Drivers” then on “Add Adapter.” 8 With “Unlisted or Updated Network Adapter”, click on “OK.” 9 Insert disk 1 of 5 (Auto LANStreamer PCI Driver Diskette), set the path to “A:\” and hit enter. (If you have an HP preloaded HDD, set the path to D:\MASTERS\LAN\LNSTRM\DISK2\”) 10 Select “IBM Streamer Family Adapter” and click on “OK.
3 Connecting to a Windows NT Server 3.51 Windows 95 SR2 Windows 95 SR2 Requirements • HP Vectra with Windows 95 SR2. • IBM AUTO LANStreamer PCI card and drivers disk. • Driver Name for Vectra VL8 and VL7: W95setup.inf Size: 40KB Date: 9/ 17/96. • Driver Name for Vectra VE7/VE8: Streamer.vxd Size: 80KB Date: 9/13/96. • Microsoft Windows NT Server 3.51 machine that supports Net BEUI, TCP/ IP, NWLink IPX/SPX, and NWLink NetBIOS transfer protocols.
3 Connecting to a Windows NT Server 3.51 Windows 95 SR2 Click on “Finish.” 10 When prompted to insert the disk labeled “IBM Streamer Family Adapter Option Diskette”, click “OK.” 11 Insert Disk 1 of 5 of IBM Auto LANStreamer drivers disks and set path to “A:\” (If you have an HP pre-loaded HDD, set the path statement to “C:MASTERS\LANDRV\LNSTRM\DISK1\”). 12 Click “OK” to continue installation. 13 Click “OK” to the “Network” dialog box, to provide computer / work group names.
3 Connecting to a Windows NT Server 3.51 Windows 95 SR2 “C:\MASTERS\LANDRV\LNSTRM\DISK4\WIN95\”) 25 Click on “Yes” button to finish the setup installation and restart your computer.
3 Connecting to a Windows NT Server 3.
3 Connecting to a Windows NT Server 3.51 Windows NT Workstation Version 3.51 Windows NT Workstation Version 3.51 Requirements • HP Vectra with Microsoft Windows NT Workstation 3.51 installed. • IBM AUTO LANStreamer PCI Drivers diskettes Ver. 3.04 • Driver Name for Vectra VL8 and VL7: OEMSETUP.inf Size: 67KB Date: 10/18/96 • Driver Name for Vectra VE7/VE8: Streamer.sys Size: 85KB Date: 09/ 13/96. • Microsoft Windows NT Workstation 3.51 and Service Pack Media. • Microsoft Windows NT Server 3.
3 Connecting to a Windows NT Server 3.51 Windows NT Workstation Version 3.51 9 In the “Windows NT Setup” enter the path to your NT files, and click on the “Continue” button. (If you have an HP preloaded HDD, set path to “C:\I386”) 10 Click on the “Do Not Detect” button from the “Network Adapter Card Detection” dialog box, and click on “Continue” in the second “Network Adapter Card Detection” dialog box.
3 Connecting to a Windows NT Server 3.51 Windows NT Workstation Version 3.51 box.
3 Connecting to a Windows NT Server 3.51 Windows NT Workstation Version 3.
3 Connecting to a Windows NT Server 3.51 Windows NT Workstation Version 4.0 Windows NT Workstation Version 4.0 Requirements • HP Vectra with Microsoft Windows NT Workstation 4.0 installed. • IBM AUTO LANStreamer PCI Drivers diskettes Ver. 3.04 • Driver Name for VL8 and VL7: OEMSETUP.inf Size: 67KB Date: 10/18/96. • Driver Name for VE7/VE8: Streamer.sys Size: 85KB Date: 09/13/96. • Microsoft Windows NT Workstation 4.0 and Service Pack Media. • Microsoft Windows NT Server 3.
3 Connecting to a Windows NT Server 3.51 Windows NT Workstation Version 4.0 9 With “Wired to the Network” checked, click on “Next.” 10 Click on “Select from List”, then click “Have Disk.” 11 Set the path to “A:\NT” in the “Insert Disk” dialog box, and then insert the disk 4 of 5 , Auto LANStreamer PCI drivers disk. (If you have an HP preloaded HDD, set path to “C:Masters\LanDrv\LNSTRM\DISK4\NT\”) 12 Select “IBM Streamer Family Adapters” in the “Select OEM Option” dialog box, and click “OK”.
3 Connecting to a Windows NT Server 3.51 Windows NT Workstation Version 4.0 26 To complete the installation, remove the floppy disk, and click on “Yes” to restart your computer.
