English www.skylinkhome.com Emergency Dialer DIAL-ALERT TM MODEL : AD-433S CUSTOMER SERVICE 101A320 JUNE, 2004 17 Sheard Avenue, Brampton, Ontario, Canada L6Y 1J3 Tel : (800) 304-1187 Fax : (800) 286-1320 Email : support@skylinkhome.com PAT.
SKYLINK TECHNOLOGIES INC. Your Guide to the English Emergency Dialer DIAL-ALERT TM MODEL: AD-433S Emergency Dialer DIAL-ALERT TM 9 VOLT AD-433S USER'S INSTRUCTIONS The AD-433S Emergency Dialer contains all the above items.
PACKAGE CONTENTS TABLE OF CONTENTS PACKAGE CONTENTS............................................................................................4 . . . OVERVIEW.........................................................................................................5 INSTALLATION.......................................................................................................................6 LIGHTS AND SOUNDS...............................................................................................
OVERVIEW INSTALLATION Automatically call for help when emergency The Dial-Alert is installed using the screws provided. We have also included double sided tape, to use for temporary installation while you are positioning the dialer. Once the dialer is positioned correctly, install it permanently with screws. We have also included wall anchors and a template to help position the screws correctly.
INSTALLATION 2. Thread the telephone line through the top hole in the back of the unit and plug it into the "LINE" jack. If you want to have an answering machine on the same line as the dialer, thread the phone line through the bottom hole in the back of the unit and plug it into the "PHONE" jack of the dialer. The phone line(s) must be inserted through the back of the unit before it is attached to the wall. 3.
LIGHTS AND SOUNDS Below is an explanation of the lights and sounds of the Dial-Alert LIGHTS ACPWR light on ACPWR light off LOBATT. light off LOBATT. light on DISARM light off DISARM light on Keypad backlight flashing Keypad backlight dialer is being powered by AC adapter. dialer is not receiving any AC power. backup battery is connected and working. backup battery is weak, battery needs to be replaced. the dialer will dial the pre-programmed phone numbers when activated.
STANDARD PROGRAMMING PLAYBACK PRE-RECORDED MESSAGE Press and release the [R/P] key, display will show “PLAY” and the dialer will beep. The message is then played back. If you want the dialer work without noise, means no beep or let no body knows the dialer is dialing, just turn off the Speaker Switch inside the case. STORING TELEPHONE NUMBERS This feature enables the user to program as many as 9 different telephone numbers. The dialer can send out 2 different messages.
STANDARD PROGRAMMING STANDARD PROGRAMMING C. Storing telephone numbers in memory (Sends the numeric information to pager only) TO REVIEW OR MODIFY THE PRE-PROGRAMMED PHONE NUMBERS, THE REDIAL COUNT AND/OR THE REPEAT TIMES OF A PHONE NUMBER. 1. Press the [MEM] key, the display will show a letter “M” on the upper left corner. If nothing is entered within 5 seconds, the display will return to the clock mode. 2.
ADVANCED PROGRAMMING PROGRAM THE CALLING TIME ADVANCED PROGRAMMING The calling time is the amount of time the phone will ring until the call is discontected. If the phone is not picked up within this period of time, the dialer will either call again, (depends on the redial count), or advance to the next phone number. The calling time is currently set at 60 seconds. and before you can enter the numeric information (i.e. phone number). The display will show a "P" if a pause period is entered.
ADVANCED PROGRAMMING PROGRAM THE ID CODE OF A TRANSMITTER Before any transmitter/sensor/security system can activate the Dial-Alert, they must be learned (programmed) to communicate with each other. Once they are learned, the button on the transmitter, a door with the door/window sensor on it is opened, someone walks through an area monitored by the motion sensor or the siren sounds on the security system, the dialer will begin to dial the preset telephone numbers and play the pre-recorded message.
ADVANCED PROGRAMMING Entering a premises using the delay dialing If entering a premises through a door that is monitored with a door sensor, the delay dialing is set to 0 seconds and the dialer is on, the dialer will dial the preprogrammed telephone numbers immediately once that door is opened or any sensor is activated.
ADVANCED PROGRAMMING CONNECT THE DIAL-ALERT WITH YOUR EXISTING ALARM SYSTEM You may connect your existing alarm system with the Dial-Alert so that the dialer will be triggered by your alarm system when it is activated. There are 2 ways you can connect your dialer with your existing alarm system. 1. Connect the dialer with the alarm system using hard wire (normally closed). 2. Connect the dialer with the alarm system using the Alarm Sensor (SS-433).
BATTERY MAINTENANCE The AD-433S Dial-Alert comes with 1 battery that at some point you may have to replace: One ADDITIONAL ACCESSORIES Additional sensors and transmitters as well as add on accessories are available to work with your Dial-Alert. 9 volt alkaline battery for the Dial-Alert Recommendation: Test your Dial-Alert periodically to ensure that the battery is working.
ADDITIONAL ACCESSORIES Security Control Panel (SC-001) - Four alarm modes (Day, Night, Away, Chime) - Four zones, each zone controls up to 6 decives - Reliable design with microcontroller - 110dB siren Silent Alarm (SW-433) - Plug into any AC outlet, then plug light into Silent Alarm unit - Light flashes when sensor(s)/transmitter(s) is (are) activated - Silently alerts occupants including the hearing impaired Vibration Sensor (VS-433) - Activates Security Control Panel or Emergency Dialer when vibration
