by SKYTEX Software User Guide
Contents 1. Foreword ………………………………………………………………………………………3 2. Product Configuration……………………………………………………….………………4-6 1).Keyboard function introduction………………………………………….…………………..4 2).Transferring media、recharging…….……………………………………………….……….6 3. Operations……………………………………………………………………………………..7-17 1). Opening reader……………………………………………………………………….…...…7 2). Main interface……………………………………………………………………….…...….7 3). Browse history record………………………………………………………………....…….7 4). eBook Reading.……...…………………………………………………………...…….……8-9 5).
- 1 - Foreword Thank you for purchasing Primer by SKYTEX. In this section of Primer’s User Guide, we will provide an overview of the device and highlight a few basic features so you can start reading as quickly as possible. NOTES: 1. With new lithium batteries, it’s always a good idea to fully charge and drain the battery for the first 3-4 cycles. Doing so will ensure optimum battery life and performance over the life of the device. 2.
- 2 - Product Configuration 1).keyboard function introduction: 1. Power key Long press power on/off 2、3、Navigation keys 1. On the main interface or the catalog list, short press Navigation key to select up /down file 2. Under the interface of e-book, music, and radio, a short press up/down can select up/down page, volume+/volume- and previous/next track, a long press can fast forward/backward . 4.
6. Space key On search menu, short press [Space] to insert space 7. Back key Press [Back] button to return to previous interface. Long press [Back] to return main menu 8. Zoom in /out On the book page screen: press [Zoom] button, the page is magnified in steps and returns to the original scale after the maximum magnification. On search menu, shortly press [Zoom] to alter the search category 9. Play/Pause/delete key 1.
2). Transferring media and recharging: 1. Transferring media files Connect Primer to your computer via the included USB data cable. Your computer will recognize Primer as a mass storage device. Drag your eBook, music, and/or video files onto the device. Alternately, you can drag and drop your media files onto a micro SD card (up to 16GB) and insert your card into Primer’s SD card slot. Primer will automatically sort your files into the proper categories. 2. Recharging 1).
- 3 - Operation 1). Opening reader Holding down the power key for about 3-5 seconds will power on the device 2). Main interface 3).
4). eBook Reading From the main menu, bring the cursor to EBook and press [OK]. Find the file you want to read, highlight it and press [OK]. Function operation brief description: while in the eBook interface, short press the [OK] key to enter the current eBook’s menu, it includes the below functions Page Jump Highlight Page Jump and press [OK]. Enter the page number you would wish to jump to using the numeric keypad and press [OK]. Save Bookmark Highlight Save Bookmark and press [OK].
Browser Mode Highlight Browser Mode and press [OK] Manual Mode: allows users to flip pages at their own pace. Highlight and press [OK] Automatic Mode: eBook pages will flip automatically. Highlight and press [OK] The eBook reader always defaults to manual mode. Flip Time Sets the time for Automatic Mode page flip. Highlight Flip Time from the eBook menu and press [OK]. Highlight the time you wish to set the page flip to and press [OK] Text Color Allows you to change the color of the eBook’s text.
5). Music playing Function Explanation Volume adjust: press [up/down] key to adjust volume Play/Pause Key: Briefly press to play music or pause Previous/next track: press left/right key to go to previous/next track Fast forward /backward: Press and hold [Left] arrow key to play backward, press and hold [Right] arrow key to fast forward. Press [Left] arrow key to previous track, and press [Right] arrow key to the next track.
6). Video Playback Function Explanation Volume adjust: press [LEFT/RIGHT in horizontal orientation] to adjust volume Play/pause: while watching videos pressing [Play/pause] will play/pause current video Fast Forward/Rewind: press and hold [UP/DOWN in horizontal orientation] to fast forward or rewind.
7). Photo Viewing Function Explanation Photo rotate：In the photo view interface, short press [Rotate] button Photo enlarge/reduce: When viewing a photo, short pressing the [Zoom In/Out] button can enlarge/reduce the photo Return/Exit：Short press the [Back] button to exit to the parent directory; long press the [Back] button to go back to the main menu Rotation and Zooming can also be controlled through the photo menu by pressing [OK] while viewing a photo.
8). FM Radio Function Explanation Volume adjust: press [UP/DOWN] to adjust volume Radio setup: Clicking [OK] in the radio interface will bring up the Radio setup menu. In this menu you can choose how to search for available frequencies, save and edit your presets, set your region and record live radio. Search by band: Select and press [OK]. Short press [LEFT/RIGHT] key to select the desired channel a long press will seek the next available frequency.
9). Recording Function Explanation Record/Pause：Short press [PLAY/PAUSE] key to start and stop recording Exit and Save: Short press [BACK] key, a prompt will ask if you would like to save. Press the [LEFT/RIGHT] keys to save or not. Play recorded file: Go into your music menu. Choose “recordings” and select the file you wish to listen to.
10).Explorer 11). Calendar Function Explanation Navigation: Short press [OK] key to highlight day, month, or year. Use the directional keys to go through dates.
12).
13).Settings Function Explanation Display setting: Backlight Timer: Allows you to set backlight-off timer. Brightness: Allows you to set the brightness level. System Setting: Restore Setting: Restore Primer to factory default Key Lock Timer: Allows you to set a timer to lock key functions. Language selection: Select between 19 different languages Sleep Timer: Set to automatically shut down after a period of inactivity (3, 5, 10, 15, 20 minutes).
- 6 - Specifications Panel: 7” TFT LCD Resolution: 800 x 480 Unit size: 207 x 132 x 12mm HARDWARE CPU: ARM9 400Hz Internal Storage: 2GB Expandable micro SD Card Support: Up to 16GB SUPPORTED FORMATS Audio/Video Formats: MP3, WMA, APE, FLAC, AAC, MKV, AVI, RM RMVB, VOB, DAT, MP4, FLV, 3GP Image Formats: JPG, BMP, GIF INS AND OUTS USB: Mini-USB2.0 Port Card Reader: SD Slot 3.
- 7 - Troubleshooting 1. The reader does not turn on · Plug in the power adapter and try again · If still does not turn on after battery is fully charged or while the device is plugged in，please contact customer service/tech support. 2. There is no sound in earphones · Please check to see if the volume has been set to appropriate levels. · Please check that the earphones are plugged into the 3.5mm audio jack properly. 3.