4 Connecting to a Windows NT Server 4.0 Windows NT Workstation Version 4.0 4 Connecting to a Windows NT Server 4.0 Windows NT Workstation Version 4.0 Requirements • HP Vectra with Microsoft Windows NT Workstation 4.0 installed. • IBM AUTO LANStreamer PCI Drivers diskettes Ver. 1.04 • Driver Name for Vectra VL8 and VL7: OEMSETUP.inf Size: 67KB Date: 10/18/96 • Driver Name for Vectra VE7/VE8: Streamer.386 8/19/96 Size: 85KB Date: • Microsoft Windows NT Workstation 4.0 and Service Pack Media.
4 Connecting to a Windows NT Server 4.0 Windows NT Workstation Version 4.0 6 Click on “Start”, up to “Settings”, and open “Control Panel.” 7 Select the “Network” icon in the “Control Panel” program group. 8 Click on “YES” in the “Network Settings“ dialog box, and NT Networking will be installed on your computer. 9 With “Wired to the Network” checked, click on “Next.” 10 Click on “Select from List”, then click “Have Disk.
4 Connecting to a Windows NT Server 4.0 Windows NT Workstation Version 4.0 (If you do not have the required information, contact your network administrator) 25 Verify that “Networking has been installed on this computer” and click on “Finish.” 26 To complete the installation, remove the floppy disk, and click on “Yes” to restart your computer.
4 Connecting to a Windows NT Server 4.0 Windows NT Workstation Version 3.51 Windows NT Workstation Version 3.51 Requirements • HP Vectra with Microsoft Windows NT Workstation 3.51 installed. • IBM AUTO LANStreamer PCI Drivers diskettes Ver. 1.04 • Driver Name: OEMSETUP.inf Size: 67KB Date: 10/18/96 • Microsoft Windows NT Workstation 3.51 and Service Pack Media. • Microsoft Windows NT Server 4.0 machine that supports Net BEUI, TCP/ IP, NWLink IPX/SPX, and NWLink NetBIOS transfer protocols.
4 Connecting to a Windows NT Server 4.0 Windows NT Workstation Version 3.51 10 Click on the “Do Not Detect” button from the “Network Adapter Card Detection” dialog box, and click on “Continue” in the second “Network Adapter Card Detection” dialog box. 11 From the “Drop Down List”, scroll down and select “ Requires disk from manufacturer”, then click “Continue“. 12 Set the path to “A:\NT” in the “Insert Disk” dialog box, and then insert the disk 4 of 5 , Auto LANStreamer PCI drivers disk.
4 Connecting to a Windows NT Server 4.0 Windows for Workgroups Windows for Workgroups Requirements • HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed. • IBM LANStreamer 16/4 PCI TR adapter and drivers diskettes ver 1.01. • Driver Name for for VL8 and VL7: IBMMPC.DOS Size: 60KB Date: 4/4/97 • Driver Name for VE7/VE8: Streamer.sys Size:85KB Date: 09/13/96 • Microsoft Windows NT 4.0 server that supports Net BEUI, NWLink IPX/ SPX, and NWLink NetBIOS transfer protocols.
4 Connecting to a Windows NT Server 4.0 Windows for Workgroups D:\MASTERS\LAN\LNSTRM\DISK2\”) 10 Select “IBM Streamer Family Adapter” and click on “OK.” 11 Verify that “IBM Streamer Family Family Adapter [NDIS2]” is listed under “Network Drivers” and click on “Close.” 12 Click on “OK” in the “Network Setup” window. 13 Specify your User Name, Workgroup Name, Computer Name, and click on “OK.” 14 After files copy, click on “OK” to approve the modification of your CONFIG.SYS, AUTOEXEC.BAT, AND SYSTEM.
4 Connecting to a Windows NT Server 4.0 Windows 95 SR2 Windows 95 SR2 Requirements • HP Vectra with Windows 95 SR2. • IBM AUTO LANStreamer PCI card and drivers disk. • Driver Name for VE7/VE8: Streamer.sys Size: 85KB Date:09/13/96. • Microsoft Windows NT Server 4.0 machine that supports Net BEUI, TCP/ IP, NWLink IPX/SPX, and NWLink NetBIOS transfer protocols.
4 Connecting to a Windows NT Server 4.0 Windows 95 SR2 Option Diskette”, click “OK.”Insert Disk 1 of 5 of IBM Auto LANStreamer drivers disks and set path to “A:\” (If you have an HP pre-loaded HDD, set the path statement to “C:\ MASTERS\LANDRV\LNSTRM\DISK1\”). 11 Click “OK” to continue installation. 12 Click “OK” to the “Network” dialog box, to provide computer / work group names. 13 Specify your Computer Name, Workgroup, and Computer Description.
4 Connecting to a Windows NT Server 4.0 Windows 95 SR2 computer.
4 Connecting to a Windows NT Server 4.
Version Number Lans PCI Rev.
